新型光谱可调定标光源系统准直物镜设计

翟文超; 徐骏; 丁蕾; 郑小兵

新型光谱可调定标光源系统准直物镜设计

中国科学院安徽光学精密机械研究所光学遥感中心,安徽合肥 230031

详细信息

通讯作者:
翟文超（1985-），男，河南焦作人，博士研究生，主要从事光学辐射定标研究。 Email:wczhai@aiofm.ac.cn

中图分类号: TN202；TH703
计量
- 文章访问数: 2523
- HTML全文浏览量: 119
- PDF下载量: 455
出版历程
- 刊出日期: 2013-07-14

Collimator design for novel spectral tunable calibration source system

Optical Center of Remote Sensing,Anhui Institute of Optics and Fine Mechanics,CAS,Hefei 230031,China

摘要

摘要: 高精度光谱可调定标光源系统是针对高光谱遥感器的高精度定标提出的一种新型参考光源，设计了一个折射式宽谱段大相对孔径的准直物镜。镜头工作在400 nm~1 000 nm波段，半视场角2.2、相对孔径F/2.8、焦距135 mm。利用部分色散（P）和阿贝数（）的修正公式，基于复消像差的基本原理，获得了镜头的初始结构。借助Zemax光学设计软件进行优化设计，点校正了系统的二级光谱。最后，在设计波段上实现了复消色差，二级光谱残余量约为0.04 mm，其他像差也得到了良好的平衡。镜头的MTFs在37 lp/mm空间频率处均大于0.8，镜头整体性能满足设计指标。
- 宽谱段 /
- 复消色差 /
- 二级光谱 /
- 光学设计 /
- 高光谱遥感
Abstract: High accuracy spectral tunable calibration light source is a novel calibration light source, which especially accounts for the stringent calibration requirements of hyper-spectral remote sensors. A broadband and large aperture apochromatic collimator was designed. The lens worked in band of 400~1 000 nm, half field of view was 2.2, relative aperture F was 2.8, and focal length was 135 mm. According to the corrected formula of parial dispersion (P) and Abbe number (), the original optical structure was acquired, based on the principles of apochromatic lens design. The secondary spectrum was corrected well with the help of Zemax software. At last, the lens was apochromatic in the whole working band with secondary spectrum residual of about 0.04 mm, and other aberrations are balanced well. The Lens's MTFs are better than 0.8 at spatial frequency of 37 lp/mm, which meet the requirements of the light source system.
- broadband /
- apochromatism /
- secondary spectrum /
- optical design /
- hyper-spectral remote sensing

HTML全文

参考文献(1)

［1］

DUDLEY D, DUNCAN W, SLAUGHTER J.Emerging digital micromirror device (DMD) applications[J]. SPIE, 2003, 4985:14-25.
[2]陈风, 郑小兵. 光谱非匹配对光学遥感器定标精度的影响[J]. 光学精密工程, 2008, 16(3): 415-419.
CHEN Feng, ZHENG Xiao-bing.Influence of spectrum not-matching on calibration precision of remote sensor[J]. Optics and Precision Engineering,2008,16(3): 415-419. (in Chinese with an English abstract).
[3]郑小兵, 袁银麟，徐秋云，等. 辐射定标的新型参考光源技术[J]. 应用光学, 2012,33(1): 101-107.
ZHENG Xiao-bing,YUAN Yin-lin, XU Qiu-yun,et al. New reference sources for radiometric calibration[J]. Journal of Applied Optics, 2003, 33(1):101-107. (in Chinese with an English abstract).
[4]BROWN S W, RICE J P, NEIRA J E, et al.. Spectrally tunable sources for advanced radiometric applications[J]. Journal of Research of the National Institute of Standards and Technology, 2006, 111: 401-410.
[5]BROWN S W, SAUNDERS R D, LI Zhi-gang, et al. An absolute detector-based spectral radiance source[J]. SPIE, 2010, 7807:78070A-1-78070A -8.
[6]计卓馨, 刘智颖, 付跃刚. 超光谱成像光学设计[J]. 应用光学, 2012,33(1): 26-29.
JI Zhuo-xin, LIU Zhi-ying, FU Yue-gang.Optical design of hyperspectral imager[J]. Journal of Applied Optics,2012, 33(1): 26-29.(in Chinese with an English abstract)
[7]赵葆常，杨建峰，陈立武，等. 干涉成像光谱仪中宽谱段傅氏光学系统设计[J]. 光子学报, 2009, 38(3): 468-473.
ZHAO Bao-chang, YANG Jian-feng, CHEN Li-wu, et al. Design of the wide bands Fourier lens[J]. Acta Photonica Sinica, 2009,38(3): 468-473. (in Chinese with an English abstract).
[8]FISCHER R E, GRANT A J. Removing the mystique of glass selection[J]. SPIE, 2004, 5524: 134-146.
[9]王美钦, 王忠厚, 白加光. 宽谱段光学系统消二级光谱的设计[J]. 应用光学, 2010, 31(3): 360-364.
WANG Mei-qin, WANG Zhong-hou, BAI Jia-guang, et al. Removing secondary spectrum in wide spectrum optical system[J].Journal of Applied Optics, 2010, 31(3): 360-364. (in Chinese with an English abstract).
[10]SHANNON R R. The art and science of optical design[M]. New York: Cambridge University Press, 1997.
[11]陈立武, 杨建峰, 洪新华, 等.宽谱段折射式长焦光学镜头[J]. 光子学报，2004, 33(9): 1123-1126.
CHEN Li-wu, YANG Jian-feng, HONG Xin-hua, et al. Wide bands long focal refracting lens[J].Acta Photonica Sinica, 2004, 33(9): 1123-1126.(in Chinese with an English abstract).
[12]GRUESCU C, NICOARA I, POPOV D, et al.. Optical glass compatibility for the design of apochromatic systems[J]. Science of Sintering,2008, 40: 131-140.
