1.06 μm激光对CCD、CMOS相机饱和干扰效果对比研究

邵铭; 张乐; 张雷雷; 柴国庆; 胡琥香

1.06 μm激光对CCD、CMOS相机饱和干扰效果对比研究

1.
中国人民解放军63891部队,河南洛阳 471003

详细信息

通讯作者:
邵铭（1979-），男，河南洛阳人，硕士，工程师，主要从事光电对抗技术方面的研究工作。 Email:lyshaoming@163.com

中图分类号: TN215
计量
- 文章访问数: 2461
- HTML全文浏览量: 133
- PDF下载量: 418
- 被引次数: 0
出版历程
- 刊出日期: 2014-01-15

Comparative study on saturation effect of 1.06 μm laser jamming CCD and CMOS cameras

1.
Unit 63891 of PLA,Luoyang 471003,China

摘要

摘要: 为了对比激光对CCD、CMOS两种图像传感器的干扰效果，利用1.06 m高重频激光开展了对CCD、CMOS两种相机的饱和干扰实验研究，分析了两种相机在干扰有效面积、饱和干扰面积、干扰前后图像相关度等与激光入射功率之间的关系。实验结果表明:CMOS相机达到单元像素饱和的激光功率阈值是CCD相机的20倍；要达到相同的干扰有效面积，所需的激光功率CMOS相机要大于CCD相机10倍～100倍；要达到相同的饱和像元数，所需的激光功率CMOS相机比CCD相机约大10倍～60倍。因此，CMOS相机要比CCD相机具有更好的抗1.06 m激光干扰能力。
- 激光干扰 /
- CCD相机 /
- CMOS相机 /
- 饱和效应
Abstract: To compare the jamming effect of laser on charged-coupled device (CCD) and complementary metal-oxide semiconductor （CMOS） imagers, jamming experiments with the wavelength of the 1.06 m high-repetition-rate laser were conducted. The relationships of the two cameras- laser incident power with the jamming effective area, saturated pixel number and the imaging correlation were analyzed individually. The experiment results show that the laser power threshold of one pixel saturation of CMOS camera is 20 times than CCD camera; in order to reach the same jamming effective area, the laser power of CMOS camera is 10~100 times higher than the CCD camera; and to reach the same saturation pixel, the laser power of CMOS camera is 10~60 times higher than the CCD camera. Therefore, the CMOS camera is better than CCD camera on the antijamming of the 1.06m laser.
- laser jamming /
- CCD camera /
- CMOS camera /
- saturation effect

HTML全文

参考文献(1)

［1］侯睿，赵尚弘，幺周石，等．卫星光通信系统中CCD器件的空间辐射特性研究[J]．应用光学，2011，32(6)：1263-1264．
HOU Rui,ZHAO Shang-hong,YAO Zhou-shi,et al. Radiation characteristics of CCD in satellite optical communication system[J]. Journal of Applied Optics,2011,32(6):1263-1264.(in Chinese with an English abstract)
[2]贾建军，舒嵘，王斌永．无人机大面阵CCD相机遥感系统[J]．光电工程，2006，33(8)：90-92．
JIA Jian-jun,SHU Rong,WANG Bin-yong. Large frame CCD camera system for unmanned aircraft remote sensing[J]. Opto-Electronic Engineering, 2006,33(8):90-92. (in Chinese with an English abstract)
[3]李海燕，朱敏，卢洪义．视场外激光对CCD成像制导武器的干扰研究[J]．红外与激光工程，2009，38(1)：66-69．
LI Hai-yan, ZHU Min, LU Hong-yi. Off-axis laser disturbing CCD imaging guidance weapons[J].Infrared and Laser Engineering,2009, 38(1): 66-69. (in Chinese with an English abstract)
[4]刘泽金，陆启生，蒋志平，等．面阵CCD图像传感器点破坏机理研究[J]．应用激光，1995，15(2)：85-86．
LIU Ze-jin, LU Qi-sheng, JIANG Zhi-ping, et al. Research on damaging mechanism of CCD video camera irradiated by a focusing laser beam[J].Applied Laser,1995,15(2):85-86. (in Chinese with an English abstract)
[5]王世勇，付有余，郭劲，等．脉冲激光对CCD图像跟踪系统干扰效果评估[J]．激光与红外，2002，32(1)：20-22．
WANG Shi-yong, FU You-yu, GUO Jin, et a1. Effect evaluation of array CCD detector tracking system irradiated by pulse laser[J]. Laser & Infrared, 2002,32(1):20-22. (in Chinese with an English abstract)
[6]孙守红，郭立红，王立军．808nm激光对可见光面阵CCD的干扰损伤研究[J]．长春理工大学学报:自然科学版，2008，31(1)：19-21．
SUN Shou-hong, GUO Li-hong, WANG Li-jun. Interference damage to visible light plane array CCD induced by 808nm laser[J].Journal of Changchun University of Science and Technology: Natural Science Edition, 2008,31(1):19-21. (in Chinese with an English abstract)
[7]王金宝．激光辐照可见光面阵Si-CCD探测器实验研究[D]．长沙：国防科技大学，2003．
WANG Jin-bao. Experimental investigation of the visible light arrays of Si-CCD irradiated by the laser[D]. Changsha:Graduate School of National University of Defense Technology,2003. (in Chinese)
[8]赵鹏，沈庭芝，单宝堂．基于CMOS图像传感器的微型无人机遥感系统设计[J]．光子学报，2008，37(8)：1657-1659．
ZHAO Peng,SHEN Ting-zhi,SHAN Bao-tang. The application of remote sensing system for micro UAV based on CMOS image sensor[J]. Acta Photonica Sinica,2008,37(8):1657-1659. (in Chinese with an English abstract)
[9]林均仰，舒嵘，黄庚华，等．激光对CCD及CMOS图像传感器的损伤阈值研究[J]．红外与毫米波学报，2008，27(6)：475-478．
LIN Jun-yang, SHU Rong, HUANG Geng-hua, et al. Study on threshold of laser damage to CCD and CMOS image sensors[J]. Journal of Infrared and Millimeter Waves, 2008,27(6):475-478. (in Chinese with an English abstract)
[10]张震．可见光CCD的激光辐照效应实验研究[D]．长沙：国防科技大学，2010．
ZHANG Zhen. Experimental study of laser induced effect on visible light CCD[D].Changsha:Graduate School of National University of Defense Technology,2010. (in Chinese)
[11]车进喜，王东，张恒伟，等．激光参数对红外成像系统干扰效果影响的实验研究[J]．应用光学，2011，32(5)：992997．
CHE Jinxi, WANG Dong, ZHANG Hengwei, et al. Influence of laser parameters on jamming effectiveness of IR imaging system[J].Journal of Applied Optics,2011,32(5): 992997. (in Chinese with an English abstract)
