斩波法在激光微能量计标定中的应用

许荣国, 黎高平, 王雷, 桑鹏, 南瑶, 孙鹏

许荣国, 黎高平, 王雷, 桑鹏, 南瑶, 孙鹏. 斩波法在激光微能量计标定中的应用[J]. 应用光学, 2013, 34(5): 837-840.
引用本文: 许荣国, 黎高平, 王雷, 桑鹏, 南瑶, 孙鹏. 斩波法在激光微能量计标定中的应用[J]. 应用光学, 2013, 34(5): 837-840.
shu
XU Rong-guo, LI Gao-ping, WANG Lei, SANG Peng, NAN Yao, SUN Peng. Application of chopper method in laser micro energy meter calibration[J]. Journal of Applied Optics, 2013, 34(5): 837-840.
Citation: XU Rong-guo, LI Gao-ping, WANG Lei, SANG Peng, NAN Yao, SUN Peng. Application of chopper method in laser micro energy meter calibration[J]. Journal of Applied Optics, 2013, 34(5): 837-840.
shu

斩波法在激光微能量计标定中的应用

  • 西安应用光学研究所,陕西 西安 710065

详细信息
    通讯作者:

    许荣国（1980-），男，陕西武功人，硕士，工程师，主要从事软件工程与光学计量工作。 Email：xrg1980@sina.com

  • 中图分类号: TN249

Application of chopper method in laser micro energy meter calibration

  • Xi-an Institute of Applied Optics,Xi-an 710065,China

摘要

    摘要
  • 摘要: 针对激光微能量测量的问题，提出一种激光微能量计标定新方法与装置。研究内容包括使用稳功率连续激光作为光源，通过基于斩波的脉冲发生器组件产生微能量的脉冲激光,分别使用脉冲宽度测量组件与功率测量组件进行采集、软件分析，计算微能量值及通过比对给出待标定能量计的修正系数,计算机自动控制。结果表明，该方法获得的脉冲激光波形稳定，脉冲宽度测量不确定度为0.08%，激光功率测量不确定度为0.25%，实现了对0.1 pJ～1 mJ的激光能量进行准确复现和传递。
    Abstract: Aiming at the problems of laser micro energy measurement, a new method and device were advanced. This device used a set of stable power continuous wave laser, a pulse laser generator based on chopping, a special data acquisition system that included a pulse width measuring module and a pulse power measuring module, and a control software that could calculate the value of micro energy and give the correction coefficient of the calibrate energy meter by means of contrast method. The experiment results show that the laser pulse generated by this device has stable waveform, pulse power and pulse width. The pulse width measurement uncertainty is 0.08%, the laser power measurement uncertainty is 0.25%. It implements accurate replication and transfer of the laser energy of 0.1 pJ~1 mJ.
    • HTML全文
    • 参考文献(1)
  • ［1］G W DAY.Metrology for the optoelectronics industry[R].USA:NIST,1998.
    [2]NPL.Measurement services of optoelectronics for NPL[R].UK:NPL,1998.
    [3]杨照金,王雷.激光功率和能量计量技术的现状与展望[J].应用光学,2004,25(3):1-4.
    YANG Zhao-jin,WANG Lei. Status and prospect of laser power and energy metrology[J]. Journal of Applied Optics,2004,25(3):1-4.(in Chinese with an English abstract)
    [4]黎高平，刘国荣，李四维，等.-高精度激光微能量校准技术研究[J].应用光学，2013，34（1）：148-151.
    LI Gao-ping, Liu Guo-rong, LI Si-wei, et al. High precision micro energy laser calibration technology[J]. Journal of Applied Optics, 2013, 34(1):148-151.(in Chinese with an English abstract)
    [5] 董小刚,李良钰,晏思贤.调Q激光自触发斩波产生纳秒脉宽单脉冲激光[J].中国激光,2007, 34(4):465-469.
    DONG Xiao-gang,LI Liang-yu,YAN Si-xian.Producing mono-pulse laser of nanosecond burst length by cutting-apart from Q-beam self-triggered[J].Chinese Journal of Lasers,2007, 34(4): 465-469.(in Chinese with an English abstract)
    [6]梁勖,游利兵,余吟山.重复率激光的单个脉冲能量检测技术[J].量子电子学报,2010,27(3):281-287.
    LIANG Xu,YOU Li-bing,YU Yin-shan.Excimer laser pulse energy detection under pulse repetition running mode[J].Chinese Journal of Quantum Electronics,2010,27(3):281-287.(in Chinese with an English abstract)
    [7]南瑶,贾选军,向世明,等.激光单脉冲时空采样器的研究[J].光学技术,2006,32(3):472-473.
       NAN Yao,JIA Xuan-jun,XIANG Shi-ming,et al.Research on the temporal spatial detector of laser parameters mesurement for single pulse[J].Optical Technique,2006,32(3):472-473.(in Chinese with an English abstract)
    [8]魏继锋,关有光,周山，等.激光脉冲宽度对长脉冲激光能量在线测量装置的影响[J].中国激光,2010,37(4):1088-1092.
       WEI Ji-feng,GUAN You-guang,ZHOU Shan,et al.Effect to online energy measurement device for long-pulse laser by laser pulse width[J].Chinese Journal of Lasers,2010,37(4):1088-1092. (in Chinese with an English abstract)
    [9]南瑶,贾选军,向世明，等.重频激光参数测试仪[J].红外与激光工程,2004,33(2):145-149.
    NAN Yao,JIA Xuan-jun,XIANG Shi-ming,et al.Excimer laser parameter test instrument[J]. Infrared and Laser Engineering,2004,33(2):145-149.(in Chinese with an English abstract)
    [10]王永成，党源之，徐抒岩，等. ICL 7667 实现步进电机高频斩波控制[J].-光学·精密工程，2008，16(11):2193-2198.
    WANG Yong-cheng, DANG Yuan-yuan, XU Shu-yan, et al. Realization of high-frequency chopping control for stepper motor based on ICL 7667[J]. Optics and Precision Engineering, 2008, 16(11): 2193-2198.(in Chinese with an English abstract)
