船用星敏感器星点质心精确提取方法

佟帅, 李辉, 王安国

佟帅, 李辉, 王安国. 船用星敏感器星点质心精确提取方法[J]. 应用光学, 2013, 34(6): 914-919.
引用本文: 佟帅, 李辉, 王安国. 船用星敏感器星点质心精确提取方法[J]. 应用光学, 2013, 34(6): 914-919.
TONG Shuai, LI Hui, WANG An-guo. Accurate star centroid extraction for shipboard star sensor[J]. Journal of Applied Optics, 2013, 34(6): 914-919.
Citation: TONG Shuai, LI Hui, WANG An-guo. Accurate star centroid extraction for shipboard star sensor[J]. Journal of Applied Optics, 2013, 34(6): 914-919.

船用星敏感器星点质心精确提取方法

详细信息
    通讯作者:

    佟帅(1987-),男,辽宁宽甸人,博士研究生,主要从事天文导航研究。 Email: tongs05@163.com

  • 中图分类号: TN202;TP391.9

Accurate star centroid extraction for shipboard star sensor

  • 摘要: 从星空图像中提取星点质心是星敏感器工作的重要基础,针对船用星敏感器所获取的星空图像噪声情况复杂的特点,提出一种基于重心法的星点质心精确提取方法。通过块扫描的阈值分割和星象连续性的噪点剔除,引入灰度信息参考的星象提取以及重心法质心坐标计算等步骤,从星空图像中提取星点质心。对于30幅海上实拍星图实验,该方法能够100%提取出至少10颗星点,质心坐标提取精度达到1/20像素,并且可以实现对视频图像的实时处理,满足船用星敏感器的应用需求。
    Abstract: Star centroid extraction is an important basis of star sensor. As for the complicated noise condition of offshore star image, a new star extraction method based on gravity method was proposed, which included four steps: block scan threshold segmentation, noise rejection based on star continuity, star extraction considering gray information and gravity method for centroid coordinate calculation. The algorithm was proved in experiments using 30 offshore star images that it could extract at least 10 stars centroids correctly with a success rate of 100% and an accuracy of 1/20 pixel while achieving real-time processing for video. Application requirements of shipboard star sensor could be satisfied.
  • [1]刘垒, 张路, 郑辛,等 星敏感器技术研究现状及发展趋势[J]. 红外与激光工程, 2007, 36(增刊): 529-533
    LIU Lei, ZHANG Lu, ZHENG Xin, et al- Current situation and development trends of star sensor technology[J]. Infrared and Laser Engineering, 2007, 36(Sup): 529-533.(in Chinese with an English abstract)
    [2]LIEBIE C C. Accuracy performance of star tracker-a tutorial[J]. IEEE Transaction on Aerospace and Electronic Systems, 2002, 38(2): 587-599.
    [3]李德良, 阮锦. 一种适用于星敏感器的星点提取方法[J]. 激光与红外, 2009, 39(12): 1348-1350.
      LI De-liang, RUAN Jin. Method adapting to the star sensor-s star extraction[J]. Laser & Nfrared, 2009, 39(12): 1348-1350.(in Chinese with an English abstract)
    [4]刘太阳, 王仕成, 刘志国,等. 一种高噪声情况下的星点聚心算法[J]. 光电工程, 2010, 37(12): 6-10.

    LIU Tai-yang, WANG Shi-cheng, LIU Zhi-guo, et al. Star centroiding algorithm for high-noise situation[J]. Opto-Electronic Engineering, 2010, 37(12): 6-10.(in Chinese with an English abstract)
    [5]王兆魁, 张育林. 一种CCD星图星点快速定位算法[J]. 空间科学学报, 2006, 26(3): 209-214.
    WANG Zhao-kui, ZHANG Yu-lin. Algorithm for CCD star image rapid locating[J]. Chin.J.Space.Sci., 2006, 26(3): 209-214.(in Chinese with an English abstract)
    [6]李葆华, 刘国良, 刘睿,等. 天文导航中的星敏感器技术[J]. 光学精密工程,2009,17(7):1615-1620.
    LI Bao-hua, LIU Guo-liang, LIU Rui, et al. Key techniques of star sensor for celestial navigation[J], Optics and Precision Engineering, 2009, 17(7): 1615-1620.(in Chinese with an English abstract)
    [7]余成武, 郝慧, 卢欣. 基于APS 星敏感器与光纤陀螺的星光制导[J]. 红外与激光工程, 2007, 36(9): 593-596.
      YU Cheng-wu, HAO Hui, LU Xin. Stellar guidance based on APS star sensor and fiber-optic gyrol[J]. Infrared and Laser Engineering, 2007, 36(9): 593-596.(in Chinese with an English abstract)
    [8]原玉磊, 郑勇. 一种大视场星图星点提取的阈值算法[J]. 海洋测绘, 2011, 31(5): 41-43.
      YUAN Yu-lei, ZHENG Yong. Star extraction threshold algorithm for large vision field star image[J]. Hydrographic surveying and charting, 2011, 31(5): 41-43. (in Chinese with an English abstract)
    [9]LU Chun-lin.Digital image centering with the maximum likelihood method[J]. Astron.Astrophys,1993,275:349-352.
    [10]Mcaloon K J.Design considerations for imaging charge-coupled device(ICCD) star sensors[J].SPIE,1981,265:186-207.
