光纤照明用LED耦合装置设计

付倩; 苏成悦; 周镇; 何榕礼

光纤照明用LED耦合装置设计

1.
广东工业大学物理与光电工程学院,广东广州 510006

详细信息

通讯作者:
付倩（1987-），女，湖北武汉人，硕士研究生，主要从事照明光学设计研究。Email:fuqian871108@163.com。通信作者,苏成悦,Email:scy.gdut@163.com.

付倩（1987-），女，湖北武汉人，硕士研究生，主要从事照明光学设计研究。Email:fuqian871108@163.com。通信作者,苏成悦,Email:scy.gdut@163.com.

中图分类号: TN256
计量
- 文章访问数: 2880
- HTML全文浏览量: 125
- PDF下载量: 598
- 被引次数: 0
出版历程
- 刊出日期: 2013-01-15

LED coupled device for fiber-optic illumination

1.
School of Physics and Optoelectronic Engineering,Guangdong University of Technology,Guangzhou 510006,China

摘要

摘要: 光纤照明用LED光源耦合装置多采用透镜组，其汇聚光斑小，但透镜组光能损失大。针对LED光源发光特性及聚合物光纤孔径大的特点，提出LED灯珠侧式安装和反射器切割移位优化法，设计一种基于椭圆反射器的光纤照明用LED耦合装置。运用John OFarrell的逼近算法计算出不同偏心率的椭圆反射器结构参数，结合光纤光学参数仿真比较耦合光效，得到一组偏心率和光纤直径匹配的高效耦合装置结构参数，并运用该方法设计了一款光纤直径10 mm、数值孔径0.5的光纤照明用LED耦合装置，其理想耦合光效达93.35%。
- 光纤照明 /
- LED /
- 耦合装置 /
- 反射器
Abstract: Coupled device with LED light source for fiber-optic illumination is often composed of lens group. Though the convergence spot of this system is small, the light loss of lens group is big. Due to the characteristics of LED light source and the big aperture of polymer optical fiber, an side installation for LED lamp and an optimization method that reflector was cutted and shifted were put forward,and a kind of coupled device with LED light source based on elliptical reflector was designed. Using the approximation algorithm that had been proposed by John O-Farrell, the elliptical reflector-s structure parameters for different eccentricities were calculated. Through comparing the coupling efficiency by combining with the simulation of fiber-s optical parameters, a group of structural parameters of efficient coupled device that the eccentricity matched the fiber diameter were obtained. Using this method, a coupled device with LED light source was designed which had a fiber diameter of 10 mm and numerical aperture of 0.5.The ideal coupling efficiency was up to 93.35%.
- fiber-optic illumination /
- LED /
- coupled device /
- reflector

HTML全文

参考文献(1)

［1］江源. 光纤照明发展史［J］. 光源与照明, 2009(3):46-48.
JING Yuan. History of fiber optic illumination［J］. Lamps & Lighting,2009(3):46-48 (in Chinese with an English abstract)
［2］徐晓星. 光纤照明的原理与应用［J］. 灯与照明,2002,26(5):29-30,37.
XU Xiao-xing. Principles and applications of fiber optic illumination［J］. Light & Lighting,2002,26(5):29-30,37. (in Chinese with an English abstract)
［3］谈卫,刘陈,郑重,等. 基于光纤照明技术的新型矿灯的设计及实现［J］. 照明工程学报, 2010,21(3):88-92.
TAN Wei, LIU Chen, ZHENG Zhong, et al. Design and realization of new miner-s lamp based on fiber optic technology［J］. China Illuminating Engineering Journal,2010,21(3):88-92. (in Chinese with an English abstract)
［4］范力维,邓向阳,任豪. 大功率LED 光纤特种照明灯的设计开发［J］. 机电工程技术,2010, 39(1):49-51.
FAN Li-wei, DENG Xiang-yang, REN Hao. The design and development of special high-power LED lights with fiber［J］. Mechanical & Electrical Engineering Technology,2010,39(1):49-51 (in Chinese with an English abstract)
［5］王恺. 大功率LED封装与应用的自由曲面光学研究［D］. 武汉：华中科技大学,2011.
WANG Kai. Freeform optics for high power LED packages and applications［D］.Wuhan: Huazhong University of Science and Technology,2011. (in Chinese with an English abstract)
［6］高伟霞,孙长伟,常晶晶,等. 光纤太阳光照明系统中聚光装置的设计［J］. 应用光学, 2008,29(5):808-811.
GAO Wei-xia, SUN Chang-wei, CHANG Jing-jing, et al. Design of fiber light-focusing device for sunlight illumination system［J］. Journal of Applied Optics,2008,29(5):808-811. (in Chinese with an English abstract)
［7］O-FARRELL J, LEWIN I, BOHAN S, et al. Optical component relationships in the design of efficient fiber optic illuminators［J］. Journal of the Illuminating Engineering Society, 2000,29(1): 51-57.
