一种多通道光电系统视轴平行度调校装置

  • 1.

    西安邮电大学 电子工程学院,陕西 西安 710121;

  • 2.

    西安邮电大学 自动化学院,陕西 西安 710121

基金项目:

国家863计划课题（2013AA014504）

详细信息
    作者简介:

    乔琳（1983-），女，北京人，硕士，主要从事光学精密机械设计方面的研究。E-mail：qiaolin@xupt.edu.cn

  • 中图分类号: TN202; TH114

Optical axis parallelism adjusting instrument for multichannel photoelectric system

  • 1.

    School of Electronic Engineering,Xi’an University of Posts and Telecommunications,Xi’an 710121,China;

  • 2.

    School of Automation,Xi’an University of Posts &Telecommunications,Xi’an 710121,China

摘要

    摘要
  • 摘要: 为了获得红外、可见光及微光等不同波段靶标的图像，提出一种多通道光电系统视轴平行度调校装置。该装置能够方便地加载多通道光电探测系统，主要通过下底板的腰形孔间隙及垫修下底板来实现光电探测系统视轴平行度方位及俯仰方向的调校，使其视轴平行度达到15；该装置只需首次调整光学系统的视轴平行度，光电探测系统重复更换镜头后重复定位精度优于0.01 mm。同时装置可方便地加载于光电转台等其他设备上，便于外场试验，满足使用要求。
    Abstract: In order to obtain the infrared/visible/lowlevel light images of targets, a multichannel photoelectric system optical axis parallelism calibration device was proposed. This device could easily load multichannel photoelectric detection system, it realized the adjustment for the optical axis parallism in the azimuth and pitch directions mainly through the waistshaped hole of the backplane clearance and the pad under repair backplane, to meet the optical axis parallelism not more than 15. The instrument is characterized by simply adjusting the optical system of optical axis parallelism for the first time, it is possible to achieve different detectors repeating interchangeable lenses,and the repeatable positioning accuracy is higher than 0.01 mm. In addtional,the instrument can be easily loaded on other light equipments, such as photoelectric rotary table,convenient for field experiments, which can satify the requirement for using.
    • HTML全文
    • 参考文献(1)
  • [1]Li Gang, Zhou Bing, Sun Xinhua, et al. Handy method to detect divergence angle and optical axis parallelism of laser guidance device［J］．Optical Technique,2004, 30(5):628 636. 李刚, 周冰, 孙新华,等.激光制导装置出射激光束散角和光轴平等性的简易检测方法 [J].光学技术,2004, 30(5):628636. [2]Xi’an University of Posts and Telecommunications. A kind of multichannel optical axis adjustment device: China, 201420511864.5[P].20141114. 西安邮电大学.一种多通道光电系统光轴一致性调整装置：中国，201420511864.5[P].20141114. [3]Ling Jun, Liu Bingqi, Zhao Xilin. The comparison and discussion of several testing methods about opticalaxis parallelism[J].Journal of Applied Optics,2003,24(1):4345. 凌军,刘秉琦,赵熙林.几种光轴平行性测试方法的比较与探讨[J].应用光学,2003,24(1):4345. [4]Ao Lei, Tan Jiubin, Cui Jiwen, et al. Precise center location algorithm for circle target in CCD laser dual axis autocollimator[J].Optical and Precision Engineering, 2005,13(6):668673. 敖磊,潭久彬,崔继文,等.激光CCD二维自准直仪中圆目标中心精确定位算法[J].光学精密工程, 2005,13(6):668673. [5]Zhao Desheng, Li Caiqin, Zhang Xue. Influence of clearance on sensitivity of crankslider mechanism[J].Journal of Xi’an University of Posts and Telecommunications,2011,16（5）：98100. 赵德胜，李彩琴，张雪.间隙对曲柄滑块机构灵敏度的影响研究[J].西安邮电学院学报，2011,16（5）：98100. [6]Yao Duoshun, Li Nanqian, Kang Wenli. Method of designing linearization doublelinkage continuous zoom lens［J］．2015,36(1):18. 姚多舜，李楠茜，康文莉.线性双组联动型连续变焦光学系统设计［J］．2015,36(1):18. [7]Lu Hongming. Study on the influence of boundary conditions on the finite element analysis of short beam［J］．Chinese Journal of Engineering design, 2013, 20(4):321325. 吕红明．边界条件对短梁结构有限元分析影响的研究［J］．工程设计学报，2013，20(4):321325． [8]Xu Gening, Feng Xiaolei, Tao Yuanfang, et al. Impact of boundary conditions on the result of FEM analysis of mechanical structures［J］．Hoisting and Conveying Machinery, 2010(2):6064. 徐格宁，冯晓蕾，陶元芳，等．边界条件对机械结构有限元分析结果的影响［J］．起重运输机械，2010(2):6064． [9]Wang Xiaochen, Pu Junping. The finite element analysis of nonuniform beams［J］．Journal of Zhejiang University of Technology，2008，36(3):311315．王晓臣，蒲军平.变截面梁有限元分析［J］．浙江工业大学学报，2008，36(3):311315． [10]He Zhicheng, Chen Shaowei, Li Guangyao, et al. Topology optimization using FSFEM for complex threedimensional models[J]. Chinese Journal of Mechanical Engineering，2015,26（7）：864870. 何智成,陈少伟,李光耀,等.基于面光滑有限元的复杂三维结构拓扑优化[J].机械工程学报，2015,26（7）：864870. [11]Li Xiaoli, Yuan Yuan. Finite element analysis of driving drum of belt conveyor based on COSMOS/Works[J].Mei Kuang Jixie Coal Mine Machinery，2010，31(9):9596．李晓丽，袁圆．基于COSMOS/Works的带式输送机传动滚筒的有限元分析［J］．煤矿机械，2010，31(9):9596． [12]Luo Pei. Structural damage analysis of simplesupported beam based on finite element simulation［J］．Journal of Test And Measurement Technology，2011，25(5):440444．罗裴．基于有限元仿真的简支梁结构损伤分析［J］．测试技术学报，2011，25(5):440444．
