基于扭秤的激光干涉差动测量微小冲量方法

叶继飞, 洪延姬

叶继飞, 洪延姬. 基于扭秤的激光干涉差动测量微小冲量方法[J]. 应用光学, 2013, 34(6): 990-994.
引用本文: 叶继飞, 洪延姬. 基于扭秤的激光干涉差动测量微小冲量方法[J]. 应用光学, 2013, 34(6): 990-994.
shu
YE Ji-fei, HONG Yan-ji. Laser interference differential measurement of micro impulse based on torsion balance[J]. Journal of Applied Optics, 2013, 34(6): 990-994.
Citation: YE Ji-fei, HONG Yan-ji. Laser interference differential measurement of micro impulse based on torsion balance[J]. Journal of Applied Optics, 2013, 34(6): 990-994.
shu

基于扭秤的激光干涉差动测量微小冲量方法

  • 装备学院 激光推进及其应用国家重点实验室,北京 怀柔 101416

详细信息
    通讯作者:

    叶继飞（1981-），男，吉林辽源人，博士，主要从事先进推进技术研究工作。 Email: yjf1981@163.com

  • 中图分类号: TN24

Laser interference differential measurement of micro impulse based on torsion balance

  • State Key Laboratory of Laser Propulsion &Application,Academy of Equipment,Beijing 101416,China

摘要

    摘要
  • 摘要: 基于扭秤测量冲量原理，结合激光干涉法差动测量角度的方法，提出一种基于扭秤的激光干涉差动测量微小冲量的方法。介绍系统的基本组成和测量过程，给出扭秤结构设计参数，并对系统参数进行了标定，结合设计参数与标定结果，对系统的分辨率、量程和精度进行了校核，在典型的测量环境下，对激光烧蚀靶材所形成的Ns量级微小冲量进行了测量，给出了典型的测量结果并进行分析。结果表明：所提出的基于扭秤的激光干涉差动测量微小冲量方法，系统分辨率可达10-7Ns量级，测量范围跨5个数量级，最大可以测量10-2Ns量级冲量，测量精度优于95%。
    Abstract: Based on the impulse measuring principle of torsion balance, a kind of laser interference differential method of micro impulse was advanced. The system setting and measurement procedure were introduced. The torsion balance structure design parameters were given. The calibration and verification were put forward. The system resolution, measurement range and precision were calculated. In the typical measurement condition, the micro impulse generated by the laser ablation was measured with the method, the typical result was given and analyzed. The results show that the system resolution of the method is competent for the 10-7 Ns magnitude, the measurement range covers five magnitudes, the maximum magnitude is 10-2 Ns with precision better than 95%.
    • HTML全文
    • 参考文献(1)
  • ［1］MANUEL C C. A torsional balance for the characterization of micro Newton thrusters[J]. Review of Scientific Instruments, 2003, 74(10): 289-293.
    [2]刘向阳, 范宁军, 李科杰. 微型推力器推力测试的现状及发展趋势. 测控技术, 2004, 23(5): 18-20.
    LIU Xiang-yang, FAN Ning-jun, LI Ke-ie. The state-of-the-art and development tendencies of thrust measurement for micro-thrusters[J]. Measurement ＆-Control Technology, 2004, 23(5): 18-20. (in Chinese with an English abstract)
    [3]PHIPPS C R. World-s most sensitive torsion pendulum [EB/OL].http://photonicassociates.com/Sensitive_pendulum.pdf, 2013-09-24.
    [4]PHIPPS C R, LUKE J. Micro laser plasma thrusters for small satellites [J]. SPIE, 2000, 4065: 801-809.
    [5]PHIPPS C R, LUKE J R, MARQUIS J. Diode laser-driven microthrusters: a new departure for micropropulsion[J]. AIAA Journal, 2002, 40(2):310-318.
    [6]LI Yan-chao, WANG Chun-hui .A method of measuring micro-impulse with torsion pendulum based on multi-beam laser heterodyne[J]. Chinese Physics. 2012, 21(2): 229-234.
    [7]宿非凡，姜仁志，朱亚彬. 集成扭秤放大法测量薄膜的表面张力系数[J].物理实验, 2013, 33(1):4-7.
    SU Fei-fan, JIANG Ren-zhi，ZHU Ya-bin. Measuring the surface tension coefficient of film using integrated torsion balance[J]. Physics Experimentation, 2013, 33(1): 4-7. (in Chinese with an English abstract)
    [8]LI Jing, TANG Zhi-ping．Laser micro-impulse torsion pendulum[J]．Chinese Optics Letters, 2005, 3(2): 76-79.
    [9]王广宇，洪延姬. 微冲量测量的建模误差分析[J]. 推进技术, 2009, 30(4): 509-512.
    WANG Guang-yu, HONG Yan-ji. Modeling error analysis of micro-impulse measurements [J]. Journal of Propulsion Technology, 2009, 30(4): 509-512. (in Chinese with an English abstract)
    [10]方娟，洪延姬，叶继飞，等. 激光干涉法在扭摆法测量微冲量中的应用[J]. 推进技术, 2010, 31(1): 119-122.
    FANG Juan, HONG Yan-ji, YE Ji-fei, et al. Application of laser interference in micro-impulse measurement with torsion pendulum [J]. Journal of Propulsion Technology, 2010, 31(1): 119-122. (in Chinese with an English abstract)
