基于外调制器的全双工无线信号光传输系统

李辉; 赵强; 李蕾; 黄威; 郭佳; 梁栋

基于外调制器的全双工无线信号光传输系统

李辉^1,2, ,,
赵强²,
李蕾²,
黄威²,
郭佳¹,
梁栋²

1.
西安应用光学研究所,陕西西安 710065;
2.
西安电子科技大学通信工程学院,陕西西安 710071

详细信息

通讯作者:
李辉（1988-），男，陕西渭南人，硕士研究生，主要从事光电信号研究工作。 Email: li_hui_tong_zhi@163.com

中图分类号: TN929.1
计量
- 文章访问数: 2273
- HTML全文浏览量: 84
- PDF下载量: 383
- 被引次数: 0
出版历程
- 刊出日期: 2013-03-15

Full-duplex wireless signal optical transmission system basedon external modulator

LI Hui^{1,2
, ,},
ZHAO Qiang²,
LI Lei²,
HUANG Wei²,
GUO Jia¹,
LIANG Dong²

1.
Xi-an Institute of Applied Optics,Xi-an 710065,China;
2.
Department of Communication Engineering,Xidian University,Xi-an 710071,China

摘要

摘要: 提出了一种基于双平行马赫增德尔调制器的全双工矢量信号传输系统。传统的光学倍频技术只适用于NRZ (not return to zero) 等强度调制格式，而不适用于无线通信中常用的MPSK、MQAM等矢量信号调制技术，用传统的倍频技术生成光毫米波后，用滤波器将其2个边带分开，在其中一个边带上调制矢量信号，这样幅度和相位信息被正确保留，且使用了8倍频模块，降低了传输过程中对光电器件的带宽要求。理论分析和仿真结果表明：通过此方法产生的携带在60 GHz载波上的625Msymbol/s的4QPSK信号，经过20 km单模光纤传输后，误差向量幅度损耗可以忽略不计。
- 光载射频通信 /
- 光生毫米波 /
- 矢量信号调制 /
- 双平行马赫增德尔调制器
Abstract: A full duplex vector signal transmission system based on double parallel Mach-Zehnder modulator was proposed. Traditional optical frequency doubling technology was only suitable for NRZ (not return to zero) that was intensity modulation format and not suitable for MPSK and MQAM vector signal modulation technique in wireless communication. Two sides of optical millimeter wave generated by the traditional multiplier were separated with a filter, and vector signal was modulated in a sideband so that the amplitude information and phase information were properly retained. Bandwidth requirements of optoelectronic device were reduced by using octonary module in the transmission process. Theoretical analysis and simulation results show that after 20 km single-mode optical fiber transmission, the error vector magnitude loss of 625-Msymbol/s 4QPSK signal generated by this method and carried in the carrier of 60 GHz can be neglected.
- optical carrier RF communication /
- photo-generated millimeter-wave /
- vector signal modulation /
- double parallel Mach-Zehnder modulator

HTML全文

参考文献(1)

