湿热环境对Ge基中波减反射膜可靠性的影响

陈凤金, 苏现军, 马胜昔, 孙永燕, 阎凯

陈凤金, 苏现军, 马胜昔, 孙永燕, 阎凯. 湿热环境对Ge基中波减反射膜可靠性的影响[J]. 应用光学, 2015, 36(1): 93-97. DOI: 10.5768/JAO201536.0105001
引用本文: 陈凤金, 苏现军, 马胜昔, 孙永燕, 阎凯. 湿热环境对Ge基中波减反射膜可靠性的影响[J]. 应用光学, 2015, 36(1): 93-97. DOI: 10.5768/JAO201536.0105001
shu
Chen Fen-gjin, Su Xian-jun, Ma Sheng-xi, Sun Yong-yan, Yan Kai. Reliability of Ge-based MW antireflective films in hygrothermal environment[J]. Journal of Applied Optics, 2015, 36(1): 93-97. DOI: 10.5768/JAO201536.0105001
Citation: Chen Fen-gjin, Su Xian-jun, Ma Sheng-xi, Sun Yong-yan, Yan Kai. Reliability of Ge-based MW antireflective films in hygrothermal environment[J]. Journal of Applied Optics, 2015, 36(1): 93-97. DOI: 10.5768/JAO201536.0105001
shu

湿热环境对Ge基中波减反射膜可靠性的影响

  • 1.

    中国空空导弹研究院,河南 洛阳 471009;

  • 2.

    红外探测器技术航空科技重点实验室,河南 洛阳 471009

详细信息
    作者简介:

    陈凤金(1976-)，男，江西赣州人，高级工程师，主要从事红外探测器及光学薄膜技术研究。 Email:cfjin_mail@tom.com

    通讯作者:

    陈凤金(1976-)，男，江西赣州人，高级工程师，主要从事红外探测器及光学薄膜技术研究。 Email:cfjin_mail@tom.com

  • 中图分类号: TN305.8

Reliability of Ge-based MW antireflective films in hygrothermal environment

  • 1.

    China Airborne Missile Academy,Luoyang 471009,China;

  • 2.

    Aviation Key Laboratory of Science andTechnology on Infrared Detector,Luoyang 471009,China

摘要

    摘要
  • 摘要: 采用双面抛光的锗片为基底，镀制中波减反射膜，在湿热环境中分别持续24 h、224 h、324 h、424 h、524 h、、 1224 h之后，研究了湿热环境对Ge基中波减反射膜的光学特性、牢固性等可靠性的影响。实验结果表明：在现有工艺条件下，所镀制的Ge基中波减反射膜经不同时间的湿热环境之后，透过率逐渐变低，并出现CO2和H2O的特征吸收峰，吸收峰是减反射膜长时间持续在湿热环境下CO2和H2O含量增大所致；湿热环境1024 h后，边缘膜层开始出现脱落现象，1224 h后，膜层平均透过率低于85%。
    Abstract: Mid-wave(MW) antireflective films were coated on double-side polished Ge substrate, and the films were experimented in hygrothermal environment for sustaining 24 h,224 h,324 h,424 h,524 h,724 h,,1224 h,respectively. The effects of hygrothermal environment on the reliability including transmittance and adhesion of Gebased MW antireflective films were studied .The results indicate that , the transmittance of MW antireflective films becomes lower gradually after sustained in the hygrothermal environment, and the absorption peak of CO2 and H2O turnes up , resulted from the increase of the content of CO2 and H2O in the films sustained under hygrothermal environment for enough time; The fringe of film becomes desquamated after 1024 h in hygrothermal environment ,and from that time,the average transmittance is lower than 85%.
    • HTML全文
    • 参考文献(1)
  • [1]Jiang Xiujie, Sun Huixian, Wang Zhihua, et al.The demand, status and perspective of COTS components in space application[J]. Chinese Journal of Space Science, 2005.25(1):76-80.
    姜秀杰, 孙辉先, 王志华, 等  商用器件的空间应用需求、现状及发展前景[J], 空间科学学报, 2005, 25(1)：76-80.
    [2]Dinescu A, Conache G, Gavrila R. Antireflective microstructures for silicon photodetector surfaces[C]//2004 International Semiconductor Conference. NJ:CAS, 2004 :229-232.
    [3]Ma Zhibo, Hu Manli, Li Wenhui, et al.  Design and optimization of anti-reflection coating with the structure of one-dimensional rectangular groove phase grating[J].Journal of Applied Optics, 2011, 32（5）, 971-975.
    马志博, 忽满利, 李文慧, 等 一维矩形刻槽相位栅的减反特性与结构优化[J], 应用光学, 2011, 32（5）, 971-975.
    [4]Ma Xin, Liu Xiaodong. A joint reliability analysis based on materiel s multivariate lifetime field data[J]. Journal of Applied Statistics and Management, 2014, 33(2):215-221.
    马欣, 刘晓东.装备多寿命指标变量现场数据的可靠性分析[J].数理统计与管理, 2014, 33(2):215-221.
    [5]Punch J, Grimes R, Heaslip G.  Transient hygrothermal behaviour of portable electronics[C]//thermal,  mechanical and multi-physics simulation and experiments in microelectronics and micro-systems, 2005. Proceedings of the 6th International Conference on EuroSimE 2005. US:IEEE, 2005:398-405
    [6]Bai Hongyan, Tu Jielei, Xiao Xiangjiang, et al. Preparation and properties of TiO_2/SiO_2 double-layer antireflecting films[J]. Journal of Synthetic Crystals, 2013.42(10):2059-2064.
    白红艳, 涂洁磊, 肖祥江, 等. TiO_2/SiO_2双层减反射膜的制备及其性能研究[J].人工晶体学报, 2013.42(10):2059-2064.
    [7]Tang Jinfa, Gu Peifu, Liu Xu, et al.Modern optical thin-film technology [M]. Hangzhou: Zhejiang University Press, 2006:433.
    唐晋发, 顾培夫, 刘旭, 等. 现代光学薄膜技术[M].杭州：浙江大学出版社, 2006:433.
    [8]Zhang Dongping, Qi Hongji, Fang Ming, et al. Influence of the microdefect on the environment stability of thin film filters[J]. Acta Photonica Sinica, 2005, 34（6）:873-876.
    张东平, 齐红基, 方明, 等.微缺陷对薄膜滤光片环境稳定性的影响[J].光子学报, 2005.34（6）:873-876.
    [9]Institute of China Ordnance Industry Standardization.GJB2485-95 General specification for optical coating[S].Beijing: Institute of China Ordnance Industry Standardization, 1995-10-16.
    中国兵器工业标准化研究所.GJB2485-95 光学膜层通用规范[S].北京：中国兵器工业标准化研究所, 1995-10-16.
    [10]Wang Zongming, He Xinxiang, Sun Dianqing.Practical Infrared Spectroscopy[M].Beijing: Petroleum Industry Press, 1998:326.
    王宗明, 何欣翔, 孙殿卿.实用红外光谱学[M].北京：石油工业出版社, 1998:326.
    [11]Lu Wanzhen. Modern Near Infrared Spectroscopy[M].Beijing: China Petrochemical Press, 2000:22-23.
    陆婉珍.现代近红外光谱分析技术[M].北京：中国石化出版社, 2000：22-23.
