一维光幕测试旋转对称破片的动能

鲁倩, 倪晋平

鲁倩, 倪晋平. 一维光幕测试旋转对称破片的动能[J]. 应用光学, 2012, 33(3): 558-563.
引用本文: 鲁倩, 倪晋平. 一维光幕测试旋转对称破片的动能[J]. 应用光学, 2012, 33(3): 558-563.
shu
LU Qian, NI Jin-ping. Kinetic energy measurement for rotationally symmetric fragment using one-dimensional screen[J]. Journal of Applied Optics, 2012, 33(3): 558-563.
Citation: LU Qian, NI Jin-ping. Kinetic energy measurement for rotationally symmetric fragment using one-dimensional screen[J]. Journal of Applied Optics, 2012, 33(3): 558-563.
shu

一维光幕测试旋转对称破片的动能

  • 西安工业大学 光电工程学院,陕西 西安 710032

详细信息
    通讯作者:

    鲁倩 (1986-)，女，陕西兴平人，硕士研究生，主要从事光电测试技术和信号处理研究工作。

  • 中图分类号: TN911.71

Kinetic energy measurement for rotationally symmetric fragment using one-dimensional screen

  • School of Optoelectronic Engineering,Xi-an Technological University,Xi-an 710032,China

摘要

    摘要
  • 摘要: 针对飞行破片动能测试，提出了一种采用光幕测试飞行破片动能的方法。该方法采用两台光幕靶测试飞过光幕的破片的速度，通过破片穿过光幕输出的波形提取体积信息，得到破片的穿靶质量，进而得到破片的动能。文中分析了光幕输出波形与破片体积关系的理论模型，采用3种典型的旋转对称形状物体仿真验证了理论模型，并研究了一种标定方法。实弹射击试验表明，所提方法可以测量旋转对称破片或弹丸的动能，测量精度满足靶场测试的要求。
    Abstract: Aiming at the measurement of kinetic energy for flying fragments, a measuring method of kinetic energy for the flying fragment using single screen was presented. Two screens were used to measure the speed of the flying fragment in the method, the volume information was got by mean of the output waveform of the fragment passing through the screen, further the quality and the kinetic energy of the fragment were obtained. This paper analyzed a theoretical model of the relationship between the output waveform of the screen and the volume of the fragment. Three typical rotational symmetry objects simulations were used to verify the theoretical model, and a calibrating method was studied. The testing result of the ball firing proved that the proposed method could measure the kinetic energy of the rotational symmetry projectile or fragment, the measurement precision satisfied the requirement of the range test.
    • HTML全文
    • 参考文献(1)
  • ［1］黄正祥,高森烈,李良威,等.小口径弹丸破片的测速方法研究［J］.南京理工大学学报,2000, 24(5):466-468.

    HUANG Zheng-xiang, GAO Sen-lie, LI Liang-wei. The Study of fragment velocity measurement for small caliber projectiles［J］. Journal of Nanjing University of Science and Technology,2000,24(5):466-468.(in Chinese with an English abstract)

    ［2］倪晋平，李晋慧，王铁岭.一种新的模拟导弹战斗部破片群单个速度测试系统［J］.西安工业学院学报，1999,19（4）：274-278.

    NI Jin-ping, LI Jin-hui, WANG Tie-ling. A new velocity measuring system for single fragment of simulated missile warhead［J］. Journal of Xi,an Institute  of Technology, 1999,19(4):274-278. (in Chinese with an English abstract)

    ［3］倪晋平，田会. 用于光幕测试的时刻信息提取方法研究［J］. 光学技术, 2008,34(1): 141-144.

    NI Jin-ping, TIAN Hui. A study on method for acquiring moment on which a projectile going through a light screens［J］. Optical Technique, 2008, 34(1): 141-144. (in Chinese with an English abstract)

    ［4］蔡荣立，倪晋平，杨敏,等.双缝光幕靶设计［J］.应用光学，2007，28（4）：392-396.

    CAI Rong-li, NI Jin-ping, YANG Min,et al. Design on double-slit light screens［J］. Journal of Applied Optics, 2007，28（4）：392-396. (in Chinese with an English abstract)

    ［5］倪晋平,王铁岭.光电靶的工作原理及应用［J］.西安工业学院学报,1997,17(1):42-46.

    NI Jin-ping, WANG Tie-ling . The principle and application of screens［J ］. Journal of Xi-an Institute of Technology,1997,17(1):42-46.(in Chinese with an English abstract)

    ［6］倪晋平，蔡荣立，田会,等. 基于大靶面光幕靶30mm口径弹丸速度测试技术［J］. 测试技术学报，2008，22(1):17-22.

    NI Jin-ping, CAI Rong-li, TIAN Hui, et al. Velocity measuring technology for 30 mm-caliber flying projectiles based on large area light screens［J］. Journal of Test and Measurement Technology, 2008, 22(1): 17-22. (in Chinese with an English abstract)

    ［7］智小军，倪晋平，田会,等. 相关分析技术在光幕靶速度测量中的应用［J］. 探测与控制学报，2005, 27(1): 44-46.

    ZHI Xiao-jun, NI Jin-ping, Tian Hui, et al. Application of cross-correlation analysis techniques in velocity measurement of light screen［J］. Journal of Detection & Control, 2005, 27(1): 44-46. (in Chinese with an English abstract)

    ［8］席峰，倪晋平.大靶面光幕靶中发光二极管阵列线光源的设计［J］.测试技术学报，2005,19(1):40-43.

    XI Feng, NI Jin-ping. Design of linear light source composed of light-emitting diode array in large light-screen Target［J］. Journal of Test and Measurement Technology, 2005,19(1): 40-43. (in Chinese with an English abstract)

    ［9］贾兆辉，施浣芳.光幕靶靶面光能分布均匀性的研究［J］.西安工业学院学报，2005,25(4):319-322.

    JIA Zhao-hui, SHI Huan-fang. Study on the distributing uniformity of light energy on screen［J］. Journal of Xi-an Institute of Technology, 2005, 25(4): 319-322. (in Chinese with an English abstract)

    ［10］卢芳云，李翔宇，林玉亮.战斗部结构与原理［M］.北京：科学出版社，2009.

    LU Fang-yun, LI Xiang-yu, Lin Yu-liang. The structure and principle of warhead［M］. Beijing: Science Press, 2009. (in Chinese)
