中波红外制冷型光学系统消热差设计

刘秀军; 张金旺; 张华卫; 刘波

中波红外制冷型光学系统消热差设计

1.
四川长虹电子科技有限公司,四川绵阳 621000

详细信息

通讯作者:
刘秀军（1980-），男，黑龙江绥棱人，硕士，工程师，主要从事红外光学系统设计及整机评价方面的工作。 Email: xiujunliu@126.com

中图分类号: TN216;TH703
计量
- 文章访问数: 4073
- HTML全文浏览量: 178
- PDF下载量: 441
- 被引次数: 0
出版历程
- 刊出日期: 2013-05-15

Athermal design of cooled MWIR optical system

1.
Sichuan Changhong Electronics Technology Development Co.,Ltd,Mianyang 621000,China

摘要

摘要: 对比了典型消热差方法的优劣，探讨光学被动式消热差的基本理论。在此基础上，根据系统要求的温度范围 60℃～90℃，在常温初始结构的基础上，利用Zemax软件的多重结构和自动热分析功能增加其他温度结构，运用光学被动式消热差方法进行热平衡和像差平衡，最终设计出一套中波制冷型消热差光学系统。光学设计时以探测器冷阑作为系统孔径光阑，实现了100%冷阑匹配。结构材料使用铝，光学材料为硅、锗和硒化锌,将它们组合消热差。系统在-60℃～90℃温度范围内，最大离焦量小于1倍焦深，空间分辨率17 lp/mm处，光学调制传递函数(MTF)值均大于0.74，接近衍射极限，点列图弥散斑均未超出单像元尺寸范围。
- 中波红外 /
- 消热差设计 /
- 冷阑匹配 /
- 光学被动式
Abstract: The pros and cons of the typical methods of athermal design were compared, and the basic theory of optical passive athermalization was discussed. According to the system requirement temperature range of -60℃ ~ 90℃, based on initial structure in normal temperature, using multi-configuration and automatic thermal analysis function, other temperature structures were added in Zemax software, then thermal and aberration were optimized. Finally a cooled medium wave infrared optical system was designed by using the optical passive athermalization. Detector cold-shield stop was used as system aperture stop, so this optical system could realize a 100% cold-shield-match. Optical materials were Si, Ge and ZnSe, and structure material was Al in the optical system. The MTF value is greater than 0.74, which is close to diffraction limit at the spatial resolution of 17 lp/mm, and the RMS spot diameter is less than single pixel size within -60℃～90℃. Those results show that the optical system has good image quality and athermal effect.
- MWIR /
- athermal design /
- cold-shield-match /
- optical passive mode

HTML全文

参考文献(1)

［1］孟庆超，潘国庆，张运强，等.红外光学系统的无热化设计［J］.红外与激光工程,2008,37(增刊):723-727.
MENG Qing-chao,PAN Guo-qing,ZHANG Yun-qiang,et al. Design of athermalizing infrared optical system［J］.Infrared and Laser Engineering, 2008,37(Sup):723-727.（in Chinese with an English abstract）
［2］顿雄,孟军合,张振.被动无热化切换式长波红外双视场望远镜［J］.应用光学,2011,32(4):767-772.
DUN Xiong,MENG Jun-he,ZHANG Zhen.Athermalised dual FOV LWIR telecope［J］.Journal of Applied Optics, 2011,32(4):767-772. （in Chinese with an English abstract）
［3］陈德富,李相军,朱敏.一种红外镜头的被动式无热补偿设计［J］.光电技术应用,2011,26(3):21-23.
CHEN De-fu,LI Xiang-jun,ZHU Min.Design of passive athermal compensation of infrared lens［J］.Electro-optic Technology Application, 2011,26(3):21-23. （in Chinese with an English abstract）
［4］邓健,童卫红,安晓强,等.双视场红外变焦镜头的无热化研究［J］.应用光学,2011,32(1):133-137.
DENG Jian,TONG Wei-hong,AN Xiao-qiang,et al.Athermalization of infrared zoom system［J］. Journal of Applied Optics, 2011,32(1):133-137. （in Chinese with an English abstract）
［5］林福跳,刘朝晖.中波红外折衍射光学系统消热差设计与杂散光分析［J］.应用光学,2010,31(5):833-837.
LIN Fu-tiao,LIU Chao-hui.MWIR refractive/diffractive hybrid athermal optical system and its stray light analysis［J］. Journal of Applied Optics, 2010,31(5):833-837. （in Chinese with an English abstract）
［6］POVEY V.Athermalisation techniques in infrared systems［J］.SPIE,1986,655:142-153.
［7］陈吕吉,冯生荣.一种紧凑的红外消热差光学系统［J］.红外技术,2007,29(4):203-205.
CHEN Lü-ji,FENG Sheng-rong.A Compact athermalizing infrared optical system［J］.Infrared Technology,2007,29(4):203-205. （in Chinese with an English abstract）
［8］杨长城,李升辉.中波红外光学系统无热化设计［J］.光学与光电技术,2006,4(6):28-31.
YANG Chang-cheng,LI Sheng-hui. Athermalization of MWIR optical system［J］.Optics & Optoelectronic Technology, 2006,4(6):28-31. （in Chinese with an English abstract）
［9］王学新,焦明印.红外光学系统无热化设计方法的研究［J］.应用光学,2009,30(1):129-133.
WANG Xue-xin,JIAO Ming-yin.Athermalization design for infrared optical systems［J］. Journal

of Applied Optics, 2009,30(1):129-133.（in Chinese with an English abstract）
［10］FISCHER R E.红外系统的光学设计［J］.云光技术,2000,32(6):6-20.
FISCHER R E.Infrared system of optical design［J］.Yunguang Technology, 2000,32(6):6-20. （in Chinese with an English abstract）
［11］李华,韩维强,沈忙作.中波红外光学系统被动无热化设计及测试［J］.红外与激光工程,2009,38(4):687-691.
LI Hua,HAN Wei-qiang,SHEN Mang-zuo.Passive athermal design and measurement of MWIR optical system［J］. Infrared and Laser Engineering, 2009,38(4):687-691. （in Chinese with an English abstract）
