光学材料光学不均匀性绝对测量误差分析

李强; 刘昂; 高波; 徐凯源; 柴立群

光学材料光学不均匀性绝对测量误差分析

1.
成都精密光学工程研究中心,四川成都 610041

详细信息

通讯作者:
李强 (1979-)，男，四川达州人，助理研究员，主要从事光学检测方面的研究工作 Email:ocean_leon@126.com

中图分类号: TN29;O436.1
计量
- 文章访问数: 2796
- HTML全文浏览量: 134
- PDF下载量: 421
- 被引次数: 0
出版历程
- 刊出日期: 2013-05-15

Error analysis of absolute test method of inhomogeneity of optical materials

1.
Fine Optical Engineering Research Center,Chengdu 610041,China

摘要

摘要: 绝对测量技术去除了干涉仪参考面面形误差，可实现光学材料光学不均匀性的高精度测量。对现有主要光学材料光学不均匀性绝对检测技术进行了总结比较，针对像素错位、干涉图分辨率、干涉仪测量重复性、样品厚度以及折射率测量等因素对光学不均匀性绝对检测的影响进行了实验分析。实验结果表明：干涉仪重复性是光学不均匀性测量的主要误差。样品翻转测量法、样品直接透射测量法、平行平板样品测量法3种测量方法均可实现光学不均匀性（RMS）10-8检测精度。
- 测量 /
- 光学不均匀性 /
- 绝对检测 /
- 误差分析
Abstract: Absolute test eliminates the surface errors of reference plane of interferometer, so that the inhomogeneity of optical materials can be measured with high accuracy. A brief review and comparison of several mainstream absolute test methods for inhomogeneity of optical material were given. And influence of the factors, such as the pixel offset, resolution of interference pattern, repetition of interferometer, the sample thickness and the refractive index measurement, etc, on the measurement error of absolute test was analyzed respectively. Experimental results indicate that the measuring accuracy of window-flipping method, transmission method and parallel flat method can reach 10-8 respectively. Repetition of interferometer is the main error in absolute test method of the inhomogeneity of optical materials.
- measurement /
- optical inhomogeneity /
- absolute test /
- error analysis

HTML全文

参考文献(1)

［1］CHIAYU A, JAMES C W. Measurement of the inhomogeneity of a window［J］. Opt.Eng.,1991,30(9): 1399-1403.
［2］郭培基,余景池,丁泽钊,等. 光学玻璃光学均匀性的绝对测量技术［J］. 激光杂志, 2003,24(3)：26-27.
GUO Pei-ji, YU Jing-chi, DING Zhe-zhao, et al. Absolute testing method of the homogeneity of optical glass［J］. Laser Journal, 2003,24(3):26-27. (in Chinese with an English abstract)
［3］郭培基，余景池，丁泽钊,等. 高精度光学玻璃光学均匀性测量仪研制［J］.激光杂志，2004，25(3):36-38.
GUO Pei-ji, YU Jing-chi, DING Zhe-zhao, et al. A high accuracy instrument of testing the homogeneity of optical glass［J］. Laser Journal,2004,25(3):36-38.(in Chinese with an English abstract)
［4］任寰，袁静，许华,等. 光学材料光学均匀性检测方法分析［J］. 光学与光电技术，2007，6(5)：48-51.
REN Huan, YUAN Jing, XU Hua, et al. Optical homogeneity measure method analysis of optical material［J］. Optics & Optoectronic Technology,2007,6(5):48-51.(in Chinese with an English abstract)
［5］郭培基，余景池，丁泽钊,等. 光学玻璃光学均匀性高精度测量技术［J］. 光学技术，2001，27(6)：528-531.
GUO Pei-ji, YU Jing-chi, DING Zhe-zhao, et al. High accuracy testing method of the homogeneity of optical glass［J］. Optical Technique, 2001,27(6):528-531.(in Chinese with an English abstract)
［6］宋波. 大尺寸石英玻璃光学均匀性的测量［J］. 中国建材科技，2006(1)：35-36.
SONG Bo. Measurement of optical homogeneity of large-sized quartz glass［J］. China Building Materials Science & Technology, 2006(1):35-36.(in Chinese with an English abstract)
［7］宋宝安，王乔方，张莹昭,等. 红外硒基硫系玻璃光学非均匀性及影响因素分析［J］. 红外与激光工程，2012，8(41)：1985-1988.
SONG Bao-an, WANG Qiao-fang, ZhANG Ying-zhao, et al. Optical inhomogeneity of IR Se-based chalcogenide glasses and influencing factor analysis［J］. Infrared and Laser Engineering, 2012,8(41):1985-1988.(in Chinese with an English abstract)
［8］林娟.大口径光学玻璃光学均匀性干涉绝对测量方法［J］.应用光学，2008，29(1):121-123.
LIN Juan.Interference absolute measurement for homogeneity of large-aperture optical glass［J］. Journal of Applied Optics, 2008, 29(1):121-123.(in Chinese with an English abstract)
［9］张建锋，曹学东, 景洪伟,等.基于旋转法的干涉仪系统误差标定［J］.光电工程，2011，38(12):71-73.
ZHANG Jian-feng, CAO Xue-dong, JING Hong-wei, et al. Rotation method for system error calibration of interferometer［J］. Opto-Electronic Engineering, 2011,38(12):71-73.(in Chinese with an English abstract)
［10］杨鹏，伍凡，侯溪. 旋转非对称项面形误差绝对检测的仿真分析［J］.光电工程，2011,38(1):93-102.
YANG Peng, WU Fan, HOU Xi. Simulation analysis of absolute measurement for rotationally asymmetric surface error［J］. Opto-Electronic Engineering, 2011,38(1):93-102.(in Chinese with an English abstract)
