Review of low-illuminance image enhancement algorithm based on deep learning
-
摘要:
在弱光条件下拍摄的图像往往存在亮度和对比度较低、颜色失真和噪声较大等特点，严重影响人眼的主观效果，极大地限制了高阶视觉任务的性能。低照度图像增强(low illuminance image enhancement, LIIE)旨在改善这类图像的视觉效果，为后续处理提供有利条件。在诸多低照度图像增强算法中，基于深度学习的低照度图像增强成为最新的解决方案。首先梳理了基于深度学习的低照度图像增强的代表性方法；其次介绍了现有低照度图像数据集、损失函数和评价指标；再次通过基准测试与实验分析，进一步对现有基于深度学习的低照度图像增强算法进行全面评估；最后对目前研究进行总结，并对低照度图像增强的发展方向进行讨论和展望。
Abstract:Images captured under low-light conditions are often characterized by low brightness and contrast, color distortion, and high noise, which seriously affect the subjective vision of human eyes and greatly limit the performance of higher-order vision tasks. Low illuminance image enhancement (LIIE) aims to improve the visual effect of such images and provide favorable conditions for subsequent processing. Among many low-illuminance image enhancement algorithms, the LIIE based on deep learning has become the latest solution. Firstly, the representative methods for LIIE based on deep learning were reviewed. Secondly, the existing low-illuminance image datasets, loss functions, and evaluation indicators were introduced. Thirdly, the existing LIIE algorithms based on deep learning were comprehensively evaluated through benchmark testing and experimental analysis. Finally, a summary of current research was provided, and the development direction of LIIE was discussed and prospected.
-
Keywords:
- low-illuminance images /
- image enhancement /
- deep learning /
- loss function /
- benchmark testing
-
引言
英伟达TensorRT是一种高性能神经网络推理（Inference）引擎，是一个标准C++库。TensorRT只能用来做Inference（推理），不能用来进行训练，用于在生产环境中部署深度学习应用程序[1]。应用领域包括图像分类、分割和目标检测等，可提供最大的推理吞吐量和效率。TensorRT需要CUDA（compute unified device architecture）的支持，包含一个为优化生产环境中部署的深度学习模型而创建的库，可获取经过训练的神经网络（通常使用32位或16位数据），并针对降低精度的INT8运算来优化这些网络。借助CUDA的可编程性，TensorRT将能够应对深度神经网络日益多样化、复杂化的趋势。TensorRT在不断的改进过程中，在保证软件精度的同时，自动优化训练过的神经网络，不断提高速度。TensorRT能够支持Caffe等主流深度学习框架[2-3]。
本文实现了一个利用TensorRT执行智能视频分析的典型应用，演示了使用片上解码器进行解码，使用片上转换器进行视频缩放，利用TensorRT执行对象标识，利用OpenGL2和XWindow-11进行渲染，并在标识的对象周围生成包围框。此外，还使用视频转换器函数进行各种格式转换。使用EGLImage来演示缓冲区共享和图像显示。图1展示了使用TensorRT的流程细节[4-5]。
1 定义视频处理结构体
本文例程将本地存储的H.264视频文件进行解码、格式转换和渲染，为了使流程清晰，便于管控，定义context_t结构管理视频处理全部资源。如表1所示成员主要包括一个解码器类、一个转换器类、一个渲染器类、一个数据指针。解码器类NvVideoDecoder封装了用于视频解码的多媒体API函数，用于从H.264视频文件解码压缩的视频。转换器类NvVideoConverter封装了视频转换的相关函数，包括色彩空间变换、尺度变换以及软硬件缓存空间的变换。渲染器类NvEglRenderer类封装了图像渲染的相关函数以及XWindow-11以及OpenGL2的部分函数，使用EGL和OpenGL ES 2.0进行呈现。渲染器需要缓冲区的文件描述符（FD）作为输入，创建自己的X窗口。渲染速率（以帧/s为单位），窗口的宽度、高度、水平偏移量和垂直偏移量都是可配置的。所有EGL调用只能通过一个线程进行。该类在内部创建一个线程，该线程执行所有EGL/GL初始化，从FD获取EGLImage对象，然后反初始化所有EGL/GL结构[6-9]。
表 1 Context_t结构主要成员Table 1. Main members of Context_t structure成员 描述 NvVideoDecoder 包含视频解码相关的成员和函数 NvVideoConverter 包含视频格式转换相关的成员和函数 NvEglRenderer 包含EGL显示渲染相关函数 EGLImageKHR EGLImage图像数据指针，用于CUDA处理，这个类型来源于EGL开源库 2 利用TRT_Context类进行加速推理
