基于涡流脉冲相位热成像的金属材料裂纹检测

胡德洲; 左宪章; 李伟

基于涡流脉冲相位热成像的金属材料裂纹检测

军械工程学院无人机工程系,河北石家庄 050003

详细信息

通讯作者:
胡德洲（1990-），男，湖北襄阳人，硕士研究生，主要从事电磁热成像无损检测技术的研究。 Email:hdz199075@sina.cn

中图分类号: TN911.72; TG115.28
计量
- 文章访问数: 1872
- HTML全文浏览量: 108
- PDF下载量: 236
出版历程
- 刊出日期: 2014-07-14

Crack detection for metallic materials based on eddy-current pulsed-phase thermography

Department of UAV Engineering,Ordnance Engineering College,Shijiazhuang 050003,China

摘要

摘要: 涡流热成像可以对金属材料表面、近表面缺陷进行快速准确的检测。采用涡流热成像与脉冲相位分析相结合的方法，针对裂纹附近相位谱的分布规律及温度场对相位谱的影响关系问题，分别对带有上表面裂纹和下表面裂纹的45#钢料进行感应加热仿真和实验分析。结果表明，相位谱分布与温度大小无关，只与温度变化趋势有关，相位谱图对不均匀加热有很好的抑制作用，可以扩大裂纹的检测范围,当频率低于12.5 Hz时能够清晰地识别裂纹。结合实验验证了仿真结论的正确性，为下一步利用相位信息实现缺陷的定量检测提供参考。
- 无损检测 /
- 涡流加热 /
- 图像处理 /
- 脉冲相位法
Abstract: The surface and near surface crack of metallic materials can be detected efficiently and accurately by eddy current thermography. In this paper, combining with eddy current thermography and pulsed phase analysis, 45# steel with surface and subsurface cracks were studied by inductive heating simulation and experiments, which were aimed to solve the problem of the phase spectrum distribution and the influence of temperature distribution on the phase spectrum. It shows that, the phase spectrum distribution has nothing to do with temperature value, but is closely related to temperature trend. The phase image has good suppression to inhomogeneous heating, and can also broaden the detection range. Crack can be easily detected when frequency is below 12.5 Hz. The conclusions are experimentally verified, in order to provide guidance for quantitative crack detection with the phase information in the future study.
- nondestructive testing /
- eddy current heating /
- image processing /
- pulsed phase analysis

HTML全文

参考文献(1)

[1]Feng Fuzhou, Zhang Chaosheng, Zhang Lixia, et al. Application of infrared thermal wave technology in fault diagnosis and defect detection for armored equipments[J]. Journal of Applied Optics, 2012, 33(5): 827-831.
冯辅周, 张超省, 张丽霞, 等. 红外热波技术在装甲装备故障诊断和缺陷检测中的应用[J]. 应用光学, 2012, 33(5): 827-831.
[2]Xing Chunfei, Li Yanhong, Chen Dapeng, et al. Ultrasonic infrared technology for checking inner wall of metal pipeline[J]. Journal of Applied Optics, 2009, 30(3): 465-468.
邢春飞, 李艳红, 陈大鹏, 等. 基于超声红外技术对金属管内壁缺陷的检测[J]. 应用光学, 2009, 30(3): 465-468.
[3]Ben W, Darryl P A，Peter C, et al. Eddy-current induced thermography-probability of detection study of small fatigue cracks in steel, titanium and nickel-based superalloy[J].NDT&E International, 2012, 49:47-56.
[4]Seunghoon B k, William X, Feng M Q, et al. Nondestructive corrosion detection in RC through integrated heat induction and IR thermography[J]. J. Nondestruct Eval, 2012, 31: 181-190.
[5]Zuo Xianzhang, Chang Dong, Qian Sumin, et al. Simulation analysis of crack detecting mechanism using pulsed eddy current thermography[J]. Laser & Infrared, 2012, 42(9):998-1003.
左宪章, 常东, 钱苏敏, 等. 脉冲涡流热成像裂纹检测的机理仿真分析[J]. 激光与红外, 2012, 42(9):998-1003.
[6]Zuo Xianzhang, Chang Dong, Wang Jianbin, et al. Analysis of magnetocaloric effect in electromagnetically stimulated thermography for detecting crackin ferromagnetic material[J]. J. Magn Mater Devices, 2013, 44(3):31-36.
左宪章, 常东, 王建斌, 等. 电磁激励热成像检测铁磁性材料裂纹的磁热效应分析[J]. 磁性材料及器件, 2013, 44(3):31-36.
[7]Chang Dong, Zuo Xianzhang, Tian Guiyun, et al. Analysis of the crack orientation effect on pulsed eddy current stimulated thermography[J]. Journal of Shanghai Jiao Tong University, 2013, 47(5):779-785.
常东, 左宪章, 田贵云, 等. 裂纹方向对脉冲涡流热成像的影响 [J]. 上海交通大学学报:自然版, 2013, 47(5):779-785.
[8]Yang S X, Tian G Y, Abidin I Z, et al. Simulation of edge cracks using pulsed eddy current stimulated thermography[J]. Journal of Dynamic Systems, Measurement, and Control, 2011, 133: 011008-1-011008-6.
[9]Oswald T B, Sorger M. Detection of subsurface defects in aluminium with thermo-inductive inspection[J]. SPIE, 2011, 8013: 801310.1-801310.10.
[10]Oswald T B, Sorger M. Localizing surface cracks with inductive thermographical inspection: from measurement to image processing[J]. Quantitative Infrared Thermography Journal, 2011, 8(2): 149-164.
[11]Tian H Y, Pan M G. Eddy current pulsed phase thermography and feature extraction[J]. Applied Physics Letters, 2013, 103(8): 084104-1-084104-4.
[12]He Y, Pan M, Tian G, et al. Eddy current pulsed phase thermography for subsurface defect quantitatively evaluation[J]. Applied Physics -etters, 2013, 103(14):144108-144108-4.
[13]Maldague X, Marinetti S, Pulsed infrared thermography[J]. Journal of Applied Physics, 1996,79(5): 2694-2698.
[14]Vrana J, Goldammer M, Baumann J, et al. Mechanisms and models for crack detection with induction thermography[J]. AIP Conference Proceedings, 2008, 975: 475.
