影响光纤参量振荡器全光时钟提取性能的因素分析

文峰; 武保剑; 李智; 罗特; 周星宇

影响光纤参量振荡器全光时钟提取性能的因素分析

1.
电子科技大学光纤传感与通信教育部重点实验室,四川成都 611731

详细信息

通讯作者:
文峰（1982-），男，辽宁凌源人，博士研究生，主要从事全光信息处理方面的研究工作。 Email: fengwen@uestc.edu.cn论文联系人：武保剑 Email:bjwu@uestc.edu.cn

文峰（1982-），男，辽宁凌源人，博士研究生，主要从事全光信息处理方面的研究工作。 Email: fengwen@uestc.edu.cn论文联系人：武保剑 Email:bjwu@uestc.edu.cn

中图分类号: TN929.11
计量
- 文章访问数: 2967
- HTML全文浏览量: 105
- PDF下载量: 425
- 被引次数: 0
出版历程
- 刊出日期: 2013-01-15

Factors affecting all-optical clock recovery performance based onfiber-optical parametric oscillators

1.
Key Lab of Optical Fiber Sensing and Communications,Ministry of Education,University of Electronic Science and Technology of China,Chengdu 611731,China

摘要

摘要: 实验考察了输入光信号调制速率、泵浦功率、偏振态以及光纤参量振荡器（FOPO）环形腔内光纤长度、光偏振旋转等因素对FOPO提取的时钟信号相位抖动和幅度噪声的影响。实验表明，在光时钟信号相位抖动均方值（RMS）为0.025 UI的容限内，基于FOPO的全光时钟提取方案对这些变化因素的承受能力分别为：8.2 kHz的输入信号调制速率变化、5 dB的泵浦光功率变化、20泵浦信号方位角变化、2 mm的腔内光纤长度变化以及14的腔内信号方位角变化。这为进一步提高基于FOPO全光时钟提取性能提供了重要实验依据。
- 光通信 /
- 全光时钟提取 /
- 光纤参量振荡器 /
- 高非线性光纤
Abstract: The factors influencing the phase jitter and amplitude noise of clock signal extracted by the fiberoptical parametric oscillator (FOPO), such as the modulation rate, pump power and polarization state of the input signal and the fiber length, polarization rotation in the FOPO cavity, were experimentally investigated. Experimental results show that, the all-optical clock recovery based on the FOPO can handle the variation of 8.2 kHz modulation rate, 5 dB pump power, 20 azimuth of pump signal, 2 mm cavity length and 14 signal azimuth in the cavity when the root-mean-square (RMS) phase jitter of clock signal is less than 0.025 UI. It helps to further improve the performance of all-optical clock recovery based on FOPOs.
- optical communications /
- all-optical clock recovery /
- fiber-optical parametric oscillator /
- highly nonlinear fiber

HTML全文

参考文献(1)