英伟达提供的TRT_Context类包含一系列接口来加载Caffe模型并执行推理。表2描述了本示例中使用的关键TRT_Context成员。本文中使用buildTrtContext实现Caffe模型到TensorRT模型转换，它的输入参数包括caffe网络结构文件和模型参数文件。实际上也可借助转换工具实现Caffe模型到gie模型的转换。TRT_Context:: getNumTrtInstances用于获取加速上下文的实例。TRT_Context::doInference用转换好的模型利用TensorRT进行加速推理。此外，TRT_Context还实现了一些模型控制和剪裁的一些函数接口[10-13]。
表 2 TRT_Context类主要成员Table 2. Main members of TRT_Context classTRT_Context类成员 描述 TRT_Context::buildTrtContext 构建Tensorrt上下文 TRT_Context::getNumTrtInstances 获取TRT_context 实例. TRT_Context::doInference TensorRT 推理接口 3 主进程
主进程调用以上定义的类和结构实现整个处理流程，主要代码如下：
TRT_Context g_trt_context;
main(int argc, char *argv[])
{
//程序入口参数处理
context_t ctx[CHANNEL_NUM];
global_cfg cfg;
char **argp;
set_globalcfg_default(&cfg);
argp = argv;
parse_global(&cfg, argc, &argp);
parse_csv_args(&ctx[0], &g_trt_context, argc-cfg.channel_num-1, argp)；
//设置g_trt_context参数
g_trt_context.setModelIndex(TRT_MODEL);
g_trt_context.buildTrtContext(cfg.deployfile, cfg.modelfile, true);
pthread_create(&TRT_Thread_handle, NULL, trt_thread, NULL);
// 获取EGL默认值
egl_display = eglGetDisplay(EGL_DEFAULT_DISPLAY);
// EGL 初始化
eglInitialize(egl_display, NULL, NULL)
for (iterator = 0; iterator < cfg.channel_num; iterator++)
{
int ret = 0;
sem_init(&(ctx[iterator].dec_run_sem), 0, 0);
set_defaults(&ctx[iterator]);
char decname[512];
sprintf(decname, "dec%d", iterator);
ctx[iterator].channel = iterator;
ctx[iterator].in_file_path = cfg.in_file_path[iterator];
ctx[iterator].nvosd_context = nvosd_create_context();
//创建解码器
ctx[iterator].dec = NvVideoDecoder::createVideoDecoder(decname);
//设置输出面板格式
ctx[iterator].dec->setOutputPlaneFormat(ctx[iterator].decoder_pixfmt, CHUNK_SIZE);
//映射输出面板缓存
ctx[iterator].dec->output_plane.setupPlane(V4L2_MEMORY_MMAP, 10, true, false);
//创建渲染线程
pthread_create(&ctx[iterator].render_feed_handle, NULL, render_thread, &ctx[iterator]);
char convname[512];
// 创建BL到 PL转换器
ctx[iterator].conv = NvVideoConverter::createVideoConverter(convname);
ctx[iterator].conv->output_plane.setDQThreadCallback(conv_output_dqbuf_thread_callback);
ctx[iterator].conv->capture_plane.setDQThreadCallback(conv_capture_dqbuf_thread_callback);
if (ctx[iterator].cpu_occupation_option!= PARSER)
pthread_create(&ctx[iterator].dec_capture_loop, NULL, dec_capture_loop_fcn, &ctx[iterator]);
pthread_create(&ctx[iterator].dec_feed_handle, NULL, dec_feed_loop_fcn, &ctx[iterator]);
//等待解码器获取EOS
sem_wait(&(ctx[iterator].dec_run_sem));
//向渲染器发送命令
ctx[iterator].stop_render = 1;
pthread_cond_broadcast(&ctx[iterator].render_cond);
pthread_join(ctx[iterator].render_feed_handle, NULL);
}
}
4 测试与分析
在这个示例中，对象检测仅限于在960×540分辨率的视频流中识别汽车。该网络基于GoogleNet。推理是在逐帧的基础上进行的，不涉及任何对象跟踪，展示了如何使用TensorRT快速构建计算管道。示例使用训练过的GoogleNet网络，它是用NVIDIA深度学习GPU训练系统（DIGITS）训练的。训练是大约3 000帧从1.5 m（5英尺）~3 m（10英尺）的高度拍摄的。根据输入的视频样本，预计会有不同程度的检测精度。运行程序对H.264本地视频进行测试，TensorRT能够成功运行，实时识别目标图像[14-15]，测试效果如图2所示。
其运行性能如下：
FP32 run:400 batches of size 100 starting at 100
........................................