［1］MA J, YU J, YU C, et al. Transmission performance of the optical mm-wave generated by double sideband intensity-modulation［J］. Optics Communications, 2007, 280(2): 317-326.
［2］YU J, JIA Z, WANG T, et al. Centralized lightwave radio-over-fiber system with photonic frequency quadrupling for high-frequency millimeter-wave generation［J］. IEEE Photonics Technology Letters, 2007, 19(19): 1499-1501.
［3］GOMES N J, MORANT M, ALPHONES A, et al. Radio over fiber transport for the support of wireless broadband services［J］. Journal of Optical Networking, 2009, 8(2): 156-178.
［4］SHIH P T, LIN C T, JIANG W J, et al. Full duplex 60-GHz RoF link employing tandem single sideband modulation scheme and high spectral efficiency modulation format［J］. Optics Express, 2009, 17(22): 19501-19508.
［5］MOHAMED M, ZHANG X. Frequency sixupler for millimeter-wave over fiber systems［J］. Optics Express, 2008, 16(14): 10141-10151.
［6］张芳，高教波，王军，等. 光纤光谱仪绝对光谱辐射定标新技术［J］. 应用光学, 2011, 32(1): 101-105.
ZHANG Fang, GAO Jiao-bo, WANG Jun, et al. Fiber optic spectrometer absolute spectral radiometric calibration of the new technology［J］. Journal of Applied Optics, 2011, 32(1): 101-105. (in Chinese with an English abstract)
［7］袁燕，秦毅. 基于串联双电极马赫曾德尔调制器的六倍频技术［J］. 中国激光, 2011, 38(10): 1004-1005.
YUAN Yan, QIN Yi. Frequency sextupling technique using two cascaded dual-electrode Mach-Zehnder modulators［J］. Chinese Journal of Lasers, 2011, 38(10): 1004-1005. (in Chinese with an English abstract)
［8］徐刚，郑小平，张汉一. 基于四倍频技术的单边带光载毫米波上变频［J］. 光学学报, 2010, 30(12): 3386-3390.
XU Gang, ZHENG Xiao-ping, ZHANG Han-yi. Frequency quadrupling for single-sideband optical millimeter-wave up conversion［J］. Acta Optica Sinica, 2010, 30(12): 3386-3390. (in Chinese with an English abstract)
［9］朱子行，赵尚弘，幺周石，等. 一种克服色度色散影响的四倍频光毫米波信号产生方法［J］. 中国激光, 2012, 39(4): 405-406.
ZHU Zi-hang, ZHAO Shang-hong, YAO Zhou-shi, et al. Generation of frequency quadruple optical millimeter-wave signal to overcome chromatic dispersion［J］. Chinese Journal of Lasers, 2012, 39(4): 405-406. (in Chinese with an English abstract)
［10］刘丽敏，董泽，皮雅稚，等. 采用外调制器产生四倍频的光载毫米波光纤无线通信系统［J］. 中国激光, 2009, 36(1): 148-153.
LIU Li-min, DONG Ze, PI Ya-zhi, et al. Radio-over-fiber system for frequency-quadruple millimeter-wave generation by external modulator［J］. Chinese Journal of Lasers, 2009, 36(1): 148-153. (in Chinese with an English abstract)
［11］CHANG Q, FU H, SU Y. Simultaneous generation and transmission multi-band signals and upstream data in a bidirectional radio over fiber system［J］. IEEE Photonics Technology Letters, 2008, 20(3): 181-183.
［12］MA J, XIN X, YU J, et al. Optical millimeter wave generated by octupling the frequency of the local oscillator［J］. Journal of Optical Networking, 2008, 7(10): 837-845.
［13］ZHANG Y, XU K, ZHU R, et al. Photonic generation of M-QAM/M-ASK signals at microwave/millimeter-wave band using dual-drive Mach-Zehnder modulators with unequal amplitudes［J］. Journal of Lightwave Technology, 2008, 26(15): 2604-2610.
［14］MOHAMED M, HRAIMEL B, ZHANG X, et al. Frequency quadrupler for millimeter-wave multiband OFDM ultra-wideband wireless signals and distribution over fiber systems［J］. Journal of Optical Communications and Networking, 2009, 1(5): 428-438.
［15］LIN C T, SHIH P T, JIANG W J, et al. Photonic vector signal generation at microwave/millimeter-wave bands employing an optical frequency quadrupling scheme［J］. Optics Letters, 2009, 34(14): 2171-2173.
［16］SHIH P T, LIN C T, JIANG W J, et al. Transmission of 20-Gb/s OFDM signals occupying 7-GHz license-free band at 60 GHz using a RoF system employing frequency sextupling optical upconversion［J］. Optics Express, 2010, 18(12): 12748-12755.
［17］JIANG W J, LIN C T, NG-OMA A, et al. Simple 14-Gb/s short-range radio-over-fiber system employing a single-electrode MZM for 60-GHz wireless applications［J］. Journal of Lightwave Technology, 2010, 28(16): 2238-2246.
［18］LIN C T, DAI S P, CHEN J, et al. A novel direct detection microwave photonic vector modulation scheme for radio-over-fiber system［J］. IEEE Photonics Technology Letters, 2008, 20(13): 1106-1108.
