数字电影反光镜3D扫描面形检测与评价

吕少波; 王银河; 雷鹏; 姚春龙; 高鹏; 阴晓俊

数字电影反光镜3D扫描面形检测与评价

1.
沈阳仪表科学研究院,辽宁沈阳 110043

详细信息

通讯作者:
吕少波（1980-），男，河北新乐人，工程师，博士，主要从事薄膜光学研究。 Email:lvshaobo@hb-optical.com

中图分类号: O483；TH74
计量
- 文章访问数: 2296
- HTML全文浏览量: 97
- PDF下载量: 399
- 被引次数: 0
出版历程
- 刊出日期: 2013-01-15

Surface inspection and evaluation of ellipsoidal mirror using 3D scanning

1.
Shenyang Academy of Instrumentation Science,Shenyang 110043,China

摘要

摘要: 通过3D扫描的方法，对椭球反光镜的面形进行了检测，并与标准椭球面形进行最佳拟合对比，以E210反光镜为例。结果表明：3D扫描能够完成椭球反光镜的检测，E210反光镜在底孔部位存在加工过量，在端口部位存在近似十字形对称的加工不足的现象，加工误差范围为-0.06 mm ~+0.08 mm，符合轮廓度误差0.1 mm的要求。3D扫描点云能够进行逆向反求并建立实际反射面模型，进一步模拟反光镜的反射光斑形状、大小等参数，模拟结果与检测结果一致。
- 椭球反光镜 /
- 3D扫描 /
- 面形偏差 /
- 光路模拟
Abstract: By using 3D scanning detection method, we measured the surface of ellipsoidal reflector and performed the best fitting contrast with the standard ellipsoidal suface-taking E210 reflector as an example. The result shows that the 3D scan detection method is capable of ellipsoidal reflector inspection, and the E210 ellipsoidal reflector is processed excessively on the bottom and insufficiently on the top in an approximate shape like cross. The processing error is -0.06 mm~+0.08 mm, which meets the limited profile error range of -0.1 mm~+0.1 mm. We carried out the reverse calculation according to the scanned point cloud data and established an actual reflection surface model, moreover, further simulation of reflector parameters, such as reflecting spot shape and size, was accomplished. The simulation results correspond well to the test result.
- ellipsoidal reflector /
- 3D scan /
- surface error /
- optical-path simulation

HTML全文

参考文献(1)

［1］陶友石. 深椭球冷膜反光镜在放映机光学系统中的应用［J］. 影视技术, 2004(4):58-63.
TAO You-shi.Application of ellipsoidal reflector in optical system of movie projector［J］. Motion Picture & Video Technology, 2004(4):58-63.(in Chinese with an English abstract)
［2］朴承镐, 于化东, 顾莉栋, 等. 切线法数控加工高次非球面新原理的提出［J］. 吉林大学学报:工学版, 2011, 41(增刊1), 134-139.
PIAO Cheng-hao, YU Hua-dong, GU Li-dong, et al. Proposal of new principle for high-order aspherical machining by CNC tangent method［J］. Journal of Jilin University:Engineering and Technology Edition, 2011, 41(Sup.1):134-139. (in Chinese with an English abstract)
［3］于化东, 顾莉栋, 朴承镐, 等. 用切线法数控加工高次非球面［J］.吉林大学学报:工学版, 2012, 42(2):354-359.
YU Hua-dong, GU Li-dong, PIAO Cheng-hao, et al. Processing high-order aspherical by CNC tangent method［J］.Journal of Jilin University:Engineering and Technology Edition, 2012, 42(2):354-359. (in Chinese with an English abstract)
［4］SUN Xu-tao, ZHENG Zhen-rong, LIU Xu, et al. Etendue analysis and measurement of light source with elliptical reflector［J］. Displays, 2006, 27(2):56-61.
［5］沈阳百格机器人.三维扫描仪在发动机叶片测量中的应用［J］. 航空制造技术, 2010(9):105.
SHENYANG BERGER ROBOT.Application of 3D scanner in aeroengine blade measurement［J］. Aeronautical Manufacturing Technology, 2010(9):105. (in Chinese with an English abstract)
［6］赵文辉, 段振云, 何龙, 等. 锥椭球反光镜加工与检测原理与应用［J］.机械传动, 2011, 35(8):85-87;90.
ZHAO Wei-hui, DUAN Zhen-yun, HE Long, et al. Principle and application of machining and measurement for taper ellipsoid reflector［J］.Journal of Mechanical Transmission, 2011, 35(8): 85-87;90. (in Chinese with an English abstract)
［7］陆鹏, 张熹. 回转体三维扫描形貌测量及其应用［J］. 实验力学, 2012, 27(2):29-33.
LU Peng, ZHANG Xi. 3D scan method for measurement of profile and its application［J］. Journal of Experimental Mechanics, 2012, 27(2):29-33.(in Chinese with an English abstract)
［8］饶锡新, 钟春华. 3D扫描的产品质量检测方法［J］.江西冶金, 2006, 26(2):37-38;48.
RAO Xi-xin, ZHONG Chun-hua. A new method of the product quality testing besed on 3D scanning［J］.Jiangxi Metallurgy, 2006, 26(2):37-38;48.(in Chinese with an English abstract)
［9］熊汉伟, 张洪, 张湘伟. 基于双目立体视觉的手持式线激光3D扫描方法［J］.应用激光, 2009, 29(3):233-236.
XIONG Han-wei, ZHANG Hong, ZHANG Xiang-wei. Hand-held line laser 3D scanning method based on stereo vision［J］.Applied Laser, 2009, 29(3):233-236.(in Chinese with an English abstract)
［10］王诩, 王银河, 姚春龙,等. 基于TracePro软件的组合反光镜设计与分析［J］.灯与照明, 2010, 34(3):18-21.
WANG Xu, WANG Yin-he, YAO Chun-long, et al. Design of combined reflector using TracePro［J］. Light & Lighting, 2010, 34(3):18-21.(in Chinese with an English abstract)
［11］陈月娥, 李国强, 候蓝田. 基于TracePro软件的多曲面路灯反射器设计［J］.建筑电气, 2008, 27(4):21-23.
CHEN Yue-e, LI Guo-qiang, HOU Lan-tian. Design of multi-curved surfaces street lamp reflector based on TracePro software［J］. Building Electricity, 2008, 27(4):21-23.(in Chinese with an English abstract)