Top1: 0.9904, Top5: 1
Processing 40000 images averaged 0.00157702 ms/image and 0.157702 ms/batch.
FP16 run:400 batches of size 100 starting at 100
Engine could not be created at this precision
INT8 run:400 batches of size 100 starting at 100
........................................
Top1: 0.9908, Top5: 1
Processing 40000 images averaged 0.00122583 ms/image and 0.122583 ms/batch.
可以看到这个例子中采用int8量化时，提速可以达到20%以上，对于大计算量的应用，提速效果更好。推理（Inference）可以使用低精度的技术，训练的时候因为要保证前后向传播，每次梯度的更新是很微小的，这个时候需要相对较高的精度，一般来说需要float型，如FP32，32位的浮点型来处理数据。但是在推理的时候，对精度的要求没有那么高，很多研究表明可以用低精度，如半长（16字节）的FP16，也可以用8位的整型INT8来做推理，结果没有特别大的精度损失。低精度计算的好处是一方面可以减少计算量，原来计算32位的单元处理FP16的时候，理论上可以达到2倍的速度，处理INT8的时候理论上可以达到4倍的速度。另一方面是模型需要的空间减少，不管是权值的存储还是中间值的存储，应用更低的精度，模型大小会相应减小。
TensorRT的运行效果与GPU的硬件性能和采用的网络结构直接相关，量化标准仅仅是其中一个影响因素，不同的硬件和网络结构也会带来不同程度的速度提升。为了对比上述例子的加速性能，图3展示了采用GPU卡V100对ResNet网络进行TensorRT加速的实际效果。
![]()
图 3 V100卡+ResNet网络使用TensorRT推理的效果Figure 3. Effect of TensorRT reasoning in V100 card+ResNet network这是一个比较极端的例子，该例中使用的是先进的GPU卡V100，V100添加了专门针对深度学习优化的TensorCore，TensorCore可以完成4×4矩阵的半精度乘法，也就是可以完成一个4×4的FP16矩阵和另外一个4×4的FP16矩阵相乘，当然可以再加一个矩阵（FP16 或FP32），得到一个FP32或者FP16的矩阵的过程。TensorCore在V100上理论峰值可以达到120 Tflops。如果只是用CPU来做推理，首先它的吞吐只能达到140，也就是说每秒只能处理140张图片，同时整个处理过程需要有14 ms的延迟，也就是说用户提交请求后，推理阶段最快需要14 ms才能返回结果；如果使用V100，在TensorFlow中去做推理，大概是6.67 ms的延时，但是吞吐只能达到305；如果使用V100加TensorRT，在保证延迟不变的情况下，吞吐可以提高15倍，高达5 700张图片帧/s。可以看到随着GPU性能的提升，以及网络结构的复杂化，TensorRT对推理速度的提升非常明显，对于大数据应用是一个很好的选择。目标英伟达公司已经将TensorRT项目部分开源，这势必会使TensorRT得到更好的推广应用。
-
![]()
图 1 配对低光数据集的低照度图像示例(第1行为弱光图像，第2行为参考图像)
Figure 1. Examples of low-illuminance images in some paired low-light datasets (row 1 refers to low-light images, and row 2 refers to reference images)
![]()
图 2 无配对低光数据集的低照度图像示例
Figure 2. Examples of low-illuminance images in some unpaired low-light datasets
![]()
图 3 不同方法在MIT-Adobe FiveK-test数据集中的低照度图像增强效果对比
Figure 3. Contrast of low-illuminance images enhancement effect in MIT-Adobe FiveK-test dataset with different methods
![]()
图 4 不同方法在LOL-test数据集中的低照度图像增强效果对比
Figure 4. Contrast of low-illuminance images enhancement effect in LOL-test dataset with different methods
表 1 基于深度学习的代表性低照度图像增强方法
Table 1 Representative low-illuminance image enhancement methods based on deep learning
Method Learinng Network structure(model) Loss function Format Code Publication Project address LLNet[14] SL Stacked sparse denoising autoencoder SRR loss RGB Theano PR(2017) https://github.com/kglore/llnet_color LightenNet[27] SL Four layers $ {L}_{2} $ loss RGB Caffe PR(2018) https://github.com/Li-Chongyi/low-light-codes MBLLEN[19] SL Feature extraction module;
Enhancement module;
Fusion moduleSSIM loss; Region loss;
Perceptual lossRGB TensorFlow BNVC(2018) https://github.com/Lvfeifan/MBLLEN RetinexNet[26] SL Multi-scale network $ {L}_{1} $ loss; Smoothness loss;
Invariable reflectance lossRGB TensorFlow BMVC(2018) https://github.com/weichen582/RetinexNet SICE[40] SL Low frequency luminance;
