光电成像检测系统像面照度均匀性分析

赵霞; 刘宾

光电成像检测系统像面照度均匀性分析

赵霞^,,
刘宾

1.
中北大学电子测试技术国家重点实验室,山西太原 030051

详细信息

通讯作者:
赵霞 (1981-)，女，山西太原人，讲师，主要从事光电检测、信息处理方面的研究。 Email:zhaoxianuc@126.com

中图分类号: TP394.1；TH691.9
计量
- 文章访问数: 2128
- HTML全文浏览量: 101
- PDF下载量: 292
- 被引次数: 0
出版历程
- 刊出日期: 2014-03-15

Illuminance uniformity of image plane in photoelectronic imagetesting system

ZHAO Xia^,,
LIU Bin

1.
National Key Laboratory for Electronic Measurement Technology,North University of China,Taiyuan 030051,China

摘要

摘要: 非均匀发光光源、大视场角等因素会造成光学成像检测系统像面照度分布不均匀,进而导致检测效率下降。研究非均匀发光光源和大视场角对像面照度均匀性的影响程度,首先建立光源间距与受光面接收照度间的关系模型，仿真分析不同LED间距对像面照度均匀性的影响,然后建立光学耦合系统的物面张角和像面照度间的关系模型，仿真分析物面张角对像面照度均匀性的影响。实验结果表明：在非均匀发光光源和大视场角的作用下，检测系统会造成像面照度严重不均匀现象。研究结果为后续像面照度校正算法设计提供了理论依据。
- 光学成像 /
- 检测 /
- 像面光照度 /
- 均匀性
Abstract: Non-uniform light source and wide field angle were two causes for illumination non-uniformity of image plane in photoelectronic image testing system. To study the influence, the relationship model between spacing of LED light source and image plane illumination was built. The influence of different LED intervals on image plane illumination was simulated and analyzed. The relationship model between opening angle of object plane of optical coupling system and image plane illumination was established, and the influence of opening angle of object plane on illuminance uniformity of image plane was simulated and studied. The experiment results show that non-uniform light source and wide field angle are two main causes for non-uniformity illumination of image plane, which provides the theoretical basis for designing better corresponding correction algorithm.
- optical imaging /
- detection /
- illumination intensity at image plane /
- uniformity

HTML全文

参考文献(1)

[1]张新,林家明,张哲,等.大视场CCD成像系统像面均匀性测试技术研究[J].光学技术，2005,31(6): 846-853.
ZHANG Xin，LIN Jia-ming，ZHANG Zhe，et al.Research on measuring technique for image sensors’ uniformity of the CCD image-forming system with large-field angle [J].Optical Technique, 2005,31(6): 846-853.(in Chinese with an English abstract)
[2]吴亚平,张天序,桑农,等.大视场主动光学成像系统的成像研究[J].光学精密工程，2000,8（2）:106-108.
WU Ya-ping, ZHANG Tian-xu, SANG Nong, et al.Imaging of active optical imaging system with a wide field of view[J]. Optics and Precision Engineering, 2000, 8(2):106-108. (in Chinese with an English abstract)
[3]沈湘衡，杨亮，贺庚贤,等.光电测量设备光学系统的像面照度均匀性检测[J].光学精密工程，2008,16（12）：2513-2536.
SHEN Xiang-heng,YANG Liang,HE Geng-xian,et al. Measurement of image plane illumination non-uniformity of optical system in photoelectric equipment[J].Optics and Precision Engineering, 2008, 16(12): 2513-2536. (in Chinese with an English abstract)
[4]钟兴，张元，金光.大视场光学系统像面照度均匀性优化[J].光学学报，2012,32(3):0322004.
ZHONG Xing, ZHANG Yuan, JIN Guang. Illumination uniformity optimization of wide-viewing-field optical system[J] Acta Optica Sinaca，2012,32(3) : 0322004. (in Chinese with an English abstract)
[5]许兴胜,明海,赵欣,等,白光照明和CCD投影成像在线监测聚合物光纤[J]. 光电工程,2000,27(3):34-38.
XU Xing-sheng, MING Hai, ZHAO Xin, et al. On-line detection of white light illuminated polymer optic fiber with CCD projection imaging[J]. Opto-Electronic Engineering, 2000,27(3):34-38.(in Chinese with an English abstract)
[6]胡海蕾.LED照明光学系统的设计及其阵列光照度分布研究[D].福州：福建师范大学，2005.
HU Hai-lei. Design of LED illumination system and research of illuminance distribution of LED arrays [D].Fuzhou: Fujian Normal University,2005.(in Chinese)
[7]浦昭邦，屈玉福，王亚爱.视觉检测系统中照明光源的研究[J].仪器仪表学报，2003,24（4）：438-439.
PU Zhao-bang;QU Yu-fu;WANG Ya-ai. Study of iIlumination in vision measuring system[J]. Chinese Journal of Scientific Instrument, 2003,24（4）：438-439. (in Chinese with an English abstract)
[8]严萍，李剑清. 照明用LED光学系统的计算机辅助设计[J].半导体光电,2004,25(3):181-183.
YAN Ping, LI Jian-qing. Computer aid design of optical system of LED for illumination[J]. Semiconductor Optoelectronics,2004,25(3):181-183. (in Chinese with an English abstract)
