High-precision photoelectric centering instrument based on PSD
-
摘要: 针对目前定心仪精度不高、并依赖于人眼的现状，提出一种基于PSD的高精度定心仪研究方法。采用自准直光路形式和位置敏感探测器PSD对经过被测目标返回的光斑实行定位，并通过读取计算机上的坐标值来判断是否达到准确的定心。文中对定心仪的光学系统进行设计，并运用神经网络的训练来校正PSD的非线性，在测量范围2 mm~500 mm内定心精度达到1 m的设计要求。Abstract: Against the current situation of centering instrument with low precision and dependent on the human eyes, a research method of high-precision centering instrument based on position-sensitive detector (PSD) was put forward. Through the use of self-collimated optical path and PSD, the return light spot from the target was located, and the coordinate value on the computer was read to judge whether the accurately centering was achieved. The design of the centering instrument optical system and the nonlinear correction of PSD by neural network training were carried out. Results show that t can achieve the design requirement of centering accuracy with measuring range of 2 mm~500 mm, which is much better than traditional centering instruments.
-
Keywords:
- optical design /
- centering instrument /
- high-precision /
- position sensitive detector /
- nonlinear
-
-
［1］王肇勋.整组物镜各面偏心差的测量[J].光学工程,1980,7(1):1-11
WANG Zhao-xun.The test of entire optical system errors[J].Optical Engineering, 1980,7(1):1-11.(in Chinese with an English abstract)
[2]高志荣.高精度中心偏测量仪的设计和使用[J].光学工程,1983,10(3):40.
GAO Zhi-yong.The design and use of high precision off-center measurement system[J]. Optical Engineering, 1983,10(3):40. (in Chinese with an English abstract)
[3]张欣婷.高精度光电自准直仪的研究[D].长春：长春理工大学,2010.
ZHANG Xin-ting.The research of high-precision photoelectric autocollimator[M]. Changchun: Changchun University of Science and Technology, 2010.(in Chinese) -