High frequency detail$ {L}_{1} $ loss; $ {L}_{2} $ loss;
SSIM lossRGB Caffe TIP(2018) https://github.com/csjcai/SICE SID[20] SL Amplification ratio $ {L}_{1} $ loss RAW TensorFlow CVPR(2018) https://github.com/cchen156/Learning-to-See-in-the-Dark SMD[41] SL Filtered results;
Siamese networkRecovery loss; Self-Consistency loss RAW TensorFlow ICCV(2019) https://github.com/cchen156/Seeing-Motion-in-the-Dark SMOID[42] SL 3D U-Net $ {L}_{1} $ loss RAW TensorFlow ICCV(2019) https://github.com/MichaelHYJiang/Learning-to-See-Moving-Objects-in-the-Dark DeepUPE[23] SL Illumination map $ {L}_{1} $ loss; Color loss;
Smoothness lossRGB TensorFlow ACM(2019) https://github.com/dvlab-research/DeepUPE EnlightenGAN[30] UL Attention map;
Self-regularzationAdversarial loss;
Self feature preserving lossRGB PyTorch arXiv(2019) https://github.com/VITA-Group/EnlightenGAN KinD[29] SL Reflectance layers $ {L}_{1} $ loss; SSIM loss; Reflectance similarity loss; $ {L}_{2} $ loss; smoothness loss; RGB TensorFlow ACMMM(2019) https://github.com/zhangyhuaee/KinD ExCNet[37] ZSL Fully connected layers Energy minimization loss RGB PyTorch ACMMM(2019) https://cslinzhang.github.io/ExCNet/ DSLR[22] SL Laplacian pyramid;
U-Net like network$ {L}_{2} $ loss; Color loss;
Laplacian lossRGB PyTorch IEEE(2020) https://github.com/SeokjaeLIM/DSLR-release TBEFN[44] SL Three stages;
U-Net like networkSSIM loss; Perceptual loss
Smoothness loss;RGB PyTorch IEEE(2020) https://github.com/lukun199/TBEFN Zero-DCE[39] ZSL Fully connected network Illumination smoothness loss; Spatial consistency loss; Color constancy loss RGB PyTorch CVPR(2020) https://github.com/soumik12345/Zero-DCE DRBN[35] SSL Recursive network SSIM loss; Perceptual loss;
Adversarial lossRGB PyTorch CVPR(2021) https://github.com/flyywh/CVPR-2020-Semi-Low-Light Retinex DIP[45] ZSL Encoder-decoder network Reflectance loss; Smoothness loss RGB PyTorch IEEE(2021) https://github.com/zhaozunjin/RetinexDIP RUAS[46] ZSL Neural architecture search Cooperative loss; Similar
Loss; Total variation lossRGB PyTorch CVPR (2021) https://github.com/KarelZhang/RUAS SCI[34] UL Self-Calibrated Illumination Fidelity loss;
Smoothness lossRGB PyTorch CVPR(2022) https://github.com/tengyu1998/SCI SNR-aware[43] SL SNR-guided attention Charbonnier loss; Perceptual loss RGB PyTorch CVPR(2022) https://github.com/dvlab-research/SNR-Aware-Low-Light-Enhance Dimma[36] SSL Mixture density network;
U-Net like networkMean squared error loss;
Perceptual lossRGB PyTorch arXiv(2023) https://github.com/WojciechKoz/Dimma PairLIE[15] UL Encoder-decoder networks Projection Loss; Retinex Loss; Reflectance consistency loss RGB PyTorch CVPR(2023) https://github.com/zhenqifu/PairLIE CUE[62] SL Masked autoencoder;
Customized learnable priorsIllumination smoothness loss; Noise prior loss RGB PyTorch ICCV(2023) https://github.com/zheng980629/CUE
