弹光调制光电转换放大电路设计

黄艳飞, 王志斌, 王艳超, 赵冬娥, 张瑞, 王耀利

黄艳飞, 王志斌, 王艳超, 赵冬娥, 张瑞, 王耀利. 弹光调制光电转换放大电路设计[J]. 应用光学, 2013, 34(3): 420-424.
引用本文: 黄艳飞, 王志斌, 王艳超, 赵冬娥, 张瑞, 王耀利. 弹光调制光电转换放大电路设计[J]. 应用光学, 2013, 34(3): 420-424.
shu
HUANG Yan-fei, WANG Zhi-bin, WANG Yan-chao, ZHAO Dong-e, ZHANG Rui, WANG Yao-li. Photoelectric conversion and amplifying circuit for photoelasticmodulated interferometer[J]. Journal of Applied Optics, 2013, 34(3): 420-424.
Citation: HUANG Yan-fei, WANG Zhi-bin, WANG Yan-chao, ZHAO Dong-e, ZHANG Rui, WANG Yao-li. Photoelectric conversion and amplifying circuit for photoelasticmodulated interferometer[J]. Journal of Applied Optics, 2013, 34(3): 420-424.
shu

弹光调制光电转换放大电路设计

  • 1.

    中北大学 山西省光电信息与仪器工程技术研究中心,山西 太原 030051;

  • 2.

    中北大学 仪器科学与动态测试教育部重点实验室,山西 太原 030051

详细信息
    通讯作者:

    黄艳飞（1989-），男，河南驻马店人，硕士研究生，主要从事光电检测技术研究。 Email：huang_yanfei@126.com

  • 中图分类号: TN247

Photoelectric conversion and amplifying circuit for photoelasticmodulated interferometer

  • 1.

    Engineering Technology Research Center of Shanxi Province for OptoElectronic Information and Instrument,North University of China,Taiyuan 030051,China;

  • 2.

    Key Laboratory of Instrumentation Science &Dynamic Measurement,Ministry of Education,North University of China,Taiyuan 030051,China

摘要

    摘要
  • 摘要: 弹光调制干涉具调制的干涉光被探测器接收后输出高速变化的微弱电信号，能否将该电信号提取并放大输出对弹光调制-傅里叶变换光谱仪的研制至关重要。通过对调制干涉光进行理论分析，设计一种具有高信噪比和较高带宽的光电转换放大电路，主要由电源电路、光电转换电路、放大电路、理论通频带为100 kHz~3.5 MHz的带通滤波电路组成。实验结果表明：设计的电路能够将探测器输出的最大频率为1.6 MHz的信号放大至670 mV左右，实现了将探测器输出的微弱速变电信号从背景噪声中有效提取与放大，为后续傅里叶变换提供可靠数据。
    Abstract: The output of detector which receives the interference light that is modulated by photoelastic modulated interferometer is weak electric signal that is of rapid change. Extracting and amplifying this electric signal is crucial to the development of the photoelastic modulator-Fourier transform spectrometer. A photoelectric conversion amplifying circuit with high signal-to-noise ratio and high bandwidth was designed through analyzing the interference light. The circuit consists of power circuit, photoelectric conversion circuit, amplifying circuit and the band-pass filter circuit with the theoretical pass band of 100 kHz ~ 3.5 MHz. The test results indicate that the circuit can amplify the signal from the detector whose maximum frequency is 1.6 MHz to about 670 mV, extract and amplify the output signal effectively from the background noise, and provides reliable data to the subsequent Fourier transform.
    • HTML全文
    • 参考文献(1)
  • ［1］BUICAN T N, CARRIERI A H. Ultra-high speed solid-state FTIR spectroscopy and applications for chemical defense［C］//Proceedings for the Army Science Conference (24th),  2004. USA:Semiotic Engineering Associates LLC Albuquerque NM,2004.
    ［2］BUICAN T N. High retardation-amplitude photoelastic modulator: US,7764415, B2［P］. 2010-7-28.
    ［3］伯广宇,戚俊,李季,等.一种基于宽带低噪声THS4012运放的激光测高仪前置放大电路设计与实现［J］.大气与环境光学学报,2007,2(4):316-320.
    BO Guang-yu, QI Jun, LI Ji,et al.. Design method of preamplifier circuit with THS4012 in laser altimeter［J］.Journal of Atmospheric and Environmental Optics,2007,2(4):316-320.(in Chinese with an English abstract)
    ［4］BUICAN T N. Controlling resonant photoelastic modulators:US,6970271［P］.2005-03-01.
    ［5］张跃国.基于弹光效应的静态傅里叶变换干涉具设计［D］.太原:中北大学,2011.
    ZHANG Yue-guo. Design of static FTIR interferometer with photoelastic-effect［D］. Taiyuan:North University of China,2011. (in Chinese)
    ［6］景宁,王志斌,张记龙,等.弹光调制非线性光程差干涉信号的快速反演［J］.激光技术,2012,36(2):271-274.
    JING Ning, WANG Zhi-bin, ZHANG Ji-long, et al. Fast  spectrum recovery of nonlinear optical path difference interferogram in photoelastic modulator［J］. Laser Technology,2012,36(2):271-274. (in Chinese with an English abstract)
    ［7］龚涵,陈浩宇.微弱光信号检测电路的设计与实现［J］.科技信息,2007(27):85-87.
       GONG Han, CHEN Hao-yu.The design and  realization of an optic electric detecting circuit for weak signal［J］. Science & Technology Information,2007(27):85-87. (in Chinese with an English abstract)
    ［8］李常青.梅欣丽,明奇.微弱光信号检测电路的实现［J］.应用光学,2010,31(5):724-727.
        LI Chang-qing,  MEI Xin-li,  MING Qi. Implementation of weak optical signal detection circuit［J］.Journal of Applied Optics,2010,31(5):724-727. (in Chinese with an English abstract)
    ［9］胡涛,司汉英.光电探测器前置放大电路设计与研究［J］.光电技术应用,2010,25(1):52-55.
    HU Tao, SI Han-ying.Design and research of pre-amplifier circuit from a photoelectric detector［J］.Electro-Optic Technology Application,2010, 25(1):52-55. (in Chinese with an English abstract)
    ［10］JOHNSON D E,HILBURN J L.有源滤波器的快速实用设计［M］.薄秋明 译.北京:人民邮电出版社,1980.
    JOHNSON D E,HILBURN J L. Rapid practical designs of active filters［M］. Translated by BO Qiu-ming. Beijing:Posts & Telecom Press,1980. (in Chinese)
    ［11］张国雄.测控电路［M］.北京:机械工业出版社,2008.
    ZHANG Guo-xiong. Measurement and control circuit［M］. Beijing:China Machine Press,2008. (in Chinese)
