AOTF光谱相机前置变焦光学系统设计

赵昭, 安志勇, 高铎瑞, 王劲松, 蔡红星, 钟刘军

赵昭, 安志勇, 高铎瑞, 王劲松, 蔡红星, 钟刘军. AOTF光谱相机前置变焦光学系统设计[J]. 应用光学, 2014, 35(4): 580-585.
引用本文: 赵昭, 安志勇, 高铎瑞, 王劲松, 蔡红星, 钟刘军. AOTF光谱相机前置变焦光学系统设计[J]. 应用光学, 2014, 35(4): 580-585.
shu
Zhao Zhao, An Zhi-yong, Gao Duo-rui, Wang Jin-song, Cai Hong-xing, Zhong Liu-jun. Design of fore continuous zoom optical system of AOTF spectral camera[J]. Journal of Applied Optics, 2014, 35(4): 580-585.
Citation: Zhao Zhao, An Zhi-yong, Gao Duo-rui, Wang Jin-song, Cai Hong-xing, Zhong Liu-jun. Design of fore continuous zoom optical system of AOTF spectral camera[J]. Journal of Applied Optics, 2014, 35(4): 580-585.
shu

AOTF光谱相机前置变焦光学系统设计

  • 1.

    长春理工大学 光电工程学院,吉林 长春 130022;

  • 2.

    长春理工大学 空间光电技术研究所,吉林 长春 130022;

  • 3.

    长春理工大学 理学院,吉林 长春 130022

详细信息
    通讯作者:

    赵昭（1991-），女，陕西宝鸡人，硕士研究生，主要从事光学系统设计及AOTF光谱相机的研究。 Email: zhaozhao_cust@163.com

  • 中图分类号: TN202;TH703

Design of fore continuous zoom optical system of AOTF spectral camera

  • 1.

    School of OptoElectronic Engineering,Changchun University of Science and Technology,Changchun, Changchun 130022,China;

  • 2.

    Institute of Space Photoelectric Technology,Changchun University of Science and Technology,Changchun 130022,China;

  • 3.

    School of Science,Changchun University of Science and Technology,Changchun 130022,China

摘要

    摘要
  • 摘要: 基于声光可调谐（AOTF）光谱相机的技术指标和性能要求，采用机械正组补偿方式，实现了10可见光波段连续变焦光学系统的设计。详细介绍各组元的光焦度分配和初始结构的计算过程，并用Zemax光学软件进行设计，对设计结果进行了像质评价和像差分析，并对凸轮曲线进行求解。设计和分析结果表明：该系统在0.38 m~0.7 m波段实现了30 mm~300 mm连续变焦，在空间频率50 lp/mm处调制传递函数（MTF）值最大达到0.7。该系统可工作在可见光波段，具有变倍比大、变焦曲线平滑的特点，能够满足光谱相机的成像要求。
    Abstract: Based on performance and application requirements of acousto-optic turnable filter (AOTF) spectral camera, the positive mechanical compensation was introduced to achieve a visible optical system which was 10 continuous zoom configuration with high speed. Details were given to present the process of focal power distribution and computation of initial structure, the simulation was conducted with Zemax to show the results. Then the image quality evaluation was done, the cam curve was solved and the aberration was analyzed. Results show that the system can realize 30 nm~300 mm continuous zoom at 0.38 m~0.7 m, and the maximum modulation transfer function (MTF) is 0.7 at 50 lp/mm . The system is characterized by large zoom ratio and smooth cam curve, which make the system reach the target of AOTF spectral camera.
    • HTML全文
    • 参考文献(1)
  • [1]Jiang Qinghui, Qiu Yuehong.Design of data acquisition system for AOTF polarization spectral imaging instrument[J]. Infrared and Laser Engineering, 2012, 41(1):218-222.
    姜庆辉. AOTF偏振光谱成像数据采集系统设计[J]. 红外与激光工程，2012，41(1):218-222.
    [2]Chang Lingying, Zhao Baochang, Qiu Yuehong. Optical scheme of AOTF imaging spectrometer optical system[J]. Journal of applied optics. 2012, 33(1):5-8.
    常凌颖,赵葆常,邱跃洪，等.AOTF成像光谱仪光学系统的最优方案选择[J].应用光学,2012,33(1):5-8.
    [3]Song Yulong, Liu Zhiyin, Cui Chengjun. Optical design of the fore hyper-spectral imaging zoom system[J]. Acta Photonic Sinic, 2012,41(11):1301-1306.
    宋玉龙，刘智颖，崔成君.前置超光谱成像变焦系统的设计[J]. 光子学报. 2012,41(11):1301-1306.
    [4]Lu Qiang, Ji Yiqun.Design of a fore continuous zoom optical system with high speed[J]. Acta Optical Sinica, 2010,30(9):2674-2679.
    陆强，季轶群. 大相对孔径连续变焦前置物镜的光学设计[J]. 光学学报, 2010, 30(9):2674-2679.
    [5]Fan Xuewu, Cheng Rongli. Optical design of prefixing objective of imaging spectrometer[J]. Optical Technique,2003, 29(4): 498-499, 503.
    樊学武，陈荣利. 一种成像光谱仪前置物镜的设计[J]. 光学技术，2003，29(4): 498- 499, 503.
    [6]Tao Chunkan. Zoom focus optics system design[M]. Beijing:National Defense Industry Press, 1998.
    陶纯堪. 变焦距光学系统设计[M]. 北京：国防工业出版社，1988.
    [7]Cai Wei. Compensation mode of zoom change times of the zoom system[J]. Optics and Precision Engineering, 2011,19(9):2063-2071.
    蔡伟. 变焦距系统的变倍补偿方式[J]. 光学精密工程, 2011,19(9):2063-2071.
    [8]Yu Daoyin, Tan Hengying. Engineering optics[M]. Beijing:China Machine Press, 2006.
    郁道银，谈恒英.工程光学[M]. 北京:机械工业出版社， 2006.
    [9]Li Shixian， Zhen Nianle. Optical design handbooks[M]. 2nd ed. Beijing:Beijing Institute

     of Technology Press, 1990.
    李世贤,郑年乐. 光学设计手册[M]. 北京:北京理工大学出版社,1990.
    [10]Yuan Xucang. Optical system design[M]. Beijing:Science Press, 1985.
    袁旭沧. 光学系统设计[M]. 北京：科学出版社，1985.
