基于峰值信噪比和小波方向特性的图像奇异值去噪技术

王敏; 周磊; 周树道; 叶松

基于峰值信噪比和小波方向特性的图像奇异值去噪技术

王敏^1, ,,
周磊²,
周树道¹,
叶松¹

1.
解放军理工大学气象海洋学院,江苏南京 211101;
2.
南京南瑞继保电气有限公司,江苏南京 211101

详细信息

通讯作者:
王敏(1983-),女,汉族,陕西咸阳人, 讲师,硕士,主要从事图像处理、模式识别的研究工作. Email：yu0801@163.com

中图分类号: TN911.73
计量
- 文章访问数: 3185
- HTML全文浏览量: 130
- PDF下载量: 397
- 被引次数: 0
出版历程
- 刊出日期: 2013-01-15

Image SVD denoising based on PSNR and wavelet directional feature

1.
Institute of Meteorology and Oceanography,PLA University of Science and Technology,Nanjing 211101,China;
2.
NR Electric Co.,Ltd.,Nanjing 211101,China

摘要

摘要: 提出一种利用小波变换子图像不同的方向特性和峰值信噪比进行奇异值分解的图像去噪算法。由于图像经过小波变换后，低频子图像集中了原图像的大部分能量噪声，故仅作简单维纳滤波；而噪声则主要集中在小波域中的三个不同方向的高频子图中，且系数较小，因此可以利用奇异值分解进行去噪处理，即用较大的奇异值和对应的特征向量重构出去噪图像，然而由于奇异值分解固有的行列方向性，对于高频对角线子图重构出的图像去噪效果不理想，故采取旋转至行列方向后再进行常用的奇异值滤波；最后将去噪后的低频和高频子图进行小波反变换重构出最终的去噪图像,其中重构所需的奇异值个数由图像的峰值信噪比确定。实验结果表明，该方法在有效去噪的同时较好的保留了原有的高频细节信息。
- 图像去噪 /
- 小波变换 /
- 奇异值分解 /
- 峰值信噪比 /
- 小波重构
Abstract: An optimized image singular value decomposition (SVD) denoising algorithm based on wavelet transform directional information and peak signal to noise ratio (PSNR) was proposed. As most of the energy noises were concentrated in low-frequency sub-image after wavelet transform, the simple Wiener filtering was made; on the other hand, the image noises were mainly concentrated in the high-frequency sub-image with three different directions and the coefficient was smaller, so the larger singular values of SVD and their corresponding eigenvectors were used to reconstruct denoising image; however, because of the inherent directional feature of the SVD, the denoising result of image reconstructed from high-frequency diagonal sub-image was not satisfied, so the diagonal sub-image was rotated to the level (vertical) direction, then the SVD filtering was done; finally, the anti-wavelet transform was used to reconstruct the denoising image based on the low-frequency and high-frequency sub-images, and the required number of singular values was determined by PSNR of the image. Experimental results show that this method has effective denoising effect, while retaining the high-frequency original details.
- image denoising /
- wavelet transform /
- singular value decomposition /
- peak signal to noise ratio /
- wavelet reconstruction

HTML全文

参考文献(1)

［1］HOU Z. Adaptive singular value decomposition in wavelet domain for image denoising［J］.Pattern Recognition, 2003(36):1747-1763.
［2］KONSTANINIDES K, NATARAJAN B, YOVANOF G S. Noise estimation and filtering using blockbased singular value decomposition［J］. IEEE Transactions on Image Processing,1997,6(3):479-483.
［3］周树道,王敏,刘志华,等.基于多方向小波变换及形态学重构的SAR图像边缘检测［J］.解放军理工大学学报:自然科学版,2011,12(5):436-439.
ZHOU Shu-dao, WANG Min, LIU Zhi-hua et al. SAR image edge detection based on multi-directional wavelet transform and morphological reconstruction［J］. Journal of PLA University of Science and Technology: Natural Science Edition. 2011,12(5):436-439.(in Chinese with an English abstract)
［4］黄飞江,朱守业. 基于小波变换和改进SVD的红外图像去噪［J］.激光与红外,2009,39(3):335-338.
HUANG Fei-jiang, ZHU Shou-ye. Infrared image denoising based on wavelet transform and improved SVD［J］. Laser & Infrared,2009,39(3):335-338.(in Chinese with an English abstract)
［5］DEVCIC Z, LONCARIC S. SVD blok processing for nonlinear image noise filtering［J］. Journal of Computing and Information Technology,1999,7(3):255-259.
［6］刘波,杨华,张志强.基于奇异值分解的图像去噪［J］.微电子与计算机,2007,24(11):169-174.
LIU Bo, YANG Hua, ZHANG Zhi-qiang. Image de-noising based on singular value decomposition［J］.Microelectronics & Computer,2007,24(11):169-174.(in Chinese with an English abstract)
［7］KONSTANINIDES K, YAO K. Statistical analysis effective singular values in matrix rank determination［J］. IEEE Transactions on Acoustics, Speech, and Signal Process,1988,36(5):757-763.
［8］张俊峰,孙清伟.基于图像旋转和分块的奇异值分解图像去噪［J］.激光与红外,2009,39(5):538-541.
ZHANG Jun-feng, SUN Qing-wei. Image denoising based on SVD using image rotation and block［J］. Laser & Infrared, 2009,39(5):538-541.(in Chinese with an English abstract)
