Time-gated processing of pulse laser ranging echo signal
-
摘要: 为了降低高重频脉冲激光测距回波信号的误识别率，提高测距性能，对高重频脉冲激光测距回波信号调理技术进行深入研究。采用FPGA作为主控芯片，产生激光调制脉冲，并根据被测距离3.33 μs～33.33 μs时间选通方波信号，驱动开关芯片产生与量程关联的时间波门，有效滤除脉冲回波中的干扰脉冲，该方法改进了常规脉冲激光测距信号处理系统的自动增益控制环节。测试实验结果表明：在脉冲回波信号60 dB的动态范围内，可有效滤除回波信号中引入的干扰脉冲，极大地降低了干扰脉冲误识别造成粗大误差的可能性。该方法可推广应用于脉冲激光测距信号处理系统，使系统测距精度提高12.6%。Abstract: In order to reduce the error recognition rate of high repetition pulse laser ranging echo signal and improve the ranging performance, the adjustment technology of high repetition pulse laser ranging echo signal is studied deeply. FPGA was used as the main control chip to generate laser modulation pulses, and square wave signals were selected according to the measured distance of 3.33 μs～33.33 μs, and the switch chip was driven to generate the time wave gate associated with the range, effectively filtering out the interference pulses in the pulse echo. This method improved the automatic gain control link of the conventional pulse laser ranging signal processing system. The test results show that within the dynamic range of 60 dB of the pulse echo signal, interference pulses introduced in the echo signal can be effectively filtered out, greatly reducing the possibility of error caused by the false recognition of interference pulses. This method can be applied to the pulse laser ranging signal processing system, and the ranging accuracy of the system can be increased by 12.6%.
-
Keywords:
- laser ranging /
- time gate /
- interference pulse /
- high frequency
-
-
![]()
图 1 常规高重频脉冲激光测距系统
Figure 1. Conventional high repetition rate pulse laser ranging system
![]()
图 5 不同起始相位、相同幅值下的峰值保持值
Figure 5. Peak holding value under different starting phases and same amplitude
![]()
图 7 时间波门内不同位置、相同幅值的峰值AD采集值
Figure 7. Peak AD values of different positions and same amplitude in time gate
-
[1] 于彦梅. 激光测距机及发展趋势[J]. 情报指挥控制系统与仿真技术,2002(8):19-21. YU Yanmei. Laser rangefinder and its development trend[J]. Information Command Control System and Simulation Technology,2002(8):19-21.
[2] 蔡红霞, 刘继勇. 基于FPGA脉冲激光测距高精度时间间隔的测量[J]. 计算机与数字工程,2013,41(11):1843-1845. doi: 10.3969/j.issn.1672-9722.2013.11.040 CAI Hongxia, LIU Jiyong. Measurement of high precision time interval based on FPGA pulse laser ranging[J]. Computer and Digital Engineering,2013,41(11):1843-1845. doi: 10.3969/j.issn.1672-9722.2013.11.040
[3] 王秀芳, 王江, 杨向东, 等. 相位激光测距技术研究概述[J]. 激光杂志,2006(2):4-5. doi: 10.3969/j.issn.0253-2743.2006.02.002 WANG Xiufang, WANG Jiang, YANG Xiangdong, et al. Overview of phase laser ranging technology[J]. Laser Journal,2006(2):4-5. doi: 10.3969/j.issn.0253-2743.2006.02.002
[4] 李兵. 精密激光干涉测距电路系统研究[D]. 西安: 中国科学院研究生院(西安光学精密机械研究所), 2013. LI Bing. Research on precision laser interference ranging circuit system[D]. Xian: Graduate School of Chinese Academy of Sciences (Xi'an Institute of Optics and precision machinery), 2013.
