风云二号辐射计百叶窗式遮光罩杂散光抑制研究

李欣耀; 陈福春; 陈桂林

风云二号辐射计百叶窗式遮光罩杂散光抑制研究

1.
中国科学院上海技术物理研究所中国科学院红外探测与成像技术重点试验室,上海 200083

详细信息

通讯作者:
李欣耀（1979-），男，江西南昌人，硕士，副研究员，主要从事空间杂散光星地一体化研究和红外遥感仪器光学系统设计的工作。Email:xinyaoli@sina.com

中图分类号: TN202
计量
- 文章访问数: 1716
- HTML全文浏览量: 105
- PDF下载量: 317
- 被引次数: 0
出版历程
- 刊出日期: 2014-01-15

Stray light suppression in FY-2 radiometer with shutter

1.
Key Laboratory of Infrared System Detection and Imaging Technology,Shanghai Institute of Technical Physics of the Chinese Academy of Sciences,Shanghai 200083,China

摘要

摘要: 风云二号卫星扫描辐射计为视场分光方式的R-C光学系统，视场外的杂光掠过次镜穿过主镜孔直接混入信号光路照射在焦面上，形成直射杂光。为了消除该直射杂光，使用TracePro软件对辐射计模型进行正追和倒追，都追到了直射杂光的存在，利用Zemax软件仿真找出了该直射杂光的形成机理，并计算出该直射杂光域。根据仿真和计算，设计了可以透信号光阻挡杂散光的叶片状次镜遮光罩。软件仿真表明：百叶窗式遮光罩可以彻底抑制该区域可见直射杂光，积分球实验也验证了该百叶窗式遮光罩可以降低辐射计95.2%的可见杂光。
- 杂光抑制 /
- R-C系统 /
- 百叶窗 /
- 直射杂光
Abstract: FY-2 radiometer is a multi-field Ritchey-Chretien（R-C） optical system. Stray light outside the field grazes the secondary mirror, then goes across the primary mirror, and finally hits the detector, which produces the straight hit path. To eliminate this straight hit, we used Tracepro software package to trace the path and used Zemax software package to find out the generation mechanisms of it, and then calculated the area of the straight hit. Based on the simulation and calculation, a shutter with some laminas was designed, which could allow signal light to transmit but prevent the stray light entering into the detector. Results of the simulation illuminate that the direct stray light in this area can be eliminated completely by using the designed shutter. Also the integrated sphere experiment indicates the shutter can decrease 95.2% of the visible stray light.
- stray light suppressing /
- R-C optical system /
- Shutter /
- direct stray light

HTML全文

参考文献(1)

［1］李婕,明景谦,卢若飞.一种改进型的红外卡塞格林光学系统设计[J]. 红外技术，2010, 32(2):76-80.
LI Jie,MING Jing-qian,LU Ruo-fei. Design of an ameliorating infrared Cassegrain optical system[J]. Infrared Technology, 2010, 32(2): 76-80.(in Chinese with an English abstract)
[2]魏彩英，张晓虎，邱康睦．风云二号静止气象卫星图像杂散信号分析[J]．应用气象学报,2004，15(5):564-571.
WEI Cai-ying, ZHANG Xiao-hu,QIU Kang-mu. Analysis of scattered signal in geostationary meteorological satellite image[J].J. Appl. Meteorol. Sci.,2004,15(5):564-571. (in Chinese with an English abstract)
[3]GUO Q, XU J M, HANG W J. Stray light modeling and analysis for the FY-2 meteorological satellite[J]. International Journal of Remote Sensing, 2005,26(13):2817-2830.
[4]李欣耀,原育凯,裴云天,等. 风云二号扫描辐射计可见杂光分析与抑制[J].科学技术与工程, 2006,6(12):1605-1608.
LI Xin-yao,YUAN Yu-kai,PEI Yun-tian,et al.Analyzing and suppressing visible stray light of scanning radiometer for FY-2 meteorological satellite[J]. Science Technology and Engineering, 2006,6(12):1605-1608. (in Chinese with an English abstract)
[5]钟兴,张雷,金光.反射光学系统杂散光的消除[J].红外与激光工程,2008，37(2):316-318.
ZHONG Xing, ZHANG Lei, JIN Guang. Stray light removing of reflective optical system[J]. Infrared and Laser Engineering,2008,37(2):316-318. (in Chinese with an English abstract)
[6]李欣耀，裴云天，王成良. 空间光学系统中红外杂散辐射的抑制方法[J]. 红外，2011, 32(1):31-34.
LI Xin-yao,PEI Yun-tian,WANG Cheng-liang.Suppressing method of infrared stray radiation in space optical system[J].Infrared,2011,32(1):31-34. (in Chinese with an English abstract)
