Study on measurement technology of ultra-low brightness
-
摘要:
光亮度是表征发光体的重要光度特性参数。提出了一种超低亮度计的设计方法，描述了超低亮度计的工作原理和组成；利用微弱光信号处理技术、非线性校准技术、制冷散热技术等实现了超低亮度的自动测量；根据亮度计的测量原理，对仪器进行了标定，测量不确定度达到5%。超低亮度计可适用于实验室和现场等测试场所，为微光夜视装备、显示系统、特种光源、发光材料等的性能评估测试和校准提供计量保障。
Abstract:The brightness is an important parameter of photometric characteristics to characterize the luminescent materials. A design method of ultra-low brightness meter was proposed, and the working principle and composition of the device were described. The automatic measurement of ultra-low brightness was realized by using the technologies of weak light signal processing, nonlinear calibration, cooling and heat dissipation. According to the principle of brightness meter measurement, the calibration was carried out, and the uncertainty of measurement was up to 5%. The ultra-low brightness meter can be used in testing sites such as laboratory and field, which can provide metrological guarantee for performance evaluation and calibration of low-level-light night vision equipment, display system, special light source and luminescent materials.
-
-
![]()
图 2 超低亮度计组成及工作原理图
Figure 2. Composition and working principle of ultra-low brightness meter
![]()
图 6 超低亮度计测量亮度源示意图
Figure 6. Schematic of measuring luminance source by ultra-low brightness meter
表 1 PMT制冷方案温控原理实验数据
Table 1 Experimental data of temperature control principle of PMT refrigeration scheme
时间/min 温度/℃ 电流/A 备注 0 22.6 10 − 1 2.8 9.9 − 2 −6 9.8 − 3 −11.8 9.7 − 4 −15.6 9.6 − 5 −18.4 9.5 − 6 −20.3 9.4 5′50″时达到-20 ℃ 7 −21.9 9.3 − 8 −19.85 9.2 8′50″时达到平衡 9 20.02 9.1 温度稳定 10 −20.05 9 温度稳定
下载: 导出CSV
表 2 超低亮度计亮度实验结果
Table 2 Brightness experimental results of ultra-low brightness meter
测量次数 亮度/×10−6 cd/m2 亮度平均值/
×10−6 cd/m2相对实验
标准偏差/%1 3.727 3.684 2.65 2 3.812 3 3.745 4 3.539 5 3.763 6 3.604 7 3.756 8 3.641 9 3.535 10 3.718
下载: 导出CSV
表 3 超低亮度计测量不确定度一览表
Table 3 List of ultra-low brightness photometer measurement uncertainties
测量不确定
度分量ui测量不确
定度来源测量不
确定度/%评定
方法u1 透镜焦距引入的不确定度 0.05 B u2 成像面上的照度引入的不确定度 2.0 B u3 光学系统的透过率引入的不确定度 1.0 B u4 透镜与发光面的距离引入的不确定度 0.1 B u5 孔径直径引入的不确定度 0.5 B u6 测量重复性引入的不确定度 0.9 A
下载: 导出CSV
-
[1] 曹远生. JMS便携成像式亮度计的研制[J]. 实用测试技术,2000(1):21-24. CAO Yuansheng. Development of JMS portable imaging luminance meter[J]. Practical Measurement Technology,2000(1):21-24.
[2] 刘玉龙, 黎俊. 图像色度亮度计的校准方法研究[J]. 工业计量,2017,27(2):1-4. LIU Yulong, LI Jun. Research on calibration method of image chroma luminance meter[J]. Industrial Metrology,2017,27(2):1-4.
[3] 李默. 积分式与分光式测光测色仪器的计量校正[J]. 电视技术,2012,36(4):71-77. doi: 10.3969/j.issn.1002-8692.2012.04.022 LI Mo. Metrological correction of integral and spectroscopic photometry and color measuring instruments[J]. Television Technology,2012,36(4):71-77. doi: 10.3969/j.issn.1002-8692.2012.04.022
[4] 阮育娇. 显示用亮度计的校准[J]. 中国照明电器,2017(8):49-52. doi: 10.3969/j.issn.1002-6150.2017.08.012 RUAN Yujiao. Calibrating methods for luminance meters used on display industry[J]. China Light & Lighting,2017(8):49-52. doi: 10.3969/j.issn.1002-6150.2017.08.012
[5] 周拥军, 赵宝奇, 王鹏. CCD成像型亮度计测量方法研究[J]. 电学与控制,2010,17(12):49-52. ZHOU Yongjun, ZHAO Baoqi, WANG Peng. Study on a measurement method of CCD imaging luminance meter[J]. Electronics Optics & Control,2010,17(12):49-52.
