超短脉冲激光瞄准装置光学系统设计

谢正茂; 何俊华; 齐文博; 韦明智

超短脉冲激光瞄准装置光学系统设计

1.
中国科学院西安光学精密机械研究所,陕西西安 710119;
2.
中国科学院研究生院,北京 100049

详细信息

通讯作者:
谢正茂（1982-），男，江西赣县人, 工程师, 博士研究生，主要从事光学设计方面的研究工作。 Email: minrycn@163.com

中图分类号: TN249；TH703
计量
- 文章访问数: 2074
- HTML全文浏览量: 95
- PDF下载量: 356
- 被引次数: 0
出版历程
- 刊出日期: 2013-11-15

Optical system of collimator for ultra-short pulsed Laser

1.
Xi-an Institute of Optics and Precision Mechanics,CAS,Xi-an 710119,China;
2.
Graduate School of Chinese Academy of Sciences,Beijing 100049,China

摘要

摘要: 为了提高超短脉冲激光的瞄准精度，基于自准直原理提出瞄准装置光学系统。以670 nm光纤耦合激光器为光源,设计指示光准直、扩束光学系统，准直光的不平行度达到3.2，设计焦距为350 mm,相对孔径1/5,离轴量50 mm的主激光离轴抛物面镜，其成像质量达到衍射极限，基于准直束光学系统和离轴抛物面镜，设计可适应670 nm和800 nm两种波长的20和100的瞄准和监测成像光学系统。提出一种小孔准直的安装调试方法，以指示光进行实验验证，结果表明：设计的光学系统成像光斑均匀,其物方分辨率达到4.1 m。　
- 成像系统 /
- 超短脉冲激光 /
- 光学设计 /
- 瞄准 /
- 离轴抛物面镜
Abstract: In order to improve the collimation precision of ultra-short pulsed laser, an optical system of collimator based on auto-collimation theory was proposed. Beam spread collimation optical system providing a parallel precision of 3.2, which is illuminated by fiber coupled laser with a wavelength of 670 nm, was designed. As well as, an off-axis parabolic mirror of principal laser with the focal length of 350 mm, relative aperture of 1/5, and off-axial distance of 50 mm, was designed, and the imaging quality could reach the diffraction limit. Based on the collimating optical system and off-axial parabolic mirror, the 20 and 100 imaging systems working at wavelength of 670 nm and 800 nm synchronously were designed. An installation and alignment method based on pinhole collimation was proposed. The results of experiment illuminated by indicated light show that the image spot is even, and its resolution can reach to 4.1 m in the object space.
- imaging system /
- ultra-short pulse laser /
- optical design /
- collimation /
- off-axial parabolic mirror

HTML全文

参考文献(1)

［1］唐翠明,谷渝秋,周维民,等. 100 TW激光与等离子体相互作用中质子背向发射的能谱测量[J].强激光与粒子束,2007，19(1) :5-8.
TANG Cui-ming, GU Yu-qiu, ZHOU Wei-min, et al. Measuring energy spectra of proton generated by 100 TW laser plasma interaction at rear side of target [J].High Power Laser and Particle Beams, 2007,19(1):5-8.(in Chinese with an English abstract)
[2]王光昶,郑志坚,杨向东,等. 超短超强激光与固体靶相互作用中背表面光发射的实验研究[J]. 物理学报，2005,54（10）:4803-4807.
WANG Guang-chang , ZHENG Zhi-jian, YANG Xiang-dong, et al. Experimental study of optical emission from the rear surface in ultra-short ultra- intense laser interaction with solid targets[J]. Acta Physic Sinica, 2005,54(10）:4803-4807. (in Chinese with an English abstract)
[3]ROCCA J J , SHLYAPTSEV V, TOMASEL F G, et al. Demonstration of a discharge pumped table top soft X-ray laser[J] . Phys. Rev. Lett , 1994,73(16):2192-2195.
[4]TABAK M, HAMMER J, GLINSKY M E, et al..Ignition and high gain with ultra-powerful lasers [J]. Phys Plasmas, 1994( 5) : 1626-1634.
[5]黄小军,魏晓峰,彭翰生,等. 20TW超短脉冲激光装置的研制[J].强激光与粒子束,2003,15(12):1191-1194.
HUANG Xiao-jun, WEI Xiao-fen, PENG Han-sheng, et al. Design and characterization of 20TW Ti sapphire laser system[J]. High Power Laser and Particle Beams,2003,15(12):1191-1194. (in Chinese with an English abstract)
[6]张双根, 谷渝秋, 温贤伦，等.相对论激光固体靶作用中超热电子能谱测[J]. 光电子·激光, 2006,17(3):347-351.
ZHANG Shuang-gen , GU Yu-qiu , WEN Xian-lun, et al. A measurement of hot electron energy spectrum in relativistic laser solid target interactions [J]. Journal of Optoelectronics·Laser, 2006,17(3):347-351. (in Chinese with an English abstract)
[7]华剑飞,安维明,黄文会,等.SILEX1装置上等离子体尾场加速电子初步实验[J].高能物理与核物理,2006(Supp.I):108-110.
HUA Jian-fei, AN Wei-ming, HUANG Wen-hui, et al. A preliminary experiment of plasma electron[J].High Energy Physics and Nuclear Physics, 2006(Supp.I):108-110. (in Chinese with an English abstract)
[8]谢正茂,董晓娜,闫亚东，等.神光-Ⅲ诊断包瞄准指示器光学系统的设计与研究[J].应用光学, 2008, 29(6): 940-943.
XIE Zheng-mao,DONG Xiao-na,YAN Ya-dong, et al. Optical system design of alignment pointer for SG-Ⅲ diagnostics [J].Journal of Applied Optics, 2008,29(6): 940-943. (in Chinese with an English abstract)
[9]潘君骅.光学非球面的设计、加工与检验[M].苏州:苏州大学出版社，2004.
PAN Jun-hua. Design,manufacture and test of optical aspheric surface[M].Suzhou: Suzhou University Press, 2004. (in Chinese)
[10]迟泽英，陈文建.应用光学与光学设计基础[M].江苏：东南大学出版社，2008.
CHI Ze-ying, CHEN Wen-jiang. Applied optics and foundation of optical design[M]. Jiangsu: Southeast University Press, 2008.(in Chinese)