[5] 王古常, 孙斌, 万强, 等. 军用脉冲激光测距技术与研究现状[J]. 光学与光电技术,2003(4):55-59. doi: 10.3969/j.issn.1672-3392.2003.04.014 WANG Guchang, SUN Bin, WAN Qiang, et al. Military pulse laser ranging technology and research status[J]. Optics and Optoelectronics Technology,2003(4):55-59. doi: 10.3969/j.issn.1672-3392.2003.04.014
[6] 左胜广, 柴利飞, 马号兵, 等. 高重频脉冲激光测距回波处理技术研究[J]. 中国计量大学学报,2018,29(1):1-7. doi: 10.3969/j.issn.2096-2835.2018.01.001 ZUO Shengguang, CHAI Lifei, MA Haobing, et al. Research on echo processing technology of high repetition rate pulse laser ranging[J]. Journal of China University of Metrol-ogy,2018,29(1):1-7. doi: 10.3969/j.issn.2096-2835.2018.01.001
[7] 马建平, 尚建华, 孙嘉曈, 等. 基于高速脉冲调制和回波采样的激光测距系统[J]. 中国激光,2019,46(8):282-288. MA Jianping, SHANG Jianhua, SUN Jiatong, et al. Laser ranging system based on high-speed pulse modulation and echo sampling[J]. China Laser,2019,46(8):282-288.
[8] 白雪菲, 冯迪, 秦川, 等. 高精度脉冲激光测距系统设计与实验研究[J]. 激光杂志,2019,40(10):6-10. BAI Xuefei, FENG Di, QIN Chuan, et al. Design and experimental study of high precision pulse laser ranging system[J]. Laser Journal,2019,40(10):6-10.
[9] 雷佳. 全数字高精度激光测距系统的设计与实现[D]. 上海: 上海交通大学, 2009. LEI Jia. Design and implementation of all digital high precision laser ranging system[D]. Shanghai: Jiaotong University, 2009.
[10] 龙卓群, 贡雪梅. 激光多周期测距脉冲飞行时间的测量[J]. 西安航空技术高等专科学校学报,2009,27(5):16-18. LONG Zhuoqun, GONG Xuemei. Measurement of pulse flight time of laser multi period ranging[J]. Journal of Xi'an Aviation Technology College,2009,27(5):16-18.
[11] 孟浩, 付继华, 王中宇. 远距离低盲区脉冲激光测距的实验系统[J]. 激光杂志,2008(2):59-60. doi: 10.3969/j.issn.0253-2743.2008.02.025 MENG Hao, FU Jihua, WANG Zhongyu. Experimental system of long distance low bl-ind area pulse laser ranging[J]. Laser Journal,2008(2):59-60. doi: 10.3969/j.issn.0253-2743.2008.02.025
[12] ZHENG H, MA R, LIU ML. A linear dynamic range receiver with timing discrimination for pulsed TOF imaging LADAR application[J]. IEEE Trans Actions on Instrumentation and Measurement,2018,67(11):2684-2691. doi: 10.1109/TIM.2018.2826860
[13] 郭颖, 陈弈, 黄庚华, 等. 一种应用于高精度脉冲激光测距的自动增益控制方法[J]. 激光与红外,2010,40(4):345-348. doi: 10.3969/j.issn.1001-5078.2010.04.001 GUO Ying, CHEN Yi, HUANG Genghua, et al. An automatic gain control method for high precision pulse laser ranging[J]. Laser and Infrared,2010,40(4):345-348. doi: 10.3969/j.issn.1001-5078.2010.04.001
[14] 程鹏飞. 大动态范围高精度激光测距关键技术研究[D]. 上海: 中国科学院研究生院(上海技术物理研究所), 2014. CHENG Pengfei. Research on key technologies of large dynamic range and high precision laser ranging[D]. Shanghai: Graduate School of Chinese Academy of Sciences (Shanghai Institute of Technical Physics), 2014.
[15] 戴永江. 激光雷达技术[M]. 北京: 电子工业出版社, 2010. DAI Yongjiang. Lidar technology[M]. Beijing: Electronic Industry Press, 2010.
-