[6] 温娜, 武晓光, 李默, 等. 成像式亮色度计测量特性分析[J]. 电视技术,2014,38(增刊1):34-38. WEN Na, WU Xiaoguang, LI Mo, et al. Analysis of measurement characteristics of imaging brightness colorimeter[J]. Television Technology,2014,38(S1):34-38.
[7] 张雪静, 徐英莹, 曹峰梅. 两种不同类型的滤光片式彩色亮度计性能比较[J]. 液晶与显示,2013,28(1):146-151. doi: 10.3788/YJYXS20132801.0146 ZHANG Xuejing, XU Yingying, CAO Fengmei. Performance contrast of two different types of optical filter color luminance meter[J]. Chinese Journal of Liquid Crystals and Displays,2013,28(1):146-151. doi: 10.3788/YJYXS20132801.0146
[8] 全国光学计量技术委员会. 亮度计检定规程: JJG 211-2005 [S]. 北京: 国家质量监督检验检疫总局, 2005. National Optical Metrology Technical Committee. Verification regulation of luminance meters: JJG 211—2005 [S]. Beijing: State General Administration of the People's Republic of China for Quality Supervision and Inspection and Quarantine, 2005.
[9] 魏建中, 王仲春, 苏学刚, 等. CCD成像型宽量程亮度计系统研究[J]. 光学技术,1999(1):88-91. doi: 10.3321/j.issn:1002-1582.1999.01.029 WEI Jianzhong, WANG Zhongchun, SU Xuegang. Study on measurement method of CCD imaging luminance meter[J]. Optical Technology,1999(1):88-91. doi: 10.3321/j.issn:1002-1582.1999.01.029
[10] 孙德印, 姚军. BM-5彩色亮度计的改造设计[J]. 电视技术,2002(6):99-100. doi: 10.3969/j.issn.1002-8692.2002.06.037 SUN Deyin, YAO Jun. Redesign of BM-5 color luminance meter[J]. Television Technology,2002(6):99-100. doi: 10.3969/j.issn.1002-8692.2002.06.037
[11] 郑喜凤, 黄娉, 刘贵华. 三基色亮度计的设计和应用[J]. 微计算机信息,2009,25(2):62-64. ZHENG Xifeng, HUANG Ping, LIU Guihua. Design and application of tricolor luminance meter[J]. Microcomputer Information,2009,25(2):62-64.
[12] 徐骏, 孟炳寰, 郑小兵, 等. 红外标准辐亮度计的研制及定标[J]. 红外与激光工程, 2013, 42(4): 863-868. XU Ju, MENG Binghuan, ZHENG Xiaobing, Development and calibration of infrared standard radiometer[J]. Infrared and Laser Engineering, 2013, 42(4): 863-868.
[13] 黄蓓. 遮光筒式亮度计的不确定度分析[J]. 电子产品可靠性与环境试验,2014,32(1):49-51. doi: 10.3969/j.issn.1672-5468.2014.01.011 HUANG Bei. Uncertainty analysis for shading luminance meter[J]. Electronic Product Reliability and Environmental Testing,2014,32(1):49-51. doi: 10.3969/j.issn.1672-5468.2014.01.011
[14] 汪立文, 万蕴杰. 成像式亮度计亮度测量的不确定度分析[J]. 计量与测试技术,2009,36(1):69-70. doi: 10.3969/j.issn.1004-6941.2009.01.032 WANG Liwen, WAN Yunjie. Luminance uncertainty evaluation for the measurement of luminance meter[J]. Measurement and Testing Technology,2009,36(1):69-70. doi: 10.3969/j.issn.1004-6941.2009.01.032
[15] 李振国. 光电成象式亮度计的特性及其误差表示方法[J]. 计量技术,1996(6):23-25. LI ZhenGuo. Characteristics of photoelectric imaging luminance meter and expression method of measurement error[J]. Measurement Technology,1996(6):23-25.
-
