Testing system of radiation gain in UV image intensifiers
-
摘要: 针对辐射增益是紫外像增强器的主要性能参数，决定着紫外像增强器的综合性能，提出一种用于测试紫外像增强器辐射增益的测试仪，测试波长范围为200 nm~400 nm，亮度测量视场角可选(1/8)、(1/4)、(1/2)、1、2、3。通过改变微通道板电压、阴极电压和荧光屏电压等参数，完成对紫外像增强器的辐射增益测试,测试结果表明：测试曲线变化趋势和紫外像增强器的工作特性相吻合，入射紫外辐射强度调节范围为10-11W/cm2～10-7W/cm2，辐射计最低探测强度可达10-11W/cm2，最低亮度探测阈值可达310-4cd/m2，辐射增益测试重复性优于8%。Abstract: Radiation gain acting as the main performance parameter of the ultraviolet(UV) image intensifier determines the comprehensive performance of it，so a test intensifier was designed to measure the radiation gain in UV image intensifier,whose test range was 200 nm~400 nm, and there were 6 (1/8,1/4,1/2,1,2and 3) fields of view (FOVs) for choice .Referring to the image intensifier brightness gain measurement device, the testing system of radiation gain in UV image intensifier was designed. Based on the testing principle and method, the test software was designed. By changing the voltage of micro channel plate,the cathode voltage and screen voltage, the UV image intensifier was measured. The test results indicate that the test curve changing trend coincides with the operation characteristics of the UV intensifier, the incident UV radiation intensity is 10-7W/cm2~10-11W/cm2,the minimum detecting intensity of radiometer was 10-11W/cm2,the minimum brightness detection threshold is 310-4cd/m2 and the test repeatability of radiation gain is better than 8%.
-
Keywords:
- UV image intensifiers /
- radiation gain /
- gain testing
-
-
[1]Jin Guiping, Pang Qichang. The key points of UV imaging and detecting system [J]. Acta Photonica Sinica, 2003, 32(3):294-297.
靳贵平,庞其昌. 紫外成像检测技术[J]. 光子学报, 2003,32(3):294-297.
[2]Teng Hesong. The technology of photoelectron[J].Optoelectronic Technology,2001,21(4):294-297.
腾鹤松.紫外成像技术及其应用[J].光电子技术, 2001,21(4):294-297.
[3]Wu Xingling，Qiu Yafeng, Qian Yunsheng, et al. Relationship between voltage of MCP and signal-to-noise ratio of UV image intensifier[J]. Journal of Applied Optics，2013，34（3）：494-497.
吴星琳，邱亚峰，钱芸生，等. 紫外像增强器信噪比与MCP电压的关系[J]. 应用光学，2013，34（3）：494-497.
[4]Qian Yunsheng, Chang Benkang, Qiu Yafeng,et al. Measurement of luminance gain and equivalent background input LLL image intensifiers[J]. Vacuum Electronics, 2004(2) : 35-37.
钱芸生,常本康,邱亚峰,等.微光像增强器亮度增益和等效背景照度测试技术[J].真空电子技术, 2004(2): 35-37.
[5]Wang Guihua. Ptoelectronic decices[M].Beijing:Nation Defense Industry Press,2014.
汪贵华.光电子器件[M].北京：国防工业出版社，2014.
[6]Cheng Hongchang,Duanmu Qingduo, Shi Feng, et al. Characterization of solar blind double micro-channel plate ultraviolet image intensifier[J]. Chinese Journal of Vacuum Science and Technology, 2013,33(6):524-527.
程宏昌，端木庆铎，石峰，等. 双微通道板紫外像增强器工作特性研究[J]. 真空科学与技术学报,2013,33(6):524-527.
[7]He Yingping, Yin Lei, Bai Xiaofeng, et al. Testing method of radiation gain about UV image intensifier[J]. Vacuum Electronics, 2013(1):56-58.
贺英萍，尹雷，拜晓锋，等. 紫外像增强器辐射增益测试方法研究[J]. 真空电子技术,2013(1):56-58.
[8]Shi Jifang, Wang Shengyun, Sun Yunan, et al. Third generation of image intensifier brightness gain measurement device[J]. Journal of Applied Optics，2011，32（2）：300-302.
史继芳, 王生云, 孙宇楠,等. 三代微光像增强器亮度增益测量装置[J].应用光学，2011，32（2）：300-302.
[9]He Yingping. The research of UV image intensifiers’performance test［D］.Xi’an: Xi’an Technological University,2007.
贺英萍．紫外像增强器性能测试研究［D］.西安：西安工业大学，2007.
[10]Qiu Yafeng, Qian Yunsheng, Chang Benkang. Research and development of luminance gain and equivalent background input test set for LLL image intensifier[J]. Optoelectronic Technology & Information,2003,16(5):17-20.
邱亚峰,钱芸生,常本康. 像增强器亮度增益和等效背景照度测试仪的计算机模拟与研制[J]. 光电子技术与信息,2003,16(5):17-20. -
