人眼安全激光测距与红外成像滤光膜的研制

王丽荣; 石澎; 李华杰

人眼安全激光测距与红外成像滤光膜的研制

王丽荣^1,2, ,,
石澎¹,
李华杰³

1.
中山火炬职业技术学院,广东中山 528436;
2.
重庆大学软件学院,重庆 400044;
3.
西安应用光学研究所,陕西西安 710065

详细信息

通讯作者:
王丽荣（1976-），女，湖北潜江人，工程师，主要从事光学零件制造与检测方向的研究工作。 Email: aolifou@163.com

中图分类号: TN214
计量
- 文章访问数: 2563
- HTML全文浏览量: 94
- PDF下载量: 380
- 被引次数: 0
出版历程
- 刊出日期: 2013-01-15

Design and fabrication of eye-safe laser ranging andinfrared imaging filter film

WANG Li-rong^{1,2
, ,},
SHI Peng¹,
LI Hua-jie³

1.
Zhongshan Torch Polytechnic,Zhongshan 528436,China;
2.
College of Software Engineering,Chongqing University,Chongqing 400044,China;
3.
Xi-an Institute of Applied Optics,Xi-an 710065,China

摘要

摘要: 从人眼安全的角度，设计并制备了对1 064 nm激光抑制并可用于1 550 nm激光测距以及3 m～5 m波段红外成像的滤光膜。选用ZnS、YbF3作为膜料组合、多光谱ZnS作为基底，利用薄膜设计软件对薄膜进行了优化设计。膜系设计通过合理的厚度控制和膜层安排，来增强薄膜的机械强度。滤光膜的制备采用了电子束沉积技术，通过离子辅助沉积和真空退火处理技术，进一步提高滤光膜的牢固性。光谱测试表明：在1 064 nm处的透射率仅为0.5%，1 550 nm处的透过率为99.3%，3 m～5 m波段的平均透过率大于96%，经分析YbF3的折射率在薄膜沉积过程中有所提高，但是对光谱曲线影响不大；可靠性测试表明：滤光膜能够耐受恶劣的环境考验，满足使用要求。
- 人眼安全 /
- 激光测距 /
- 红外成像 /
- 滤光膜
Abstract: From the viewpoint of eye-safe, a filter film with 1 550 nm for laser ranging and 3 m～5 m spectral band for infrared imaging was designed and fabricated to inhibit 1 064 nm laser. In order to improve the mechanical strength of filter film, the thickness of every film layer was limited and the layers were reasonably arranged. ZnS and YbF3 were used as the materials and multi-spectral ZnS was used as the substrate. The filter film was fabricated by the electron beam deposition technique. Ion assisted deposition and vacuum annealing techniques were used to improve the stability of filter film. The result of spectrum measurement shows that the transmittance is only 0.5% for 1 064 nm laser and 99.3% for 1 550 nm laser, and the average transmittance is more than 99.6% for the range of 3.5 m～3.9 m. Although the refractive index of YbF3 increases in the process of deposition, the spectrum curve is not severely impacted. Environmental reliability tests were finished and results prove that the filter film is tolerant of harsh environment and can meet the requirement.
- eye-safe /
- laser ranging /
- infrared imaging /
- filter film

HTML全文

参考文献(1)

［1］卢常勇，王小兵，郭延龙，等. 1.5xμm波长人眼安全的军用激光测距机及其进展［J］. 激光与光电子学进展, 2005, 42(3): 3-35.
LU Chang-yong, WANG Xiao-bing, GUO Yan-long, et al. Principle and evolution of 1.5xμm wavelength eye-safe military laser rangefinder［J］. Laser & Optoelectronics Progress, 2005, 42(3): 3-35. (in Chinese with an English abstract)
［2］刘海波. 光电预警探测技术研究［J］. 应用光学, 2011, 32(1): 45-48.
LIU Hai-bo. Electro-optical detection technology for early warning［J］. Journal of Applied Optics, 2011, 32(1): 45-48. (in Chinese with an English abstract)
［3］阙立志. 3～13 μm宽带红外分束镜研究［J］. 红外技术, 2011, 33(12): 695-698.
QUE Li-zhi. Study of a 3 μm to 13 μm wideband infrared beamsplitter［J］. Infrared Technology, 2011, 33(12): 695-698. (in Chinese with an English abstract)
［4］乔明霞，黄伟，张彬. YbF3和ZnS薄膜的折射率和厚度的分光光度法测定［J］. 激光杂志, 2006, 27(1): 24-25.
QIAO Ming-xia, HUANG Wei, ZHANG Bin. Determination of refractive index and thickness of YbF3 and ZnS thin films from spectrophotometric method［J］. Laser Journal, 2006, 27(1): 24-25. (in Chinese with an English abstract)
［5］王懿喆，朱福荣，张凤山. 3.5 μm～12.5 μm三波段宽带红外Ge窗口多层增透膜的研制［J］. 光学与光电技术, 2005, 3(1): 32-34.
WANG Yi-zhe, ZHU Fu-rong, ZHANG Feng-shan. Design and fabrication of wide three-band infrared antireflection coatings for Ge window from （3.5～12.5） μm［J］. Optics & Optoelectronic Technology, 2005, 3(1): 32-34. (in Chinese with an English abstract)
［6］张耀平，张云洞，凌宁，等. 基底温度对YbF3薄膜缺陷和光学性能影响研究［J］. 光学仪器, 2005, 28(1): 93-96.
ZHANG Yao-ping, ZHANG Yun-dong, LING Ning, et al. Study on the influence of substance temperature on the defect and optical performance of single YbF3 films［J］. Optical Instruments, 2005, 28(1): 93-96. (in Chinese with an English abstract)
［7］贺才美，付秀华，孙钰林，等. 多波段激光滤光膜的研制［J］. 中国激光, 2009, 36(6): 1550-1554.
HE Cai-mei, FU Xiu-hua, SUN Yu-lin, et al. Study and fabrication of multi-band laser filter film［J］. Chinese Journal of Lasers, 2009, 36(6): 1550-1554. (in Chinese with an English abstract)
［8］陈焘，罗崇泰，王多书，等. 离子束辅助沉积和真空退火对硫化锌薄膜应力的影响［J］. 真空科学与技术学报, 2009, 29(S1): 55-58.
CHEN Tao, LUO Chong-tai, WANG Duo-shu, et al. Influence of ion beam assistance deposition and annealing on stress in ZnS films［J］. Chinese Journal of Vacuum Science and Technology, 2009, 29(S1): 55-58. (in Chinese with an English abstract)
［9］林大伟，黄伟，熊胜明，等. 不同沉积角度对氟化镱薄膜性质的影响［J］. 光电工程, 2011, 38(1): 103-106.
LIN Da-wei, HUANG Wei, XIONG Sheng-ming, et al. Effect of different deposition angle on the performance of YbF3 film［J］. OptoElectronic Engineering, 2011, 38(1): 103-106. (in Chinese with an English abstract)
［10］杨永亮，刘国军，付秀华，等. 激光敌我识别系统中滤光膜的研制［J］. 光学学报, 2012, 32(1): 0131002-1-7.
YANG Yong-liang, LIU Guo-jun, FU Xiu-hua, et al. Study and fabrication of filter film in laser identification between friend or FOE system［J］. Acta Optica Sinica, 2012, 32(1): 0131002-1-7. (in Chinese with an English abstract)
