非球面光学反射镜的装调方法

李小燕; 付兴; 王鹏; 段学霆

非球面光学反射镜的装调方法

1.
中科院西安光学精密机械研究所,陕西西安 710119

详细信息

通讯作者:
李小燕（1986-），女,陕西宝鸡人，助理工程师，主要从事光学装调与测试方面的研究。 Email:Lixy0609@163.com

中图分类号: TN206
计量
- 文章访问数: 2750
- HTML全文浏览量: 132
- PDF下载量: 521
- 被引次数: 0
出版历程
- 刊出日期: 2013-05-15

Alignment method of aspheric optical reflector

1.
Xi-an Institute of Optics and Precision Mechanics,CAS,Xi-an 710119,China

摘要

摘要: 针对通过胶粘固定的口径为230 mm非球面反射镜的装调要求，选用无像差面型检测法，通过对3个关键过程，即底板与裸镜的粘接，镜框与底板的连接，光学定心加工的实验研究，提出使粘接应力及结构件传导应力变化量达到最小的微应力装校方法，并通过光学定心加工标定出非球面反射镜的光学中心。装调结果表明：对于口径为230 mm的非球面反射镜，微应力装调后面型精度0.02；光学中心偏心量5 m，分划板表面与光轴垂直度误差2.5。
- 非球面反射镜 /
- 微应力装调 /
- 胶粘 /
- 光学定心
Abstract: According to the alignment demand of aspheric mirror with aperture of 230 mm, using the aberrationless surface figure test method, based on the three key processes of experimental research (bonding between the bottom plate and bare mirror; connection of the frame and the bottom plate; calibration of optical center), micro-stress alignment method that could get the minimum variation of the adhesive stress and conduction stress of structure was put forward, and aspheric mirror optical center was calibrated through the optical alignment. Alignment results show that surface shape error of the aspheric mirror with aperture of 230 mm is less than or equal to 0.02, optical center offset is less than or equal to 5 m, the plate was calibrated and the optical axis perpendicularity error is less than or equal to 2.5.
- aspheric mirror /
- micro-stress alignment /
- viscose /
- calibration of optical center

HTML全文

参考文献(1)

［1］陈晓丽，傅丹鹰.大口径甚高分辨率空间光学遥感器技术途径探讨［J］.航天返回与遥感，2003,24（4）：19-24
CHEN Xiao-li，FU Dan-ying. Solutions for space optical remote sensor with large aperture and ultrahigh resolution ［J］. Spacecraft Recovery & Remote Sensing，2003,24（4）：19-24. (in Chinese with an English abstract)
［2］刘磊，李景林，吕清涛.大口径反射光学系统装调装置设计研究［J］.光学精密工程，2005，13（z1）:134-137.
LIU Lei，LI Jing-lin，LvQing-tao. Research on adjusting device of large aperture reflective optics system［J］.Optics and Precision Engineering，2005,13（z1）:134-137. (in Chinese with an English abstract)
［3］李旭阳，李英才，马臻.折轴三反射光学系统的计算机辅助装调技术［J］．应用光学，2009,30（6）:901-906.
LI Xu-yang，LI Ying-cai，MA Zhen.Computer-aided alignment method of coaxial three-mirror-anastigamat system［J］.Journal of Applied Optics，2009,30（6）:901-906. (in Chinese with an English abstract)
［4］潘君骅.光学非球面的设计、加工与检测［M］.苏州：苏州大学出版社，2004.
PAN Jun-hua. The design manufacture and test of the aspherical optical surface［M］．Suzhou:Suzhou University Press,2004. (in Chinese)
［5］CLEMENTS A. Selection of optical adhesives［M］.USA: University of Arizona,2006.
［6］YODER P R. Opto-mechanical system design［M］.3rd. LLC:Talor &Francis Group,2006.
［7］LI Yan, HU Yong-ming, LI Ying-cai.Analysis of bonding stress with high strength adhesive between the reflector and the mounts in space camera ［J］.SPIE, 2010,7654:76541F-1.
［8］樊学武，陈荣利，马-臻．偏心和倾斜光学系统初级像差理论的研究［J］.光子学报，2004, 33（4）：494-496.FAN Xue-wu, CHEN Rong-li, MA Zhen. A study on the primary aberration theory of decentered and tilted optical system［J］. Acta Photonica Sinica, 2004, 33（4）：494-496. (in Chinese with an English abstract)
［9］韩娟，段嘉友，张钧.大口径非球面反射镜的装调方法研究［J］．应用光学，2012，33(3)：490-495.
HAN Juan，DUAN Ja-you，ZHANG Jun.Alignment method for large aperture aspheric mirror［J］．Journal of Applied Optics, 2012,33(3)：490-495.(in Chinese with an English abstract)
