Design of SONG Shack-Hartmann optical system
-
摘要: 根据中国宋标准节点望远镜系统要求，设计了用于望远镜波前误差测量的夏克哈特曼（S-H）传感器光学系统。从望远镜衍射极限成像和观测星等要求出发，对S-H的采样点数选取和波面重建精度进行分析计算,根据所选微透镜阵列和宋望远镜光学参数进行S-H准直镜的消像差设计，采用两组双胶合透镜实现了480 nm~680 nm波长范围的系统衍射极限成像。设计的系统能够实现6等星的目标测量，测量精度0.05。根据设计结果搭建了实验系统，对主镜初始状态和校正之后的波前误差进行了测量，并将S-H测量结果与4D干涉仪测量结果进行了比较。实验结果表明：所设计S-H系统测量精度0.008 m（RMS），能够满足宋望远镜的技术要求。Abstract: In this paper, we gave an optic design of stellar oscillations network group (SONG) Shack-Hartmann (S-H). The optical system and main parameters of S-H were determined, mainly according to the demands of diffraction limited imaging quality and magnitude of the telescope; According to the optical parameters of SONG and the micro lens array, an eliminating aberration design was carried out based on two doublets; The performance of the S-H was within diffraction limit. Designing results showed that the 6th magnitude and accuracy of 0.05 could be achieved. Based on the design results, an experimental system was built. A comparative study on measuring accuracy between S-H and 4-D interferometer was carried out. The experimental results showed that the measuring accuracy of S-H is 0.008 m which could meet the requirements of Chinese SONG telescope.
-
Keywords:
- optical design /
- Shark-Hartmann /
- active support /
- contrastive measurement
-
-
［1］国家天文台.SONG 中国标准节点望远镜系统方案设计任务书[M].北京：国家天文台，2006.
National Astronomical Observatory.SONG telescope system China standard node design task book[M].Beijing: National Astronomical Observatory,2006.(in Chinese)
[2]Anton Norup Sorensen.SONG general optical layout and functions: SONG-TRE-3400-0047[M].US:[s.n], 2009.
[3]FRIED D L. Probability of getting a lucky short exposure image through turbulence[J]. Optical Society of America Journal, 1978, 68:1651-1658.
[4]CUI Xiang-qun, SU Ding-qiang, LI Guo-ping, et al. Experiment system of LAMOST active optics [J]. SPIE, 2004,5489:974-985.
[5]SU Ding-qiang, JIANG Sheng-tao, ZHOU Wei-yao, et al.Experiment system of thi-mirror active optics[J]. SPIE, 1982,2199: 609-621.
[6]SU Ding-qiang, ZOU Wei-yao, ZHANG Zhen-chao, et al.Experiment system of segmented-mirror active optics[J].SPIE, 2000,4003: 417-425.
[7]程景全. 天文望远镜原理和设计[M]. 北京:中国科学技术出版社,2003.
CHEN Jing-quan. Principles of astronomical telescope design [M]. Beijing: China Science & Technology Press, 2003.(in Chinese)
[8]易卫敏，陈东，王传军. 2-4 m望远镜曝光时间计算器的设计和实现[J].天文研究与技术，2010，7（3）：253-260.
YI Wei-min, CHEN Dong, WANG Chuan-jun. An exposure time calculator for 2.4 m telescope of the Yunnan observatory[J]. Astronomical Research & Technology, 2010, 7(3): 253-260.(in Chinese with an English abstract)
