子孔径拼接中系统误差的修正方法

吴世霞, 田爱玲, 刘丙才, 张鹏飞

吴世霞, 田爱玲, 刘丙才, 张鹏飞. 子孔径拼接中系统误差的修正方法[J]. 应用光学, 2013, 34(4): 639-643.
引用本文: 吴世霞, 田爱玲, 刘丙才, 张鹏飞. 子孔径拼接中系统误差的修正方法[J]. 应用光学, 2013, 34(4): 639-643.
shu
WU Shi-xia, TIAN Ai-ling, LIU Bing-cai, ZHANG Peng-fei. System error correcting method in sub-aperture stitching[J]. Journal of Applied Optics, 2013, 34(4): 639-643.
Citation: WU Shi-xia, TIAN Ai-ling, LIU Bing-cai, ZHANG Peng-fei. System error correcting method in sub-aperture stitching[J]. Journal of Applied Optics, 2013, 34(4): 639-643.
shu

子孔径拼接中系统误差的修正方法

  • 1.

    西安工业大学陕西省薄膜与光学检测技术重点实验室,陕西 西安 710032;

  • 2.

    Optical Bioimaging Lab,National University of Singapore,Singapore 117574

详细信息
    通讯作者:

    吴世霞(1986-),女，河北石家庄人，硕士研究生，主要从事光学检测工作。 Email: wsx0626@126.com

  • 中图分类号: TN247;　TH744.3

System error correcting method in sub-aperture stitching

  • 1.

    Shaanxi Province Key Laboratory of Thin Films Technology and Optical Test,Xi-an Technological University,Xi-an 710032,China;

  • 2.

    Optical Bioimaging Lab,National University of Singapore,Singapore 117574,Singapore

摘要

    摘要
  • 摘要: 为了提高大口径光学元件子孔径拼接测量的检测精度，提出一种平面绝对测量技术，修正子孔径拼接过程中产生的系统误差。利用改进的三面互检法获得参考平面的面形数据，采用这些测量数据构建基于Zernike多项式的参考面面形误差修正波面，在拼接过程中运用误差修正波面对获得的子孔径测量数据进行实时修正，并与全口径直接测量结果进行对比，结果PV（peak value，PV,峰谷值）误差从0.072 1 减少到0.028 6 。结果表明该方法有效减少了参考平面系统误差对拼接测量精度的影响，提高了大口径光学元件的检测精度。
    Abstract: In order to improve the detection accuracy of the measurement of large aperture optics stitching, a simple and effective absolute measurement was proposed to amend the system error of the sub-aperture stitching measurements. Firstly, an improved three-flat test was used to obtain the surface shape data of the reference plane and the surface error wave-front based on the Zernike polynomial was established which was used to correct the error of the subaperture measurement data. Then the directly measured values were compared with the full aperture surface stitching results, and the surface error peak value(DV) was reduced from 0.072 1 to 0.028 6 . The results show that the method is effective in reducing the system error that caused by the reference plane and can effectively improve the detection accuracy of the large aperture optics stitching.
    • HTML全文
    • 参考文献(1)
  • ［1］张明意,李新南.子孔径拼接法检验大口径光学镜面精度分析[J].应用光学,2006,27(5):446-449.
    ZHANG Ming-yi, LI Xin-nan. Accuracy analysis of stitching interferometry for test of large-diameter mirror[J]. Journal of Applied Optics, 2006,27(5):446-449.(in Chinese  with an English abstract)

    [2]刘智颖,张磊,胡原,等.子孔径拼接技术应用的研究[J].应用光学,2008,29(6):1009-1012.
    LIU Zhi-Ying, ZHANG Lei, HU Yuan, et al. Application of sub-aperture stitching technique[J]. Journal of Applied Optics, 2008,29(6):1009-1012. (in Chinese  with an English abstract)
    [3]XU C, CHEN L, YIN J. Method for absolute flatness measurement of optical surfaces[J]. Applied Optics, 2009, 48(13): 2536-2541.
    [4]张明意，李新南. 子孔径拼接检验法中倾斜的影响及消除方法[J]. 光电工程, 2006,33(8):117-122.
    ZHANG Ming-yi, LI Xin-nan. Influence of tilt in stitching interferometry and how to eliminate it [J]. OptoElectronic Engineering,2006,33(8):117-122.(in Chinese  with an English abstract)
    [5]GRIESMANN U, WANG Q, SOONS J. Three-flat tests including mounting-induced deformations[J]. Optical Engineering, 2007, 46(9): 093601-15.
    [6] 徐晨,陈磊.光学平面绝对检验方法的研究[J].光学技术,2006,32(5):775-778.
    XU Chen, CHEN Lei. Absolute flatness measurement of optical surfaces[J].Optical Technique,2006,32(5):775-778.(in Chinese  with an English abstract)
    [7]VANNONI M, MOLESINI G. Iterative algorithm for three flat test[J]. Optics Express, 2007, 15(11): 6809-6816.
    [8]赵华伟,王军.一种用于光学平面面形误差绝对测量的新方法[J].应用光学,1991,12（2）:53-55.
    ZHAO Hua-wei, WANG Jun. A new method of absolutely measuring the surface shape error of optical plane[J]. Journal of Applied Optics, 1991,12(2): 53-55.(in Chinese  with an English abstract)
    [9] GRIESMANN U. Three-flat test solutions based on simple mirror symmetry[J]. Applied optics, 2006, 45(23): 5856-5865.
    [10]田爱玲,郑显锋,刘丙才,等.三维面型的绝对测量[J].西安工业大学学报,2012,32(6):431-436.
    TIAN Ai-ling, ZHENG Xian-feng, LIU Bing-cai,et al. Absolute measurement of 3D surface.[J].Journal of Xi-an Technological University , 2012,32 (6):431-436.(in Chinese  with an English abstract)
