用于CCD立靶的双光幕触发系统研究

董涛; 华灯鑫; 李言; 倪晋平

用于CCD立靶的双光幕触发系统研究

董涛^1,2, ,,
华灯鑫¹,
李言¹,
倪晋平²

1.
西安理工大学机械与精密仪器工程学院,陕西西安 710048;
2.
西安工业大学光电工程学院,陕西西安710032

详细信息

通讯作者:
董涛（1980-），男，陕西西安人，博士研究生，讲师，主要从事靶场光电测试技术方面的研究。 Email：dongtao80@126.com

中图分类号: TN29;TJ012.3
计量
- 文章访问数: 1799
- HTML全文浏览量: 162
- PDF下载量: 256
出版历程
- 刊出日期: 2014-07-14

Dual-screen triggering system for CCD vertical target

1.
School of Mechanical and Precision Instrument Engineering,Xi-an University of Technology,Xi-an 710048,China;
2.
School of Opto-Electronic Engineering,Xi-an Technological University,Xi-an 710032,China

摘要

摘要: 针对靶场测试当中CCD立靶测量系统需要稳定可靠触发的需求，提出一种双光幕触发系统。采用镜头式光幕探测器配合高亮度LED慢散射光源组成触发探测光幕，利用2个同样的光幕探测器配合测时装置组成区截测速系统，根据测得的速度值判定飞越探测光幕的目标是否为真实弹丸，并决定是否输出触发信号。根据速度值V和触发光幕至CCD探测光幕的距离计算出弹丸飞越至探测光幕的时间，然后在弹丸飞越将近至探测光幕的时刻输出触发信号。该方案不但可以提高系统的稳定性，避免非真实目标对系统的干扰，还可以为后续CCD图像采集系统在准确时刻提供触发信号。经实验证明，所设计的双光幕触发系统的速度测量误差不大于0.4％，完全满足CCD立靶测量系统需要精确触发的要求。
- 着靶坐标 /
- CCD相机 /
- 立靶 /
- 双光幕
Abstract: On the request of the stable and reliable trigger required in charge-coupled device (CCD) vertical target measurement system in the condition of firing range, a dual-screen trigging system was presented . The trigging detecting screen was composed of lens-type screen detector, working with the high-intensity LED slow-scattering light, and the velocity-measuring system consists of two identical screen detectors working together with chronometer, and then it judged whether the projectile passing through the screen was real based on the measured velocity and whether to output the trigging signal or not. The time for projectile flying from impacting screen to detecting screen was achieved according to the velocity value V and the distance between impacting screen and detecting screen, and then the triggering signal was output while the projectile was approaching to CCD detecting screen. The proposed scheme can improve the stability of the system, prevent the system from being interfered by unreal targets, and can transmit trigging signal at the precise time to followup CCD image-acquisition system. It has been proved by experiment that the speed measurement error of the designed dual-screen triggering system is not more than 0.4％, fully meeting the demand of the stable and reliable trigger requirement of the CCD vertical target.
- projectile coordinate /
- CCD camera /
- vertical target /
- dual-screen

HTML全文

参考文献(1)

[1]Mccarthy B D, Regan B J. Position measuring apparatus and method：US, 4885725[P/OL].1989-12-05[2012-11-12].http://patft.uspto.gov.
[2]Chang C C, Chang H C, Tang L C, et al. Hybrid-integrated prism array optoelectronic targeting system[J]. Optical Laser Technology, 2005,37: 591-596.

[3]Davis L R, Brown T E. Photocell array sensor for projectile position detection: US, 6617563 B1[P/OL]. 2003-09-09[2007-12-11].http://patft.uspto.gov.
[4]Lu S T, Chou C, Lee M C, et al. Electro-optics target system for position and speed measurement[J]. IEE Proceedings-A, 1993, 140(4): 252-256.
[5] Goodwin M W, Melsheimer T T. Target scoring and display system and method: US, 4763903[P/OL]. 1988-08-16[2013-01-31].http://patft.uspto.gov.
[6] Downing D L. Moving object monitoring system: US, 5988645[P/OL]. 1999-11-23[2013-01-31].http://patft.uspto.gov.
[7]Ma Weihong, Ni Jinping, Dong Tao, et al. Design of high precision CCD vertical target coordinate measurement system used indoor [J]. Optical Technique，2012，38(2)：180-184.
马卫红，倪晋平，董涛，等.高精度CCD室内立靶测试系统设计[J].光学技术，2012，38(2):180-184.
[8]Liu Wen, Xiong Rensheng, Zhang Yunqi，et al. Research on acquirement rate of CCD vertical target coordinate measurement system[J].Acta Photonica Sinica，2008，37(2)：413-416.
刘文，熊仁生，张蕴琦，等. CCD立靶坐标测量系统捕获率研究[J].光子学报，2008，37（2）：413-416.
[9]Luo Honge，Chen Ping，Gu Jinliang，et al. Error analysis on the linear CCD crossing measurement system[J]. Optical Technique，2009，35（3）391-393.
罗红娥, 陈平, 顾金良，等. 线阵CCD立靶系统全视场测量误差分析[J].光学技术，2009，35（3）391-393.
[11]Dong Tao, Ni Jinping. Measuring principle of vertical target based on one linear array CCD camera[J]. Journal of Applied Optics，2011，32(3)：482-485.
董涛，倪晋平. 单线阵CCD相机立靶测量原理[J]. 应用光学，2011，32(3)：482-485.
[12]Dong Tao, Hua Dengxin, Li Yan, et al. Method for measuring target coordinates of two projectiles impacting simultaneously[J]. Acta Armamentar II，2013，34(10)：1273-1278.
董涛，华灯鑫，李言，等. 一种双目标同时着靶坐标测量方法[J]. 兵工学报，2013，34(10)：1273-1278.
[13]Dong Tao, Hua Dengxin, Li Yan, et al. Measuring principle of vertical target density based on single linear array CCD camera[J]. Optik , 2014,125:176-178.
