Pyroelectric laser energy meter used in non-regular ambient environment
-
摘要: 现有的激光能量计传感器灵敏度系数都与其所处环境温度有关，在-50℃～70℃的温度范围内，灵敏度偏差较大，直接影响测量结果。为了达到消除环境温度的影响，采取在不同环境温度下对热释型能量计的灵敏度进行校准的研究方法。该校准方法与普通激光能量计的校准方法的不同之处在于对热释电型能量计进行校准时，温度由室温扩展到-50℃～70℃的温度范围。利用环境试验箱，每隔10℃固定一个温度点，进行激光能量的测量实验，得到各个温度点所对应的灵敏度修正系数，再借助最小二乘法建立起各个温度点上能量计灵敏度系数同环境温度的函数关系，从而实现了-50℃～70℃的温度范围内激光能量的准确计量。研制能直接工作于非常规工作环境下的热释电型激光能量计，对解决激光能量测量的外场需求有一定现实意义。Abstract: The sensor sensitivity of laser energy meter at present is related to the ambient temperature and varies considerably in the range of -50℃～70℃ which influences the measurements directly. To eliminate the influence of ambient temperature，this paper describes the sensitivity calibration method for pyroelectric energy meter at different ambient temperatures. First of all，the energy meter is put into the environment test chamber and the temperature point is set every 10℃ in the range of -50℃～70℃.Next the sensitivity correction coefficients at different set temperature points are calculated. The function between the sensitivity correction coefficients gotten above and the ambient temperatures is established and the other sensitivity correction coefficients at different temperature points are deduced by least square method. In real ambient environment，the sensitivity coefficient is calculated according to the function between sensitivity coefficient and ambient temperature to realize accurate measurements of laser energy in non-regular environment. The developed pyroelectric laser energy meter which can work in non-regular environment solves the problem of laser energy measurement in field.
-
-
［1］张松祥，胡齐丰.光辐射探测技术［M］.上海：上海交通大学出版社，1996.
ZHANG Song-xiang，HU Qi-feng. Optical radiation detection technology［M］. Shanghai：Shanghai Jiaotong University Press，1996.(in Chinese)
［2］国防科工委科技与质量司.光学计量:上册［M］ .北京：原子能出版社，2002.
Science technology and quality agent of national defense science＆technology commission. Optical metrology［M］. Beijing：Atomic Energy Press，2002. (in Chinese)
［3］光学/计量测试技术手册编辑委员会.计量测试技术手册:第10卷［M］.北京:中国计量出版社，1997.
Optics/Metrology Measurement Technology Manual. Metrology measurement technology manual: Vol.10［M］. Beijing：China Metrology Press，1997. (in Chinese)
［4］杨照金，王雷.激光功率与能量计量技术现状与展望［J］.应用光学,2004,25（3）：1-4.
YANG Zhao-jing，WANG Lei. The status and outlook of metrology technology for laser power and energy［J］. Journal of Applied Optics，2004，25(3)：1-4. (in Chinese with an English abstract)
［5］马冲,郭正强.高精度激光功率能量基准的研究［J］. 测试技术学报, 1998,12(2):156-161.
MA Chong，GUO Zheng-qiang. Study of high accuracy standard of laser power and energy［J］. Measurement Technology Journal, 1998，12(2)：156-161. (in Chinese with an English abstract)
［6］于靖.瓦级激光功率基准器研究［J］.现代计量测试.1998(1): 55-58.
YU Jing. Study of standard for mega-watts laser power［J］. Contemporaneity Metrology Measurement, 1998(1): 55-58. (in Chinese with an English abstract)
［7］黎高平, 王雷,杨照金,等. 长脉冲高能激光能量测试技术的研究［J］.光子学报，2004, 33(9):1111-1114.
LI Gao-ping ,WANG Lei ,YANG Zhao-jin , et al.Study on the measurement of long pulse high power laser energy［J］. Acta Photonica Sinica, 2004 , 33 (9)：1111-1114.（in Chinese with an English abstract）
［8］王魁汉. 温度测量实用技术［M］.北京: 机械工业出版社，2006.
WANG Kui-han.Temperature measurement technology［M］. Beijing：Mechanical Industry Press，2006. (in Chinese )
［9］HAMMERICH M, OLAFSSON A. A versatile, low-cost pyroelectric laser power monitor for the lmW to 50W range［J］.J. Phys. E: Sci Instrum,1988,21(5):80-83.
［10］杨冶平，黎高平，杨斌，等.现场用激光能量计校准方法的实验研究［J］.应用光学,2008,29（1）：141-143.
YANG Ye-ping，LI Gao-ping，YANG Bin，et al. Investigation of calibration technology in field for laser energy meter［J］. Journal of Applied Optics，2008，29(1)：141-143. (in Chinese with an English abstract)
［11］孙宝贵.激光能量测量装置及脉宽对测量的影响［J］.现代计量测试,1998(6):45-47.
SUN Bao-gui. Laser measurement instrument and the pulse wide influence for the measurement ［J］. Modern Measure and Test, 1998(6): 45-47. (in Chinese with an English abstract)
