一种提取光反馈混沌激光器时延信息的谱分析方法

郭园园; 武媛; 王云才

一种提取光反馈混沌激光器时延信息的谱分析方法

1.
太原理工大学物理与光电工程学院光电工程研究所,山西太原 030024

详细信息

通讯作者:
郭园园（1986-），女，山西临汾人，硕士，主要从事半导体激光器的非线性动态特性及应用的研究工作。

中图分类号: TN248.2
计量
- 文章访问数: 2840
- HTML全文浏览量: 87
- PDF下载量: 451
- 被引次数: 0
出版历程
- 刊出日期: 2012-05-15

Time-delay signature identification in optical feedback chaotic lasers from power spectrum analysis

1.
Institute of Optoelectronic Engineering,College of Physics and Optoelectronics,Taiyuan University of Technology,Taiyuan 030024,China

摘要

摘要: 鉴于时延信息严重威胁着混沌通信的保密性，提出了一种利用频谱仪直接确定激光器时延信息的新方法。通过记录和观察信号的频谱，发现其频谱受到了时延信息的调制；进一步对频谱作逆傅里叶变换，即可直接获取光反馈混沌激光器的时延信息。实验中对腔长L=11.02 m的单反馈和腔长近似相等(L1=11.02 m, L2=11.25 m)或腔长成整数比(L1=11.02 m, L2=22.03 m) 的双反馈情形进行了研究。分析结果表明：在两外腔长度近似相等的情况下，2个外腔长度信息不能被隐藏；当反馈外腔长度成整数比时可以从频谱中提取出半导体激光器的反馈延迟时间。
- 混沌 /
- 光反馈 /
- 时间延迟
Abstract: Considering that the time delay signature has great threat to the security of chaotic communication, we proposed a novel method to directly identify the time delay signature of chaotic laser using a radio-frequency (RF) spectrum analyzer. Through recording and observing the RF power spectrum, it could be found that the power spectrum was actually modulated by the time delay signature; further performing an inverse Fourier transform to the RF power spectrum of chaotic laser, we could directly unveil the time delay signature. We experimentally studied two kinds of optical feedbacks: one was the single feedback cavity with a cavity length L=11-02 m and the other has two feedback cavities that the two cavity lengths were roughly equal to each other (L1=11-02 m and L2=11-25 m) or one was half of another (L1=11-02 m, L2=22-03 m). The results show that the time delay signatures can not be concealed when the two cavity lengths are roughly equal to each other; when one cavity is an integral multiple of another, the time delay signatures can still be extracted from the RF power spectrum of chaotic laser.
- chaos /
- optical feedback /
- time delay

HTML全文

参考文献(1)

［1］ARGYRIS A, SYVRIDIS D, LARGER L, et al. Chaos-based communications at high bit rates using commercial fiber-optic links ［J］. Nature, 2005, 437(17): 343-346.

［2］LIN F Y，LIU J M. Chaotic lidar ［J］. IEEE journal of selected topics in quantum electronics, 2004, 10(5): 991-997.

［3］WANG Yun-cai,WANG Bing-jie, WANG An-bang.Chaotic correlation optical time domain reflectometer utilizing laser diode ［J］. IEEE Photonics Technology Letters, 2008, 20(19): 1636-1638.

［4］王云才, 马建议, 韩晓红, 等. 混沌激光相关法测距系统的信号采集与处理［J］. 应用光学, 2011, 32(3): 568-573.

WANG Yun-cai,MA Jian-yi,HAN Xiao-hong, et al. Data acquisition and processing of correlation ranging system with chaotic laser ［J］. Journal of Applied Optics, 2011, 32(3): 568-573. (in Chinese with an English abstract)

［5］UCHIDA A, AMANO K, INOUE M, et al. Fast physical random bit generation with chaotic semiconductor lasers ［J］. Nature Photonics, 2008, 2(12): 728-732.

［6］WANG An-bang, WANG Yun-cai,WANG Juan-fen.Route to broadband chaos in a chaotic laser diode subject to optical injection ［J］. Optics Letters, 2009, 34(8):1144-1146.

［7］PEREZ G, CERDEIRA H A. Extracting messages masked by chaos ［J］. Physical Review Letters, 1995, 74(11): 1970-1973.

［8］KEY W H, CHOI M, RIM S, et al. Characteristics of a delayed system with time-dependent delay time ［J］. Physical Review E, 2004, 69(5): 055202.

［9］NGUIMDO R M, COLET P, LARGER L, et al. Dig-ital key for chaos communication performing time delay concealment ［J］. Physical Review Letters, 2011, 107(3): 034103.

［10］LEE M W, LARGER L,UDALTSOV V, et al. Demonstration of a chaos generator with two time delays ［J］. Optics Letters, 2004, 29(4): 325-327.

［11］KIM C M, KYE W H, RIM S, et al. Communication key using delay time in time-delayed chaos synchronization ［J］. Physics Letters A, 2004, 333(3): 235-240.

［12］RONTANI D, LOCQUET A,SCIAMANNA M, et al. Time-delay identification in a chaotic semiconductor laser with optical feedback: a dynamical point of view ［J］. IEEE Journal of Quantum Electronics, 2009, 45(7): 879-891.

［13］WU Jia-gui, XIA Guang-qiong, WU Zhang-mao. Suppression of time delay signatures of chaotic output in a semiconductor laser with double optical feedback ［J］. Optics Express, 2009, 17(22): 20124-20133.