下载: 导出CSV
表 2 低照度图像增强数据集总结
Table 2 Summary of low-illuminance image enhancement dataset
Dataset Date Number Resolution/pixel Format Real/
SyntheticPaired Download link LIME[47] 2017 10 326×326～2 000× 15000 RGB Real No https://github.com/estija/LIME NPE[12] 2013 85 267×304～749×492 RGB Real No https://github.com/Spirals-Team/npe-dataset DICM[48] 2013 64 481×321 RGB Real No https://github.com/JoshuaEbenezer/LDR ExDark[49] 2019 7363 500×332～ 1600 ×1066 RGB Real No https://github.com/cs-chan/Exclusively-Dark-Image-Dataset VE-LOL-H[50] 2021 10940 1080 ×720RGB Real No https://flyywh.github.io/IJCV2021LowLight_VELOL/ SID[20] 2018 5094 4240 ×2832 or6000 ×4000 RAW Real Yes https://github.com/cchen156/Learning-to-See-in-the-Dark LOL[26] 2018 789 400×600 RGB Real Yes https://daooshee.github.io/BMVC2018website/ SICE[40] 2018 4413 3000 ×2 000 or6000 ×4 000RGB Real Yes https://github.com/csjcai/SICE MIT-Adobe
Fivek[51]2011 5000 $ 1\;440\times 2\;160 $～ 6048 ×4032 RAW Real+
SyntheticYes https://data.csail.mit.edu/graphics/fivek/ DRV[41] 2019 202 3672 ×5496 RAW Real Yes https://github.com/cchen156/Seeing-Motion-in-the-Dark VE-LOL-L[50] 2021 2500 400×600 RGB Real+
SyntheticYes https://flyywh.github.io/IJCV2021LowLight_VELOL/ UHD-LOL[52] 2023 11065 4000 $ \times 4\;000 $ or8000 ×8000 RGB Real Yes https://github.com/TaoWangzj/LLFormer
下载: 导出CSV
表 3 在MIT-Adobe FiveK-test数据集上的性能比较
Table 3 Performance comparison on MIT-Adobe FiveK-test dataset
Metnod MSE↓ PSNR↑ SSIM↑ NIQE↓ BRISQUE↓ input[51] 1.723 14.825 0.764 6.124 31.183 LLNet[14] 4.241 9.698 0.473 6.688 38.794 lightenNet[27] 4.172 15.139 0.635 6.971 29.159 MBLLEN[19] 1.267 14.965 0.863 6.947 32.318 RetinexNet[26] 3.943 11.333 0.492 4.036 26.355 KinD[29] 1.609 14.054 0.558 4.217 35.661 TBEFN[44] 3.690 9.760 0.461 5.308 30.181 EnlightenGAN[30] 3.837 14.598 0.793 3.915 31.345 SCI[34] 3.608 14.820 0.723 3.801 29.395 ExCNet[37] 2.927 12.698 0.473 7.648 38.794 Zero-DCE[39] 3.360 12.416 0.736 4.037 31.637 RRDNet[38] 6.199 9.966 0.416 5.173 37.278 RUAS[46] 3.376 9.588 0.460 4.194 27.971 DRBN[35] 3.410 13.639 0.754 4.361 38.904
下载: 导出CSV
表 4 在LOL-test数据集上的性能比较
Table 4 Performance comparison on LOL-test dataset
Metnod MSE↓ PSNR↑ SSIM↑ NIQE↓ BRISQUE↓ input[26] 9.712 7.951 0.131 7.948 42.153 LLNet[14] 1.080 16.583 0.715 5.453 38.549 lightenNet[27] 7.993 11.876 0.428 5.394 13.440 MBLLEN[19] 1.172 18.257 0.723 5.318 12.238 RetinexNet[26] 1.714 16.141 0.464 5.702 38.681 KinD[29] 1.133 16.240 0.704 4.764 27.438 TBEFN[44] 1.445 16.002 0.730 3.983 10.956 EnlightenGAN[30] 1.824 15.997 0.715 3.720 11.070 SCI[34] 1.503 15.654 0.491 3.308 14.863 ExCNet[37] 2.752 15.370 0.538 4.648 19.134 Zero-DCE[39] 2.851 15.278 0.535 5.596 15.408 RRDNet[38] 5.993 13.982 0.461 4.909 14.071 RUAS[46] 3.144 14.667 0.416 5.625 12.287 DRBN[35] 2.622 15.047 0.432 5.121 22.781
下载: 导出CSV
-