［1］SU Y, WANG L, AGARWAL A, et al. Wavelength-tunable all-optical clock recovery using a fiber-optic parametric oscillator［J］. Optics Communications, 2000, 184(1-4): 151-156.
［2］LI J, HUANG T, CHEN L R, et al. Detailed analysis of all-optical clock recovery at 10 Gb/s based on a fiber optical parametric oscillator［J］. IEEE Journal of Selected Topics in Quantum Electronics, 2012, 18(2): 701-708.
［3］娄采云，杨彦甫，霍力，等. 40 Gb/s信号的全光3R再生［J］. 光学学报, 2005, 25(11): 1467-1471.
LOU Cai-yun, YANG Yan-fu, HUO Li, et al. 40 Gb/s all-optical 3R regeneration［J］. Acta Optica Sinica, 2005, 25(11): 1467-1471. (in Chinese with an English abstract)
［4］王顺艳，江阳，吴次南，等. 全光纤锁模腔结构的全光时钟提取实验研究［J］. 中国激光, 2012, 39(5): 0505005-1-0505005-5.
WANG Shun-yan, JIANG Yang, WU Ci-nan, et al. Experimental study on all-optical clock recovery of all-fiber mode-locking cavity configuration［J］. Chinese Journal of Lasers, 2012, 39(5): 0505005-1-0505005-5. (in Chinese with an English abstract)
［5］LI J, CHEN L R. Tunable and reconfigurable multiwavelength fiber optical parametric oscillator with 25 GHz spacing［J］. Optics Letters, 2010, 35(11): 1872-1874.
［6］LUO Z, ZHONG W, CAI Z, et al. Multiwavelength fiber optical parametric oscillator［J］. IEEE Photonics Technology Letters, 2009, 21(21): 1609-1611.
［7］SHARPING J E, SANBORN J R, FOSTER M A, et al. Generation of sub-100-fs pulses from a microstructure-fiber-based optical parametric oscillator［J］. Optics Express, 2008, 16(22): 18050-18056.
［8］ZHOU X, LU C, SHUM P, et al. A performance analysis of an all-optical clock extraction circuit based on Fabry-Perot filter［J］. Journal of Lightwave Technology, 2001, 19(5): 603-613.
［9］王廷宇，于晋龙，韩丙辰，等. 基于FP滤波器的多波长时钟提取［J］. 光电子·激光, 2010, 21(8): 1138-1140.
WANG Ting-yu, YU Jin-long, HAN Bing-chen, et al. Multi-wavelength clock extraction based on F-P filter［J］. Journal of Optoelectronics Laser, 2010, 21(8): 1138-1140. (in Chinese with an English abstract)
［10］BUTLER D L, WEY J S, CHBAT M W, et al. Optical clock recovery from a data stream of an arbitrary bit rate by use of stimulated Brillouin scattering［J］. Optics Letters, 1995, 20(6): 560-562.
［11］吕博，张峰，简水生. 基于受激布里渊散射的40 Gb/s时钟提取试验［J］. 光电子·激光, 2008, 19(10): 1339-1342.
LU Bo, ZHANG Feng, JIAN Shui-sheng. Experimental of 40 Gb/s clock recovery based on stimulated Brillouin stattering［J］. Journal of Optoelectronics · Laser, 2008, 19(10): 1339-1342. (in Chinese with an English abstract)
［12］罗特，武保剑，文峰. 低功率抽运光纤参量振荡器的时钟提取抖动性能［J］. 中国激光, 2011, 38(8): 0805003-1-0805003-5.
LUO Te, WU Bao-jian, WEN Feng. Jitter performance of clock signal extracted by fiber optical parametric oscillator with low power pump［J］. Chinese Journal of Lasers, 2011, 38(8): 0805003-1-0805003-5. (in Chinese with an English abstract)
［13］YANG S, ZHANG C, ZHOU Y, et al. Two-wavelength square-waveform generation based on fiber optical parametric oscillator［J］. IEEE Transactions on Microwave Theory and Techniques, 2010, 58(11): 3381-3386.
［14］YANG S, CHEUNG K K Y, ZHOU Y, et al. Dispersion-tuned harmonically mode-locked fiber-optical parametric oscillator［J］. IEEE Photonics Technology Letters, 2010, 22(8): 580-582.
［15］NAKAZAWA M, YOSHIDA E, KIMURD Y. Ultrastable harmonically and regeneratively mode-locked polarisation-maintaining［J］. Electronics Letters, 1994, 30(19): 1603-1605.
［16］TIAN Y, DONG P, YANG C. Polarization independent wavelength conversion in fibers using incoherent pumps［J］. Optics Express, 2008, 16(8): 5493-5498.
［17］罗特，武保剑，文峰，等. 基于闲频光功率的光纤参量振荡器反馈控制实验［J］. 中国激光, 2012, 39(8): 0805008-1-0805008-5.
LUO Te, WU Bao-jian, WEN Feng, et al. Experiments on feedback control of fiber optical parametric oscillator based on idler power［J］. Chinese Journal of Lasers, 2012, 39(8): 0805008-1-0805008-5. (in Chinese with an English abstract)
